- System parameters
- Operation systemAndroid 7.1
- ROM4 GB
- RAM2 GB
- ProcessorEmbeded high performance processor
- Display parameters
- Screen size10.1-inch
- Operation methodCapacitive touch screen
- TypeColorful IPS
- Resolution1280 × 800
- Brightness410cd/m²
- Video parameters
- Lens2 x 2 MP HD camera with low illumination
- Resolution
Main stream:1920 × 1080p and 1280 × 720p
Sub stream: 1280 × 720p and 640 × 480p
- FOVHorizontal: 88°, Vertical: 44°
- Wide dynamic range (WDR)Digital WDR/120 dB
- Supplement lightIR light, up to 3 m
- Video compression standardH.264
- Audio parameters
- Audio input2 built-in omnidirectional microphone
- Audio compression standardG.711 U, G.711 A
- Audio output1 built-in loudspeaker
- Audio compression bitrate64 Kbps
- Audio qualityNoise suppression and echo cancellation
- Volume adjustmentAdjustable
- Capacity
- User capacity20000
- Face capacity10000
- Fingerprint capacity/
- Card capacity100000
- Message capacity/
- Linked indoor station capacity500
- Sub door station capacity16
- Network parameters
- Network protocolTCP/IP, RTSP
- Wi-FiWi-Fi 802.11 b/g/n
- BluetoothSupport
- 3G/4G/
- Authentication
- Card reading frequency13.56 MHz
- Device interfaces
- Alarm input4 (2 exit butttons and 2 door contacts by default)
- Network interface2 RJ-45 10/100/1000 Mbps self-adaptive (1 reserved)
- TAMPER1
- Exit button2 (1 for lock control and 1 for secure door control unit)
- RS-4852 RS-485 (Half duplex, HIKVISION)
- USB2 for internal use only
- Wiegand/
- TF card1 (reserved)
- Alarm output2 (reserved)
- Lock control2 relays, Max. 30 VDC, 2 A, lock 2 needs secure module
- Door contact input1
- General
- InstallationSurface mounting and flush mounting
- Indicator/
Net weight: 1.225kg
Gross weight: 3.333kg
- Protective levelIP65 and IK07
- Working temperature-30 °C to 60 °C (-22 °F to 140 °F)
- Working humidity10% to 90% (no-condensing)
- Dimension (W × H × D)271 mm × 159.2 mm × 26.5 mm (10.7″ × 6.3″ × 1″)
- Battery/
- Power supply12 VDC, 2 A
- Application environmentOutdoor
- Power consumption≤ 18 W
- LanguageEnglish,French,Portuguese,BrazilianPortuguese,Spanish,Russian,German,Italian,Polish,Turkish,Vietnamese,Arabic,Czech,Hungarian,Dutch,Romanian,Bulgarian,Ukrainian,Croatian,Serbian,Greek,Lithuanian,Estonia,Latvian,Norwegian,Danish,Slovakia,Hebrew,Swedish,Finnish,TraChinese,Mongolian,HongKongTraChinese
