4-мегапиксельная сетевая камера MD 2.0 с фиксированным объективом типа «пуля»
4-мегапиксельная сетевая камера MD 2.0 с фиксированным объективом типа «пуля»
|
Image Sensor |
1/2.4″ Progressive Scan CMOS |
|
Max. Resolution |
3200 × 1800 |
|
Min. Illumination |
Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR |
|
Shutter Time |
1/3 s to 1/100,000 s |
|
Day & Night |
IR cut filter |
|
Angle Adjustment |
Pan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360° |
|
Lens Type |
Fixed focal lens, 2.8 and 4 mm optional |
|
Focal Length & FOV |
2.8 mm, horizontal FOV 105°, vertical FOV 55°, diagonal FOV 127°;4 mm, horizontal FOV 78°, vertical FOV 38°, diagonal FOV 96° |
|
Lens Mount |
M12 |
|
Iris Type |
Fixed |
|
Aperture |
F1.6 |
|
DORI |
2.8 mm, D: 76 m, O: 30 m, R: 15 m, I: 7 m;4 mm, D: 115 m, O: 45 m, R: 23 m, I: 11 m |
|
Supplement Light Type |
IR,White Light |
|
Supplement Light Range |
Up to 30 m |
|
Smart Supplement Light |
Yes |
|
IR Wavelength |
850 nm |
|
Main Stream |
50 Hz: ;20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720);60 Hz:;20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) |
|
Sub-Stream |
50 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360);60 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360) |
|
Video Compression |
Main stream: H.265+/H.265/H.264+/H.264,;Sub-stream: H.265/H.264/MJPEG |
|
Video Bit Rate |
32 Kbps to 16 Mbps |
|
H.264 Type |
Baseline Profile,Main Profile,High Profile |
|
H.265 Type |
Main Profile |
|
Bit Rate Control |
CBR,VBR |
|
Region of Interest (ROI) |
1 fixed region for main stream |
|
Scalable Video Coding (SVC) |
H.264 and H.265 encoding |
|
Audio Type |
Mono sound |
|
Audio Sampling Rate |
8 kHz/16 kHz |
|
Environment Noise Filtering |
Yes |
|
Audio Compression |
G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC |
|
Audio Bit Rate |
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC) |
|
Security |
Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address) |
|
Simultaneous Live View |
Up to 6 channels |
|
API |
Open Network Video Interface (Profile S, Profile T, Profile G),ISAPI,SDK |
|
Protocols |
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP, UPnP |
|
User/Host |
Up to 32 users;3 user levels: administrator, operator, and user |
|
Client |
iVMS-4200,Hik-Connect |
|
Web Browser |
Plug-in required live view: IE 10, IE 11,;Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ |
|
Wide Dynamic Range (WDR) |
120 dB |
|
SNR |
≥ 52 dB |
|
Day/Night Switch |
Day,Night,Auto,Schedule |
|
Image Enhancement |
BLC,HLC,3D DNR |
|
Image Settings |
Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser |
|
Privacy Mask |
4 programmable polygon privacy masks |
|
Ethernet Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
|
On-Board Storage |
;Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB |
|
Built-in Microphone |
Yes,1 built-in microphone |
|
Built-in Speaker |
Max. power consumption: 1.5 W, max. sound pressure level: 10 cm: 95 dB. |
|
Reset Key |
Yes |
|
Basic Event |
Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception |
|
Linkage |
Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,trigger capture,audible warning,flashing light |
|
Power |
12 VDC ± 25%, 0.66 A, max. 8 W,Ø5.5 mm coaxial power plug,reverse polarity protection,;PoE: IEEE 802.3af, Class 3, max. 9.5 W |
|
Material |
Metal & Plastic |
|
Dimension |
Ø110 mm × 102.7 mm (Ø4.33″ × 4.04″) |
|
Package Dimension |
150 mm × 150 mm × 141 mm (5.9″ × 5.9″ × 5.6″) |
|
Weight |
Approx. 340 g (0.7 lb.) |
|
With Package Weight |
Approx. 560 g (1.2 lb.) |
|
Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
|
Startup and Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
|
Language |
English, Ukrainian |
|
General Function |
Heartbeat,anti-banding,mirror,password protection,password reset via email |
|
Flashing Light |
Yes |
|
EMC |
;CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,;RCM: AS/NZS CISPR 32: 2015, ;IC: ICES-003: Issue 7 |
|
Safety |
UL: UL 62368-1,;CB: IEC 62368-1: 2014+A11,;CE-LVD: EN 62368-1: 2014/A11: 2017,;BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005 |
|
Environment |
CE-RoHS: 2011/65/EU, ;WEEE: 2012/19/EU, ;Reach: Regulation (EC) No 1907/2006 |
|
Protection |
IP67: IEC 60529-2013 |
