Motor |
N/A |
|
MCBF |
＞3 million times |
|
Exit button |
2 |
|
Alarm input |
1 |
|
TAMPER |
NA |
|
Throughput |
More than 35 persons per minute;The actual throughput is affected by the person passing rate and passing method. |
|
Lane width |
550mm |
|
Barrier material |
SUS304 stainless steel |
|
Pedestal material |
SUS304 stainless steel |
|
Built-in access controller |
No |
|
Power supply |
Switching power supply: 100 to 240 VAC; 50 to 60 Hz;Power adapter: 100 to 240 VAC; 50 to 60 Hz |
|
Power consumption |
Standby: 40W; |
|
Working temperature |
Switching power supply: -20 °C to 65 °C (-4 °F to 149 °F);Power adapter: -10 °C to 45 °C (14 °F to 113 °F) |
|
Working humidity |
0% to 95% (No condensing) |
|
Dimensions |
Without package: 232 mm × 960 mm × 1208 mm (9.1″ × 37.8″ × 47.6″»);With package: 390 mm × 1185 mm × 1320 mm (15.4 × 46.7″» × 52.0″»)»» |
|
Weight |
Without package: 45 kg (99.2 lb);With package: 69 kg (152.1 lb) |
|
Application environment |
Indoor and outdoor |
|
Module selection |
NO |
|
Base model |
DS-K3G501-BASE |
|
Remote controller type |
NA |
«
