Image Sensor | 1/3″ Progressive Scan CMOS |
Max. Resolution | 2688 × 1520 |
Min. Illumination | Color: 0.005 Lux @ (F1.2, AGC ON), B/W: 0.001 Lux @ (F1.2, AGC ON), 0 Lux with IR |
Shutter Time | 1/3 s to 1/100,000 s |
Day & Night | IR cut filter |
Focus | Auto,Semi-auto,Manual |
Focal Length & FOV | 2.8 to 12 mm, horizontal FOV 105.4° to 34.3°, vertical FOV 56.1° to 19.3°, diagonal FOV 125.8° to 39.3° |
Iris Type | Fixed |
Aperture | F1.2 |
DORI | 2.8 to 12 mm:;D: 63.4 to 180.6 m, O: 25.2 to 71.7 m, R: 12.7 to 36.1 m, I: 6.3 to 18.1 m |
Supplement Light Type | IR,White Light |
Supplement Light Range | IR: up to 30 m;White Light: up to 20 m |
Smart Supplement Light | Yes |
IR Wavelength | 850 nm |
Open Resources | System memory: 60 MB;Smart RAM: 350 MB;Flash: 2 GB |
Computing Power | 1.5 TOPS |
Deep Learning Structure | Caffe,PyTorch,TensorFlow |
Programming Language | C,C++ |
Main Stream | 50 Hz: 25 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720);60 Hz: 30 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720) |
Sub-Stream | 50 Hz: 25 fps (704 × 576, 640 × 480);60 Hz: 30 fps (704 × 480, 640 × 480) |
Third Stream | 50 Hz: 10 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480);60 Hz: 10 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) |
Video Compression | Main stream: H.265/H.264 /H.265+/H.264+;Sub-stream: H.265/H.264/MJPEG;Third stream: H.265/H.264 |
Video Bit Rate | 32 Kbps to 8 Mbps |
H.264 Type | Baseline Profile,Main Profile,High Profile |
H.265 Type | Main Profile |
Bit Rate Control | CBR,VBR |
Scalable Video Coding (SVC) | H.265 and H.264 encoding |
Region of Interest (ROI) | 1 fixed region for main stream and sub-stream |
Target Cropping | Yes |
Environment Noise Filtering | Yes |
Audio Sampling Rate | 8 kHz/16 kHz/32 kHz/48 kHz |
Audio Compression | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC/MP3 |
Audio Bit Rate | 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3) |
Audio Type | Mono sound |
Simultaneous Live View | Up to 6 channels |
API | Open Network Video Interface, ISAPI, SDK, ISUP |
Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, SSL/TLS |
User/Host | Up to 32 users;3 user levels: administrator, operator, and user |
Network Storage | NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),;Together with high-end Hikvision memory card, memory card encryption and health detection are supported. |
Client | iVMS-4200, Hik-Connect, Hik-Central |
Web Browser | Plug-in required live view: IE 8+, Chrome 41.0 to 44, Firefox 30.0 to 51, Safari 8.0 to 11;Plug-in free live view: Chrome 45.0+, Firefox 52.0+;Local service: Chrome 57.0+, Firefox 52.0+;Not recommended: Safari 11+, Edge |
Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, white balance, AGC, adjustable by client software or web browser |
Wide Dynamic Range (WDR) | 120 dB |
Picture Overlay | LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format. |
Day/Night Switch | Day,Night,Auto,Schedule,Alarm Trigger |
Image Enhancement | BLC,HLC,3D DNR,Defog,Gray Scale |
Image Parameters Switch | Yes |
SNR | ≥ 50 dB |
Privacy Mask | 8 programmable polygon privacy masks |
Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
On-Board Storage | ;Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB,;*You are recommended to purchase memory card together with the product if needed. After ordering, the memory card will be installed to product during manufacturing. |
Audio | 1 input (line in), 1 output (line out) |
Alarm | 1 input, 1 output (max. 24 VDC, 1 A/110 VAC, 500 mA) |
Reset Key | Yes |
Basic Event | Motion detection (support alarm triggered by specified target types (human and vehicle)), video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) |
Smart Event | Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggered by specified target types (human and vehicle));Scene change detection, audio exception detection, defocus detection, unattended baggage detection, object removal detection |
Linkage | Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture |
Power | Three-core terminal block,;DC: 12 V, 0.94 A, max. 11.24 W,;PoE: IEEE 802.3at Class 4, max. 13.37 W |
Dimension | 290.8 mm × 162.5 mm × 141 mm (11.45″ × 6.4″ × 5.55″) |
Package Dimension | 753 mm × 313 mm × 424 mm (29.65″ × 12.32″ × 16.69″) |
Weight | Appox. 6.245 kg (13.77 lb.) |
With Package Weight | Appox. 7.96 kg (17.55 lb.) |
Startup and Operating Conditions | Air cooling (with 20 °C (68 °F) air):;1. Ambient temperature 150°C (302 °F), pressure 0.1 MPa, air volume 20 m³/h, internal body temperature 54°C (129.2 °F);2. Ambient temperature 125°C (257 °F), pressure 0.1 MPa, air volume 18 m³/h, internal body temperature 49°C (120.2 °F);3. Ambient temperature 100°C (212 °F), pressure 0.1 MPa, air volume 14 m³/h, internal body temperature 43°C (109.4 °F);4. Ambient temperature 85°C (185 °F), pressure 0.1 MPa, air volume 10 m³/h, internal body temperature 41°C (105.8 °F);Humidity 95% or less (non-condensing);*It is necessary to protect the cable from heat when the ambient temperature of the cable is above 120 °C (248 °F). |
Language | 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
Linkage Method | Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture |
General Function | Anti-banding, three streams, heartbeat, mirror, flash log, password reset via email, pixel counter |
EMC | CE-EMC (EN 55032: 2015+A11:2020+A1:2020, EN 50130-4: 2011+A1: 2014,EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3: 2013+A1:2019+A2:2021);UKCA (EN 55032: 2015+A11:2020+A1:2020, EN 50130-4: 2011+A1: 2014,EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3: 2013+A1:2019+A2:2021) |
Environment | CE-RoHS (RoHS Directive 2011/65/EU+2015/863) |
Protection | IP68 (IEC 60529-2013) |
