Hikvision DS-QAE0A240G1-VB6 — 240W 6-Zone аналоговый усилитель
Hikvision DS-QAE0A240G1-VB6 — 240W 6-Zone аналоговый усилитель
По запросу
Запрос цены- Audio
- Frequency Response100 Hz-15 KHz, ±3 dB
- THD and SNRTHD: ≤2% (1KHz)
SNR: ≥65 dB - Audio Input1.-50dBx(MIC)/-10dB x(LINE) 2. 600ΩBGM 1-2:10dBx10KΩ
- Audio Output2 PIN screw terminal used to connect with speaker to output amplifier signals
(the max output power=450W). - Backup AMP Connection1 RJ45 port used to receive the signal from backup amplifier or connect with device
DS-QAE0A450G1-V/ENB. - Input Control2 groups of terminal blocks used to input external control signal (related voltage 12V) or control
external short-circuit. - Backup Amp Input2 PIN screw terminal used to connect with device DS-QAE0A450G1-V/ENB to receive signals from
backup amplifier. - Main Control Input1 RJ45 port used to connect with device DS-QAE0A360G1-V6 for audio input or or communication.
The cable (CAT5E-STP) recommended. - Main Control Link1 RJ45 port used to connect with below devices for audio output or communication.
DS-QAE0A150G1-V/EN / DS-QAE0A300G1-V/EN / DS-QAE0A450G1-V/EN
- General
- PowerAC 220-240V~, 50/60Hz, 450 W
- Dimension483x469x89 mm
- 11.7 kg
- Packing ListExtension Amplifier x1; Power Line x1;
- Operating Temperature-5°C~45 °C
- Power Consumption600 W Max
