Hikvision DS-K1109DKFB

TAMPER

1

RS-485

1

Wiegand

1

Fingerprint capacity

5000

Card type

M1 card;DESfire card;Felica card

Power supply

12 VDC

Power consumption

With load: ≤ 14 w;Without load: ≤ 4 w

Working temperature

-40 °C to 65 °C (-40 °F to 149 °F)

Working humidity

0 to 90% (no condensing)

Protective level

IP65

Dimensions

125 mm × 84.5 mm × 18 mm (4.92″ × 3.33″ × 0.71″)

Installation

Wall mounting

Weight

≤ 1 kg (2.20 lb)

Buzzer

Support
