Новинка
6,5-дюймовый сетевой безрамочный потолочный динамик PoE
6,5-дюймовый сетевой безрамочный потолочный динамик PoE
По запросу
Запрос цены- Audio
- Frequency Response1、Mic Input to Main Output：
<10 Hz～90 kHz -0 dB/-1 dB；<10 Hz～160 kHz +0 dB/-3 dB
2、Stereo input
typology 6.3 mm stereo, unbalanced；impedance about 10 kΩ；Maximum Input +22 dBu; 3、EQ single channel
LOW: 80 Hz/±15 dB; MID: 100 Hz～8 kHz/±15 dB; HIGH:12 kHz/±15 dB
4、EQ Stereo Channel
LOW: 8 0Hz/±15 dB; MID: 2 kHz/±15 dB; HIGH: 12 kHz/±15 dB - Microphone Input (Microphone Preamplifier)Typology XLR Electronically Balanced, Discrete Input Circuits
@0Ω source resistor -134dB/135.7dB A
@50Ω source resistor -131dB/133.3dB A
@150Ω source resistor -129dB/130.5dB A
frequency response <10Hz～150kHz(-1dB) <10Hz～200kHz(-3dB）
gain +10dB～+60dB
Maximum Input +12dBu@+10dB Gain
impedance 2.6kΩ
signal-to-noise ratio 110dB/112dB 0dBu In @+22dB gain)
distortion 0.005%/0.004%
typology 6.3mm stereo, balanced
impedance Balanced output: 20kΩ Unbalanced output: 10kQ
gain -10dB～+40dB
Maximum Input +22dBu@OdB Gain - Signal Attenuation (Crosstalk Attenuation)Main fader off: 90dB
Channel Mute: 89dB
Channel fader off: 89dB - AUX SENDStypology 6.3mm mono unbalanced
impedance 120Ω
maximum output +22dBu - Sub Group Sendingtypology 6.3mm Mono unbalanced
impedance 120Ω
Maximum output +22dBu - Headphone Outputtypology 6.3mm stereo
Maximum output +19dBu 150Ω(+25dBm) - Noisesmaster mix@-∞ -101dB
channel fader@-∞ -100dB
master mix@0dB -93dB
channel fader@-∞ -96dB
master mix@0dB -81dB
channel fader@0dB -83dB
- Interface
- Voltage Input230 V~50/60 Hz
- General
- MaterialCold Rolled Plate, Plastic
- Dimension360 x 493.5 x 88 mm
- Package Dimension570 x 435 x 175 mm
- 5.15 kg
- With Package Weight8.2 kg
- ColorPANTONE BLACK 6C
- Operating TemperatureAmbient Temperature: -10～40 ℃, Relative Humidity: ≤90
- InstallationIntegral mounting
- Power Consumption35 W
