Detection Method |
Passive Infrared |
|
Detection Range |
18m |
|
Detection Angle |
90° |
|
Detection Zones |
118 |
|
Detectable Speed |
0.3～2m/s |
|
Sensitivity |
Auto;Pet |
|
White Light Filter |
2000lux |
|
Digital Temperature Compensation |
Support |
|
Pet Immunity |
Up to 24Kg |
|
Digital Processing |
Support |
|
Sealed Optics |
Support |
|
Tamper Protection |
Front;Rear |
|
End of line resistance |
Alarm: 1K,2K2,4K7,5K6,6K8;Tamper: 1K,2K2,4K7,5K6 |
|
Alarm output |
Normally Closed |
|
LED Indicator |
Blue(Alarm),Orange(Fault) |
|
Power consumption |
Maximumcurrent：15mA @12VDC;Quiescent current：8mA@12VDC |
|
Typical voltage |
12 VDC |
|
Power supply |
9 to 16 VDC |
|
IP rate |
IP 65 |
|
Operation Temperature |
-25 °C to 70 °C (-13 °F to 158 °F) |
|
Storage Temperature |
-25 °C to 70 °C (-13 °F to 158 °F) |
|
Operation Humidity |
10% to 90% |
|
Dimension(WxHxD) |
67.3 × 142.0 × 60.0 mm |
|
Weight |
226.3 g |
|
Mounting Height |
2.5 — 3m High Mount;0.8 — 1.2m Low Mount |
|
Mounting Method |
Wall |
|
Application Scenario |
Indoor,Outdoor |
