Qiymət sorğusu- Software features
- Wired network10 M/100 M Self-adaptive Ethernet port
- Hardware features
- Electrical lockerElectronic Controlled Cabinet Lock/Normal Cabinet Lock
- Tamper-Prooftamper alarm
- Netowrk interface1RJ45,10 M/100 M/1000 M self adaptive
- Audio interface1-ch Built-in Omnidirectional Microphone, Pickup Distance: 5 m
1-ch 3.5 mm Audio Interface for External Audio Input - PSTN1
- BusRS-485 1, Half-duplex
- SD cardStandard Micro SD card Slot, Supports Micro SD/SDHC/SDXC Card, Max. 128G
- Loudspeaker110dB, Sound Can be Configured Separately
- Video
- Resolusion1920*1080
- Frame rate25fps
- Field angleHorizontal: 128°
Vertical: 75°
Diagonal: 147°
- Day/night switch modeIR Cut Filter
- Audio
- Audio input1-ch Built-in Omnidirectional Microphone, Pickup Distance: 5 m
1-ch 3.5 mm Audio Interface for External Audio Input - Audio output1-ch 30 W Build-in Loudspeaker
1-ch 3.5 mm Audio Interface for External Audio Output - Intercom1-ch Built-in Omnidirectional Microphone, Pickup Distance: 5 m
- Audio compression code rate64Kbps;16Kbps
- Electrical characteristics
- Operation temperature-40 °C to +60 °C (-40 °F to 140 °F)
- Power supply110-240V AC
- Operation humidity10% to 90%
- Power consumption ≤ 70 W
- General
- Dimension(WxHxD)Without Bracket: 450 mm × 500 mm × 2205 mm (17.72” × 19.69” × 86.81″)
With Bracket: 450 mm × 500 mm × 4500 mm (17.72” × 19.69” × 177.17”) - Installation methodGround Mounting
- Device management
- Alarm input2
- Alarm output2
- Camera2 MP HD IR Camera
- Sounder output110dB, Sound Can be Configured Separately
- Lamp1 Red and Blue Alarm Lamp, Light Can be Configured Separately
- Report method
- ProtocolTCP/IP, RTSP, HIK-SIP,ONVIF
