- Chassis
- Chassis Height2 U
- Bus TypeNetwork switching
- Main Control Board Slot2
- Installed Main Control Boards1
- Power Supply Slot1
- Installed Power Supplies1
- Service Board SlotInput slots: 1, output slots: 5, mixed slots: 0, empty slots: 0
- Installed Service Boards6
- Fans1
- Interface
- Optical Interface1 × 10 Gigabit optical port (SFP+)
- Electrical Interface2 × 1000 Mbps Ethernet port (RJ-45)
- USB Interface1 × USB 2.0
- Power
- Power Interface1, 100 VAC to 240 VAC, 50/60 Hz
- Device Power Consumption200 W
- Video Wall
- Video Walls8
- Video Wall Scale≤16
- Open Windows360
- Window Division1, 4, 6, 8, 9, 16, 25, 36
- Input Source Copy CapabilitySupported
- Layers36 × 720p, 18 × 1080p
- Layers per Device360
- Scenes128
- Scene Auto-Switch Delay3 s
- Video Wall Live ViewSupported(4 channels)
- Live View ResolutionCIF (352 × 288), QCIF (176 × 144), HCIF (704 × 288), DCIF (528 × 384), FCIF (704 × 576)
- Background ImageSupported (quantity: 4, max. resolution: 8129 × 4320, min. resolution: 1280 × 720, format: JPG/JPEG)
- SubtitlesQuantity per video wall: 4
- Input Image ClippingSupported (200 pixels on the left, right, top and bottom edges.)
- Local Signal Source Decoding Delay90 ms
- General
- Working Humidity10% RH to 90% RH, no condensation
- Net Weight8.27 kg (18.23 lb)
- Dimensions (W × H × D)442 mm × 88.1 mm × 385 mm (17.40 inch × 3.47 inch × 15.16 inch)
- Gross Weight11.22 kg (24.74 lb)
- Packing List1 × device, 1 × AC power cord, 1 × grounding cable, 1 × set of pads, 1 × regulatory compliance and safety information manual
- Audio Input
- Audio Input InterfaceHDMI embedded audio
- Video Input
- Video Input Interface TypeHDMI1.4
- Video Input Interfaces4
- Max. Video Input Resolution4K(Odd-numbered ports only)
- Video Input Resolution1024×768@60 Hz, 1280×1024@60 Hz, 1360×768@60 Hz, 1440×900@60 Hz, 1680×1050@60 Hz, 1280×960@60 Hz, 1600×1200@60 Hz, 1280×720@50 Hz, 1280×720@60 Hz, 1920×1080@50 Hz, 1920×1080@60 Hz, 1920×1200@60 Hz, 3840×2160@30 Hz (odd-numbered ports only).
Supports custom input resolution (odd-numbered ports only):
Even-numbered ports: Width: 800 to 4096 (a multiple of 4); height: 600 to 2160 (a multiple of 4); refresh rate: 30 Hz/60 Hz (weidth × height ≤ 1920×1200);
Odd-numbered ports: Width: 800 to 4096 (a multiple of 4); height: 600 to 2160 (a multiple of 4); refresh rate: 30 Hz/60 Hz (weigth × height ≤ 1920×1200), 30 Hz (1920×1200 < width × height ≤ 4096×2160).
- Video Encoding
- Video Encoding FormatH.265 (default), H.264
- Video Encoding Channels4
- Video Encoding Capability4 channels of 1080p
- Audio Encoding
- Audio Encoding FormatG722.1, G711_U, G711_A, AAC
- Video Output
- Video Output Interface TypeHDMI1.4
- Video Output Interfaces20
- Max. Video Output Resolution4K
- Video Output ResolutionXGA_60 Hz (1024×768@60 Hz) / SXGA_60 Hz (1280×1024@60 Hz) / 720P_60 Hz (1280×720@60 Hz) / UXGA_60 Hz (1600×1200@60 Hz) / WSXGA_60 Hz (1680×1050@60 Hz) / WUXGA_60 Hz (1920×1200@60 Hz) / 1080P_60 Hz (1920×1080@60 Hz) / 4K_30 Hz (3840×2160@30 Hz)
- Loading Capacity for Video Output to LEDSingle port load 2600000, Width 144 — 3840, Height 144 — 2160, Width must be a multiple of 2 and height must be a multiple of 2.
- Video Decoding
- Video Decoding FormatH.264, H.265, Smart264, Smart265, HIK264, MPEG2, MPEG4
- Video Decoding Channels360
- Video Decoding CapabilityH.264/H.265/Smart264/Smart265: 10 channels of 32 MP/24 MP, 20 channels of 16 MP/12 MP, 40 channels of 8 MP, 60 channels of 6 MP/5 MP, 90 channels of 4 MP, 180 channels of 1080p, or 360 channels of 720p/D1 or lower resolution @ 30 fps
HIK264: 20 channels of 720p @ 30 fps
MPEG4: 40 channels of 720p @ 30 fps (does not support resolutions above 720p)
MPEG2: 20 channels of 720p @ 30 fps (does not support resolutions above 720p)
- Audio Output
- Audio Output Interface4 × HDMI embedded audio
- Audio Decoding
- Audio Decoding FormatG711-A, G711-U, G722.1, G726-16/U/A, AAC-LC
- Device Parameters
- Device Splicing Capability20 channels
- Device Decoding Capability180 channels of 1080p 30 fps
