- General
- Dimension (W × H × D)170 × 156 × 42
- Storage Temperature-40℃-85℃
- Storage Humidity5%-95% non-condensing
- Installation ModeDIN rail
- Operating Temperature-40℃-75℃
- Operating Humidity5%-95% non-condensing
- Power SupplyDC：44～57VDC ( Power supply unit is not included )
- Power Consumption< 9W
- Protection GradeIP40
- Network Parameters
- Port Number8 × 10/100 Mbps RJ45 ports, and 2 × gigabit fiber optical ports
- MAC Address Table4 K
- Switching Capacity8.8 Gbps
- Packet Forwarding Rate4.2Mpps
- PoE Power Supply
- PoE StandardIEEE 802.3af, IEEE 802.3at
- PoE Power Pin1/2 (+), 3/6 (-)
- Max. Port PowerMax. 30 W for one port
- Approval
- EMIFCC 47 CFR Part 15 Class A
EN55022 Class A - EMSIEC (EN )61000‐4‐2, Class 4
IEC (EN )61000‐4‐4, Class 2
IEC (EN )61000‐4‐5, Class 2
IEC (EN )61000‐4‐11, Class 4
IEC (EN )61000‐4‐12, Class 4
