4-мегапиксельная вариофокальная бокс-камера DeepinView
4-мегапиксельная вариофокальная бокс-камера DeepinView
По запросу
Запрос цены|
Image Sensor |
1/1.8″ Progressive Scan CMOS |
|
Max. Resolution |
2688 × 1520 |
|
Min. Illumination |
Color: 0.0003 Lux @ (F1.0, AGC ON),B/W: 0.0001 Lux @ (F1.0, AGC ON),B/W: 0 Lux with IR |
|
Shutter Time |
1 s to 1/100,000 s |
|
Day & Night |
IR cut filter,;Blue glass module (less ghost phenomenon) |
|
Angle Adjustment |
Pan: 0° to 355°,tilt: 0° to 65°,rotate: 0° to 360° |
|
Focal Length & FOV |
2.8 mm: horizontal FOV 111.0°, vertical FOV 57.6°, diagonal FOV 138.4°;4 mm: horizontal FOV 94.7°, vertical FOV 49.4°, diagonal FOV 112.6° |
|
Iris Type |
Fixed |
|
Aperture |
F1.0 |
|
DORI |
2.8 mm: D: 61.5 m, O: 24.4 m, R: 12.73 m, I: 6.2 m;4 mm: D: 72.1 m, O: 28.6 m, R: 14.4 m, I: 7.2 m |
|
Supplement Light Type |
Hybrid (IR and White Light) |
|
Supplement Light Range |
Up to 40 m |
|
Smart Supplement Light |
Yes |
|
IR Wavelength |
850 nm |
|
Open Resources |
Memory: 40 MB,;Smart RAM: 350 MB,;eMMC: 1 GB |
|
Computing Power |
1.5 TOPS |
|
Open Capability |
HEOP 2.0 OpendevSDK |
|
Deep Learning Structure |
Caffe,TensorFlow,PaddlePaddle,ONNX |
|
Programming Language |
C++ |
|
Main Stream |
50 Hz: 25 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720);60 Hz: 30 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720) |
|
Sub-Stream |
50 Hz: 25 fps (704 × 576, 640 × 480);60 Hz: 30 fps (704 × 480, 640 × 480) |
|
Third Stream |
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) ;60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) ; |
|
Fourth Stream |
50 Hz: 25 fps (704 × 576, 640 × 480) ;60 Hz: 30 fps (704 × 480, 640 × 480) ; |
|
Fifth Stream |
50 Hz: 25 fps (704 × 576, 640 × 480);60 Hz: 30 fps (704 × 480, 640 × 480); |
|
Video Compression |
Main stream: H.265+/H.265/H.264+/H.264,;Sub-stream: H.265/H.264/MJPEG,;Third stream: H.265/H.264,;Fourth stream: H.265/H.264/MJPEG,;Fifth stream: H.265/H.264/MJPEG |
|
Video Bit Rate |
32 Kbps to 8 Mbps |
|
H.264 Type |
Baseline Profile,Main Profile,High Profile |
|
H.265 Type |
Main Profile |
|
Bit Rate Control |
CBR,VBR |
|
Scalable Video Coding (SVC) |
H.264 and H.265 encoding |
|
Target Cropping |
Yes |
|
Region of Interest (ROI) |
4 fixed regions for each stream |
|
Audio Type |
Mono sound |
|
Audio Compression |
G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
|
Audio Bit Rate |
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
|
Audio Sampling Rate |
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
|
Environment Noise Filtering |
Yes |
|
Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, SRTP, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4/IPv6, UDP, Bonjour, SSL/TLS, ARP, WebSocket, WebSockets |
|
Simultaneous Live View |
Up to 20 channels |
|
API |
Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP |
|
User/Host |
Up to 32 users;3 user levels: administrator, operator, and user |
|
Security |
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2, TLS 1.3 |
|
Network Storage |
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),;Together with high-end Hikvision memory card, memory card encryption and health detection are supported. |
|
Client |
iVMS-4200,Hik-Connect |
|
Web Browser |
Plug-in required live view: IE 10, IE 11,;Plug-in free live view: Chrome 57.0+, Firefox 52.0+ |
|
Image Parameters Switch |
Yes |
|
Image Settings |
Saturation,brightness,contrast,sharpness,AGC,white balance,adjustable by client software or web browser |
|
Day/Night Switch |
Day,Night,Auto,Schedule,Alarm Trigger,Video Trigger |
|
Wide Dynamic Range (WDR) |
140 dB |
|
Image Enhancement |
BLC,HLC,3D DNR,Defog |
|
Privacy Mask |
8 programmable polygon privacy masks |
|
Picture Overlay |
LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format. |
|
Image Stabilization |
EIS |
|
Ethernet Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
|
On-Board Storage |
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1 TB |
|
Alarm |
1 input, 1 output (max. 12 VDC, 30 mA) |
|
Audio |
1 input (line in), input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium, 1 output (line out), output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium, mono sound |
|
RS-485 |
1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) |
|
Reset Key |
Yes |
|
Power Output |
12 VDC, max. 100 mA |
|
Basic Event |
Motion detection,video tampering alarm,video quality diagnosis,exception (network disconnected, IP address conflict, illegal login, abnormal restart, HDD full, HDD error),vibration detection |
|
Smart Event |
scene change detection,audio exception detection,defocus detection |
|
Linkage |
Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,audible warning |
|
Face Capture |
;Detects up to 60 faces simultaneously,;Supports swing left and right from -60° to 60°, tilt up and down from -30° to 30°,;Uploads face with background and closed-up face pictures |
|
People Counting |
Supports crossline people counting,;Supports counting, displaying and exporting the people flow data of entering and exiting. (The data is stored in the flash.),;The real-time people flow data is displayed on the screen. ,;Supports swing left and right from -60° to 60°, tilt up and down from -30° to 30°.,;Uploads face with background and closed-up face picture.,;Supports real-time uploading and uploading by statistic cycle |
|
Queue Management |
Supports up to 8 detection regions, and independent arming schedule and linkage method,;Supports 2 detection modes: regional people queuing-up, waiting time detection,;Generates reports to compare the efficiency of different queuing-ups and display the changing status of one queue,;Supports raw data export for further analysis,;Supports real-time data uploading and scheduled data uploading,;Regional people queuing-up: supports 4 alarm trigger conditions, including greater than threshold, less than threshold, equal to threshold, not equal to threshold,;Waiting time detection: supports 1 alarm trigger condition, including greater than threshold |
|
Heat Map |
A graphic description of visits (by calculating amount of people or amount of dwell time) in a configured area.,;Two report types are available, space heat map and time heat map line chart. |
|
Perimeter Protection |
Line crossing, intrusion, region entrance, region exiting,;Support alarm triggering by specified target types (human and vehicle) |
|
Metadata |
Intrusion detection,line crossing detection,region entrance detection,region exiting detection |
|
On/Off Duty Detection |
Supports up to 8 detection regions, and independent arming schedule and linkage method,;Supports 2 detection modes: absence detection, on/off duty detection,;Supports parameter settings: person on duty, absence duration |
|
Power |
;12 VDC ± 20%, 0.66A, max. 7.9 W,;PoE: IEEE 802.3af, Type 1, Class 3, 36 V to 57 V, 0.16 A to 0.26 A, max. 9.69 W |
|
Material |
Aluminum alloy body |
|
Dimension |
;Ø138.6 mm × 124.4 mm (Ø5.46 × 4.86″)»» |
|
Package Dimension |
170 mm × 170 mm × 150 mm (6.7″» × 6.7″» × 6.0″») |
|
Weight |
Approx. 820 g (1.81 lb.) |
|
With Package Weight |
Approx. 1095 g (2.42 lb.) |
|
Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
|
Startup and Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
|
Language |
;33 languages: English Для отправки отзыва вам необходимо авторизоваться. Альтернативные товары Hikvision iDS-2CD7046G2/E-IHSYR 4-мегапиксельная вариофокальная бокс-камера DeepinView с корпусом 4-мегапиксельная вариофокальная бокс-камера DeepinView с корпусом По запросу Запрос цены 8-мегапиксельная вариофокальная бокс-камера DeepinView 8-мегапиксельная вариофокальная бокс-камера DeepinView По запросу Запрос цены Hikvision iDS-2CD7146G2-IZ(H)S(Y)(1T) 4-мегапиксельная купольная камера DeepinView с переменным фокусным расстоянием 4-мегапиксельная купольная камера DeepinView с переменным фокусным расстоянием По запросу Запрос цены Hikvision iDS-2CD7186G2-IZ(H)S(Y) 8-мегапиксельная купольная камера DeepinView Moto с вариофокальным объективом 8-мегапиксельная купольная камера DeepinView Moto с вариофокальным объективом По запросу Запрос цены Hikvision iDS-2CD7A45G2-IZHS(Y) 4-мегапиксельная вариофокальная цилиндрическая камера DeepinView Moto 4-мегапиксельная вариофокальная цилиндрическая камера DeepinView Moto По запросу Запрос цены Hikvision iDS-2CD7A45G2/P-IZHS(Y) 4-мегапиксельная мотокамера DeepinView ANPR с вариофокальным объективом типа «пуля» 4-мегапиксельная мотокамера DeepinView ANPR с вариофокальным объективом типа «пуля» По запросу Запрос цены Hikvision iDS-2CD7A46G2-IZHS(Y)(1T)(/5G) 4-мегапиксельная вариофокальная цилиндрическая камера DeepinView Moto 4-мегапиксельная вариофокальная цилиндрическая камера DeepinView Moto По запросу Запрос ценыНовинка  Hikvision iDS-2CD7A46G2/P-IZHS(Y)(/5G) 4-мегапиксельная мотокамера DeepinView ANPR с вариофокальным объективом типа «пуля» 4-мегапиксельная мотокамера DeepinView ANPR с вариофокальным объективом типа «пуля» По запросу Запрос цены Hikvision iDS-2CD7A47G2-XZHS(Y) 4-мегапиксельная вариофокальная цилиндрическая камера DarkfighterS DeepinView Moto 4-мегапиксельная вариофокальная цилиндрическая камера DarkfighterS DeepinView Moto По запросу Запрос цены Hikvision iDS-2CD7A47G2/P-XZHS(Y) 4-мегапиксельная мотокамера DarkfighterS DeepinView ANPR с вариофокальным объективом типа «пуля» 4-мегапиксельная мотокамера DarkfighterS DeepinView ANPR с вариофокальным объективом типа «пуля» По запросу Запрос цены Hikvision iDS-2CD7A86G2-IZHS(Y)(/5G) 8-мегапиксельная вариофокальная цилиндрическая камера DeepinView Moto 8-мегапиксельная вариофокальная цилиндрическая камера DeepinView Moto По запросу Запрос цены
|
