Hikvision DS-3E6600-24T24F2X-SA

Artikul: HC-DS-3E6600-24T24F2X-SA

Hikvision DS-3E6600-24T24F2X-SA — DS-3E6603 LPU modul, 24 Gigabit SFP Ports, 2 * 10GE SFP+ Ports

Port: 24 × Gigabit Ethernet port ,24 × Gigabit SFP port,2 × 10 Gigabit SFP+ port
Switching Capacity: Port Performance: 960 Gbps Whole-Device Performance: 1440 Gbps
Packet Forwarding Rate: Port Wire-Speed Packet Forwarding Rate: 714.24 Mpps Whole-Device Packet Forwarding Rate: 1071.36 Mpps
Main Processing Unit (MPU) Slots: 1 (Only slot 1 for both MPU and LPU)
Switching Fabric Unit (SFU) Slots: 0 (No dedicated SFU slots)
Line Processing Unit (LPU) Slots: 3 (Slot 1 for both MPU and LPU)
Power Supply Unit (PSU) Slots: 2
Fan Slots: 1

Sürətli çatdırılma

Mövcudluq təsdiqləndikdən sonra
Azərbaycan daxilində 1-2 gün

Rəsmi zəmanət

36 aya qədər
istehsalçıdan

100% orijinal

Hikvision-un rəsmi distribyutoru

Texniki dəstək

Avadanlıqların seçilməsi və qurulmasında köməklik

Mövcudluğu dəqiqləşdirin

Sorğu əsasında

Hissə-hissə alın

Partnyorlar üçün qiymət

Endirim tələb edin

Mütəxəssis köməyi

Müqayisə et

Avadanlıq seçməkdə çətinlik çəkirsiniz?

Hardware Specifications
Port24 × Gigabit Ethernet port ,24 × Gigabit SFP port,2 × 10 Gigabit SFP+ port
Switching CapacityPort Performance: 960 Gbps
Whole-Device Performance: 1440 Gbps
Packet Forwarding RatePort Wire-Speed Packet Forwarding Rate: 714.24 Mpps
Whole-Device Packet Forwarding Rate: 1071.36 Mpps
Main Processing Unit (MPU) Slots1 (Only slot 1 for both MPU and LPU)
Switching Fabric Unit (SFU) Slots0 (No dedicated SFU slots)
Line Processing Unit (LPU) Slots3 (Slot 1 for both MPU and LPU)
Power Supply Unit (PSU) Slots2
Fan Slots1
Power Supply1+1 redundancy backup, 1 PSU included as standard
Fan1 modular fan(s)
MAC Address Capacity32 K
Cache16 Mbits
Dimensions (W × H × D)436.6 mm × 40.6 mm × 210.0 mm (17.19” × 1.60” × 8.27”)
Net Weight1.89 kg (4.17 lb)
Gross Weight3.067 kg (6.76 lb)
Operating Temperature0°C to 50°C (32°F to 122°F)
Operating Humidity5% to 95% (no condensation)
Storage Temperature-40°C to 85°C (-40°F to 185°F)
Storage Humidity5% to 95% (no condensation)
Installation Mode1U Rack Mounting (19” width)
Power Supply MethodDual Power Input,AC: 100~240 V, 50/60 Hz, 3.5~7 A
Console Port1 × Console Port
USB Port1 × USB 2.0 Port
MGMT PortSupported
Power Consumption (Idle)Single AC: 100 W,Dual AC: 103 W
Power Consumption (Max. Load)Single AC: 350 W,Dual AC: 380 W
Surge Protection10 kV
Packing ListSwitch × 1
AC Power Cord × 1
L-Shaped Bracket Kit × 1
Console Cable × 1
Grounding Cable × 1
Cable Retention Clip × 1
Rubber Foot × 4
Quick Start Guide × 1
Regulatory Compliance and Safety Information × 1

Service Features
Flow ControlSupported
Link AggregationSupports static aggregation.
Supports dynamic aggregation via LACP.
Auto-NegotiationGigabit SFP ports 25 to 48: 1G/100M rate adaptation
10 Gigabit SFP+ ports 49 to 50: 10G/1G rate adaptation
VLANSupports 4K VLANs.
Supports port-based VLAN.
Supports IP subnet-based VLAN.
Supports QinQ.
Supports flexible QinQ.
Supports VLAN mapping.
Supports Super VLAN.
MulticastSupports IGMPv1/v2/v3 Snooping.
STPSupports STP (IEEE 802.1d).
Supports RSTP (IEEE 802.1w).
Supports MSTP (IEEE 802.1s).
ERPSSupports G.8032 ERPS.
Private Loop DetectionSupported
Storm ControlSupported
Traffic SuppressionSupported
MirroringSupports local port mirroring.
Supports N:1 port mirroring.
Supports flow mirroring.
IPv4 ServiceSupports Ping.
Supports Traceroute.
Supports DNS.
Supports ARP.
Supports ARP Proxy.
IPv4 RoutingSupports static routing.
Supports OSPFv2.
Supports RIPv1/v2.
Supports equal-cost multi-path (ECMP) routing.
Supports policy-based routing (PBR).
Supports VRRP.
IPv6 ServiceSupports Telnet6.
Supports FTP6.
Supports TFTP6.
Supports Traceroute6.
Supports Neighbor Discovery (ND).
Supports Path MTU (PMTU) Discovery.
Supports ICMPv6.
IPv6 RoutingSupports IPv6 static routing.
DHCPSupports DHCP Client.
Supports DHCP Snooping.
Supports DHCP Snooping Option 82/DHCP Relay Option 82.
Supports DHCP Relay.
Supports DHCP Server.
Cable DetectionSupports virtual cable test (VCT).
802.1X AuthenticationSupported
MAC AuthenticationSupported
RADIUSSupports RADIUS authentication.
ACLSupports L2 to L4 packet filtering.
Supports ACL definitions based on source/destination MAC address, source/destination IP address, IP protocol type, TCP/UDP port number or port range, VLAN ID, etc.
Supports Time Range-based ACLs.
Supports ACL application globally, on ports, or to VLANs.
Supports Basic ACL, Advanced ACL, and MAC ACL configurations.
Supports inbound, outbound, and VLAN-based ACLs.
QoSSupports 802.1p/DSCP priority mapping.
Supports queue scheduling mechanisms including SP, WRR, WFQ, SP+WRR, and SP+WFQ.
Supports traffic shaping.
Supports WRED.
Supports priority marking and remarking.
Supports flow-based packet filtering.
Supports flow-based traffic statistics.
Supports flow-based redirection.
Supports flow-based rate limiting.
Supports 8 queues per port.
SecuritySupports DoS attack protection.
Supports CPU protection.
Supports IP Source Guard.
Supports port isolation.
Supports HTTPS.
Supports ARP detection.
Supports ARP source suppression.
Supports ARP attack protection.
Supports IP-MAC binding.
Supports port security.
LLDPSupports LLDP.

Operation Management
Topology DisplaySupported
Status AlarmSupported
Management PlatformSupports device management via web.
Supports device management via iVMS-4200 Client.
Supports device management via Hik-Partner Pro.
Supports SADP.
Supports device management via Unified Network Management Platform.
SSHSupported
TelnetSupported
SNMPSupports SNMPv1.
Supports SNMPv2c.
Supports SNMPv3.
Clock ManagementSupports NTP.
RMONSupported
sFlowSupported
FTPSupported
TFTPSupported
DDMFiber optical ports support DDM.
LogSupports system logs.

Approval
EMCCE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020)
SafetyCB (IEC 62368-1: 2023, CE-LVD (EN 62368-1: 2024+A11: 2024)
ChemistryReach (Regulation (EC) No.1907/2006),WEEE (2012/19/EU),CE-RoHS (2011/65/EU)
