- Perimeter Protection
- Human/Vehicle AnalysisUp to 16-ch 4 MP (HD network camera, up to 8 MP, H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm
- Video and Audio
- IP Video Input16-ch
Up to 12 MP resolution - Incoming Bandwidth320 Mbps
- Audio Output1-ch, RCA (Linear, 1 KΩ)
- Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 k Ω)
- Outgoing Bandwidth256 Mbps
- Decoding
- Decoding FormatH.265+,H.265,H.264+,H.264,MPEG4
- Decoding Capability16-ch@1080p (30 fps)
- Synchronous playback16-ch
- Recording Resolution12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/2CIF/CIF/QCIF
- Stream TypeVideo, Video & Audio
- Dual-streamSupport
- Audio CompressionG.711ulaw/G.711alaw/G.722/G.726/MP2L2
- Network
- Network ProtocolTCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
- Remote Connection128
- Network Interface2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
- RAID
- RAID TypeNo
- Auxiliary Interface
- Serial InterfaceRS-485 (full-duplex), RS-232
- SATA1 SATA interface
- Alarm In/Out16/4
- Capacity1 built-in 3.5-inch 2 TB SATA hard disk
- General
- Power Supply12 VDC, 3.33 A
- Consumption≤ 30 W
- Working Temperature-10 to +55° C (+14 to +131° F)
- Working Humidity10 to 90 %
- Dimension (W × D × H)320 × 245 × 70 mm (12.6″× 9.6″ × 2.8″)
- ≤ 4.5 kg (9.9 lb)
- Certification
- FCCPart 15 Subpart B, ANSI C63.4
- CEEN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
- Obtained CertificationCE, FCC, UL, CB, WEEE, BIS, IC, RCM, KC, LOA
