Qiymət sorğusu- System parameters
- Operation systemAndroid 14
- ROM16GB
- RAM4GB
- ProcessorEmbedded high performance processor
- Display parameters
- Screen size10.1-inch
- Operation methodCapacitive touch screen
- TypeColorful IPS
- Resolution1920 ×1200
- Video parameters
- Lens1 with privacy shutter (face anti-spoofing not supported)
- Resolution5MP, 2592×1944
- Video compression standardH.264, H.265
- Audio parameters
- Audio input2 built-in omnidirectional microphone
- Audio compression standardG.711A, G.711U, G.722.1, G726, Opus, AAC, AAC_LD
- Audio output2 built-in loudspeaker
- Audio compression bitrate64 Kbps
- Audio qualityNoise suppression and echo cancellation
- Volume adjustmentAdjustable
- Capacity
- Linked doorphone capacity17
- Message capacity200 captured pictures, 200 alarm records, 200 unlock records, 200 temper records
- Face capacity50
- Linked indoor extensions capacity15
- Linked network camera capacity16
- Network parameters
- Wi-FiWi-Fi 6, 2.4 GHz & 5GHz
- BluetoothBLE 5.0
- Network protocol
IPv4, SIP, HTTP, HTTPS, DNS, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
SIP v1 (RFC2543), SIP v2 (RFC3261)
DTMF: SIP Info
SADP, ISAPI, ONVIF
- Device interfaces
- Alarm input8 (Reserved)
- Network interface2 RJ-45 10/100 Mbps self-adaptive，1 for Video Intercom, 1 for Smart Home
- RS-4851 RS-485 (Half duplex)
- TF cardSupport TF card, up to 256 G
- Alarm output2 high/low level alarm output (3.3V/0V) (Reserved)
- Power supply input12 VDC
- Power supply output12 VDC, 200mA
- Relay2 (Reserved), Max. 30VDC 1A
- NTC1, R25=10KΩ±1%, B25/50=3950K±1%
- General
- Proximity SensorDistance: 50cm, Horizontal: 25°, Vertical: 25°
- InstallationSurface mounting
- Without package: 556 g (1.23 lb),With package: 650g (1.43 lb)
- Working humidity10% to 90% (no-condensing)
- Working temperature-10 °C to 50 °C (14 °F to 122 °F)
- Dimension (W × H × D)246.58 mm × 155.76 mm × 23.62 mm (9.71″ × 6.13″ × 0.93″)
- Power supply12 VDC, 2.5 A; IEEE 802.3at, Standard PoE
- Application environmentIndoor
- Power consumption≤ 24 W
- LanguageEnglish, Arabic, French, Russian, Spanish, Spanish (Latin America), Italian, German, Polish, Turkish, Portuguese, Portuguese (Brazil), Uzbek, Kazakh, Czech, Hungarian, Dutch, Romanian, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Lithuanian, Estonian, Latvian, Norwegian, Danish, Slovenian, Slovak, Hebrew, Swedish, Finnish, Mongolian, Vietnamese, Traditional Chinese
