Hikvision DS-QAE0A240G1-VB6 — 240W 6-Zone аналоговый усилитель
Hikvision DS-QAE0A240G1-VB6 — 240W 6-Zone аналоговый усилитель
По запросу
Запрос цены- Microphone
- Typeelectret
- Polar Patterncardioid
- Frequency Response50 Hz to 16 kHz
- Sensitivity-42 dB±2 dB (0db=1V/Pa at 1KHz)
- SNR78 dB
- Dynamic Range104 dB
- Acoustic Overload Point (AOP)120 dB
- Total Harmonic Distortion (THD)THD<1%
- Speaker
- Rated Power3 W
- Sensitivity(1 m, 1 W)71 dB
- Maximum Sound Pressure Level76 dB
- Speaker UnitØ36 mm × 16.1 mm
- Speaker TypeBuilt-in Speaker:
Rated Impedance: 4 Ω
Resonant Frequency: 300 Hz
Frequency Response: 300 Hz to 10 kHz
- Function
- Audio AlgorithmNoise Gate, EQ, AGC, Compressor, AEC, Noise Reduction
- Audio Bit RateBroadcast: MP3 128 kbps
Two-Way Audio: G711 64 kbps - Audio File FormatFormat: MP3, WAV
Bit Width: 16bit
Maximum Single File Size: 100 MB - Echo CancellationSupport
- Network
- Network ProtocolIPv4, HTTP, HTTPS , SIP, SSL/TLS , DNS, NTP, TCP, UDP, IGMP, ICMP, DHCP, ARP, SSH
- Interface Protocol (API)ISAPI, SIP
- Network SecurityPassword protection, complicated password, HTTPS encryption, basic and digest authentication for HTTP/HTTPS, security audit logs, TLS 1.2/1.3
- Interface
- Alarm1 alarm input
1 alarm output - Network Interface1 RJ45 10 M/100 M adaptive Ethernet port
- Local StorageEMMC：4 GB
- Audio InGooseneck MIC, 4-pin aviation connector
MIC × 1, 0 dBV, 10 kΩ, unbalance, 3.5 mm jack
AUX In × 1, 0 dBV, 10 kΩ, unbalance, 3.5 mm jack
USB drive, USB 2.0
Bluetooth, Bluetooth 5.0 - Audio OutAUX Out × 1, 0 dBV, unbalance, 3.5 mm jack, supports connection to 3.5 mm interface headphones, capable of driving loads above 32 Ω.
Local speaker - Volume KnobMIC Volume Knob, AUX Volume Knob, MAIN Volume Knob
- ButtonHOME button, broadcast button, intercom button, listening button, back button, emergency broadcast button
- USBUSB 2.0. File format: FAT32 and EXFAT, maximum capacity: 256 GB.
FAT32 formatted USB drive: maximum capacity of a single partition is 32 GB
EXFAT formatted USB drive: Maximum capacity of a single partition is 256 GB - Display ScreenType: IPS
Size: 4 inches
Resolution: 480 × 800
Touch: Support
- General
- Power12 VDC , 12 W
- ColorBlack
- BluetoothBluetooth 5.0, 10 m
- Operating Condition-10 °C to +50 °C(14 °F to 122 °F), humidity 10% to 90%
- Dimension191 mm × 114.8 mm × 62.9 mm (7.52″ × 4.52″ × 2.48″) (L × W × H)
- Package Dimension386 mm × 218 mm × 93 mm (15.2″ × 8.58″ × 3.66″) (L × W × H)
- 0.51 kg (1.12 lb.)
- With Package Weight1.05 kg (2.31 lb.)
