Запрос цены- Camera
- Sensor Type
1/2.9″ Progressive Scan CMOS
- Main Stream
30 fps (2560*1440，1920 × 1080, 1280 × 720)
- Max. Resolution
2560*1440
- Sub Stream
30 fps (704 × 576, 640 × 480，352 × 288)30
- Min. Illumination
Color : 0.01 Lux @（F1.6，AGC ON）
- Lens
Horizontal: 78°, Vertical: 40°, Diagonal: 93°
- Image Settings
Saturation, brightness, contrast, sharpness, AGC and white balance can be adjusted through the client or browser.
- WDR
Digital WDR
- Shutter
1/25 ~ 1/100,000 s
- Image Enhancement
Backlight compensation, 3D digital noise reduction, Grayscale range adjustment
- Main Stream Video Compression Standard
Smart265,Smart264,H.265,H.264
- Sub Stream Compression Standard
Smart265,Smart264,H.265,H.264
- Video Bitrate
256Kbps ~ 8192Kbps
- Intelligent Alarm
Smoke alarm, Fire alarm
- Protocol
TCP/IP, HTTP, HTTPS, DHCP, DNS, RTP, RTSP, RTCP, NTP, IPv4, UDP
- Interface Protocol
ONVIF(PROFILE S, PROFILE G), ISAPI，EZVIZ，ISUP，SDK, GB28181
- General
One-click restoration，Anti flicker, Heartbeat,Mirroring，Password protection, Video occlusion，IP address filtering
- Storage
Micro SD/SDHC/SDXC card (Maximum support 512 GB)
- Exception Detection
Motion detection, Obstruction alarm, Hard disk full, Hard disk error, Network disconnection, IP address conflict, Illegal access, Peripheral failure
- WEB Configuration
Support web preview, configuration and parameter import/export
- IR Range
IR：30m
- Detector
- Image Sensor
Vanadium Oxide (VOx) Microbolometer
- Pixel Size
120 ×90
- Response Waveband
8~14 μm
- Focal Length of Thermal Imaging Lens
1.2 mm
- Thermal Imaging Field of View
90° ×68°
- Palette Mode
Support 15 modes including white hot, black hot, fusion 1, rainbow, fusion 2, iron red 1, iron red 2, etc.
- Fire and Smoke Detection
Yes
- Temperature Exception Detection
Yes
- Temperature Measurement Range
-20 °C~400 °C
- Thermography Precision
±8 °C or ±8% of the reading (take the maximum value) (within a distance of 0.3 to 1.5 meters from the device)
- Noise Equivalent Temperature Difference (NETD)
≤50 mK(@25 °C,F1.0)
- Temperature Sensing Mode
Support non-contact temperature sensing
- High Temperature Alarm
Yes
- Interface
- Alarm Interface
1 way alarm input (Alarm in), 3 ways alarm output (Alarm out)
- Ethernet Interface
RJ45 10 M/100 M adaptive Ethernet port × 1
- Audio Interface
1 way built-in microphone, 1 way built-in speaker
- Professional Intelligence (Deep Learning Algorithm)
- Flame Detection
Yes
coverage: 30 meters (burning object: n-heptane, 0.1㎡ fire plate) - Smoke Detection
Yes
- General
- Ingress Protection
IP 67
- Mounting Height
Indoor: higher than 2.5 m
Outdoor: higher than 3.5 m - Power Interface Type
DC 12V round head power interface
- Power
DC 9V ~ 30V，10W MAX; PoE: 802.3af，CLASS 3 (The power adapter is not included; you will need to configure it yourself)
- Working Temperature
-20~60°C
- Working Humidity
＜95% RH
- Dimension (φ × H)
245.7 mm × 80 mm ×80 mm
- Alarm Indicator Light
Red: Alarm
Green: Operation indicator light
Yellow: Fault
Blue: Communication status indicator light - Product Implementation Standard
Q/HKD 054-2024
- Power Consumption
Max 10 W
-
1.4kg (without packaging)
- Installation
Support for hanging and wall mounting
