- Model Parameters
- ModelCS-SP206-B0-68WFBS
- Video
- Video FormatResolution: 1080P NTSC (fps):24/30/48/60 PAL (fps): 24/25/48/50 FOV:Wide/Medium/Narrow; Resolution: 720P NTSC (fps):30/60/120 PAL (fps): 25/50/120 FOV:Wide/Medium/Narrow; H.264 BP/MP/HP Level 5.1 With MP4 Muxer File Format
- Record ModeVideo, Video+Photo
- Low LightAuto-adjusts frame rate for enough exposure time
- Distortion CorrectionBetter X/Y Correction
- HiLight TagHighlight important times, used for post-processing
- Split ModeSet the length of a video clip
- ProtuneWhite Balance; ISO; Sharpness; EV Comp; Color Pattern
- Loop ModeTo set up the storage mode according to the time interval set
- Single Photo
- Image Size8MP; 4MP; 2MP
- Night2s; 5s; 10s; 15s; 20s (auto-adjusts for exposure target)
- Distortion CorrectionBetter X/Y Correction
- Meter ModeCenter, Average, Spot
- ProtuneWhite Balance, ISO, Sharpness, EV Comp, Color Pattern
- Burst
- Image Size8MP; 4MP; 2MP
- Burst Rate15 frames per second; 15 frames 2 second; 15 frames 3 second; 10 frames per second; 10 frames 2 second; 10 frames 3 second; 5 frames per second (default); 3 frames per second
- Distortion CorrectionBetter X/Y Correction
- Meter ModeCenter, Average, Spot
- ProtuneWhite Balance; ISO; Sharpness; EV Comp; Color Pattern
- Time-lapse
- Shutter ModeTime-lapse Photo, Time-lapse Video
- Image Size8MP; 4MP; 2MP
- Video Resolution1080P, 720P
- Shutter Interval1s；3s；5s；10s；30s；60s；120s；300s
- Meter ModeCenter, Average, Spot
- Night2s, 5s, 10s, 15s, 20s
- Distortion CorrectionBetter X/Y Correction
- ProtuneWhite Balance; ISO; Sharpness; EV Comp; Color Pattern
- Setup
- ViewUp, Down
- Default ModeVideo, Single, Burst, Time-lapse
- Driving ModeThe camera automatically starts recording after it detects the motion
- Video-Out ModeHDMI HD output/AV analog output
- LEDSet it on or off
- OSDTurn screen display on or off
- Quick CaptureMinimum time to turn on and engage the shutter: 2s
- Auto OffSet Auto Power Off Time
- Date And TimeSet Date And Time
- Mic GainSet the Gain of Mic
- Speaker GainSet the Gain of Speaker
- Camera ResetResets camera to default settings
- Wireless
- BLE 4.0Built-in Bluetooth 4.0
- Wi-Fi802.11b/g/n, Mobile App Support
- App & RemoteSelect connect mode with the EZVIZ Sports app Or Wi-Fi remote
- SSIDSupports SSID modification via the EZVIZ Sports app
- KEYSupports key modification via the EZVIZ Sports app
- RESETReset SSID and KEY to system default
- Display
- HDMIPlayback/Record UI
- AVAV output uses USB port
- Embedded LCD320×240 (2 inch) IPS LCD with touch panel
- General
- PlatformNC96160 (custom HIKVISION chip)
- MemoryDDR3, SPI Flash
- Lens150° Ultra-wide angle of view with less distortion
- SensorHDR Support, G-Sensor
- Battery TypeEmbedded
- Battery Life2 hours in 1080p 60fps mode (varies according to video mode)
- Audio48kHz (sampling); Advanced AGC (automatic gain control); Built-in single microphone; Single track
- InterfaceMicro USB2.0; Media playback/file transfer/charging when connecting to a PC; AV output; Micro HDMI; MicroSD
- Storage
- StandardClass 10 or up to UHS-1 level Micro SD storage card
- Capacity (Auto-Negotiati on
SDIO Clk From 24MHZ to 120MHZ)8GB; 16GB; 32GB; 4GB; 128GB - Recording TimeVaries with different resolutions and frame rates
- Photo & Video Preview
& Playback Setup - App for Mobile DeviceFor iOS and Android system
- FunctionLive view, playback, recording, configuration, video file editing, and one-touch share to social media are supported
- PlaybackDecodes photo and video files in SD Card and displays it via LCD or HDTV
