Qiymət sorğusu- Lens
- Lens Type
2.8 mm
4 mm
- Aperture
2.8 mm：F2.0
4 mm：F2.0
- Focal Length & FoV
2.8 mm, horizontal FoV: 103.7±5°, vertical FoV: 56.1±5°, diagonal FoV: 121.8±5°,
4 mm, horizontal FoV: 81.3±5°, vertical FoV: 43.9 ±5°, diagonal FoV: 97±5°
- FocusFixed
- Capture Parameters
- Image FormatJPEG
- Capture Resolution2560 x 1440 (default)2688 × 1520, 1920 × 1080, 1280 × 720
- Smart Recognitionvehicle entering/exiting parking space status, parking spacestatus detection,Intelligent Detection
- Capture Picture OverlayLane No., Capture Time, Anti-counterfeiting Code, Capture No., Vehicle Entry/Exit Direction, etc
- Image
- WDR140db
- Defogsupported
- Main Stream50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub-Stream50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
- Image SettingsSaturation, brightness, contrast, white balance, and gain are adjustable by client,software or web browser.
- Day/Night SwitchAuto/Scheduled/Manual
- WDR SwitchOn, Time, Brightness
- Frame Rate25fps
- Video
- ROI8 regions respectively for main stream and sub-stream, 6 levels for each region.
- Video CompressionH.265/H264/MJPEG
- H.264 Type
Low profile
Medium profile
High Profile
- Video Bit Rate32 Kbps to 16 Mbps
- Bit Rate TypeConstant, Variable
- Scalable Video Coding (SVC)MJPEG , H.265 and H.264 encoding
- Network
- Network StorageNAS (NFS, SMB/CIFS), auto network replenishment (ANR) together with high-end Hikvision memory card, memory card encryption and health detection are supported
- ProtocolTCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNSDDNS,RT,RTSP,RTCP,NTP,SNMP，OTAP
- APIONVIF(PROFILE S,PROFILE G), ISAPI, SDK
- ClientHikCentral,SDKdemo,DS-TPM400
- Web BrowserPlug-in required live view: IE10+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+ Local service: Chrome 41.0+, Firefox 30.0+
- SecurityOne-key restoration, password protection, watermark
- Compression Standard
- Video CompressionH.265/H.264/MJPEG
- Video Bit Rate32 Kbps to 16 Mbps
- Network Function
- Smart FunctionsBuilt-in AI deep-learning algorithm, supporting ANPR and parking space detection.
- ProtocolTCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, UPnP, SNMP, FTP, 802.1x, QoS, HTTPS (SIP, SRTP, and IPv6 optional)
- Camera
- Sensor Type 1/3″ Progressive Scan CMOS
- Max. Resolution2560 × 1440
- Min. Illumination
Color: 0.019 Lux @ (F1.9, AGC OFF)
B/W: 0.011 Lux @ (F1.9, AGC OFF)
- Day/Night SwitchSupported
- Shutter1 to 1/100,000 s
- Number of Detected Parking SpaceMax 3
- Interface
- Indicator Interface3*LED lamp interface
- Network Interface2 RJ45 10 M/100 M/1000 M self-adaptive Ethernet interface
- Smart Function
- ANPR Supported Country/Region
Middle East:
The United Arab Emirates (Abu Dhabi, Ajman, Dubai, Fujairah, Ras Al Khaimah, Sharjah and Umm Al Quwain), Qatar, Iraq, Egypt, Jordan, Kuwait, Saudi Arabia, Pakistan, Oman, Lebanon, Bahrain
Africa:
Nigeria, Kenya, Ivory Coast , South Africa, Tanzania, Mauritius, Morocco, Tunisia, Sierra Leone, Zambia, Ghana, Zimbabwe, Uganda, Angola, Ethiopia, Senegal, Algeria
Asia-Pacific:
Australia, New Zealand, Indonesia, Malaysia, Singapore, South Korea, Thailand, Vietnam, the Philippines, HongKongChina, Macao, TaiwanChina, Myanmar, India, Mongolia, Cambodia, Laos, Bangladesh, Nepal, Sri Lanka
America:
Canada, Argentina, Chile, Paraguay, Uruguay, El Salvador, Bolivia, Colombia, Brazil, Ecuador, Peru, Mexico, Panama, Costa Rica, Trinidad and Tobago, the Dominican Republic, Guatemala
Europe:
Turkey, Croatia, Slovakia, Czech Republic, Bulgaria, the Republic of North Macedonia, Hungary, Greece, Poland, France, Netherlands, Switzerland, Spain, the UK, Ireland, Germany, Italy, Austria, Israel, Palestinian, Belgium, Luxembourg, Albania, Serbia, Romania, Montenegro, Denmark, Finland, Sweden, Slovenia, Portugal, Malta, Cyprus, Iceland, Liechtenstein, Bosnia and Herzegovina
Speaking Regions:
Azerbaijan, Belarus, Kazakhstan, Lithuania, Georgia, Estonia, Latvia, Ukraine, Moldova, Uzbekistan, Kyrgyzstan, Armenia, Turkmenistan, Tajikistan
- General
- Resolution4 MP
- ConsumptionMax. 6.5 W
- Power SupplyHikvision PoE, or 12 to 24 VDC wide-range voltage
- 0.525 kg (1.1 lb.)
- Dimensions170 × 121 × 105 mm (6.7 × 4.8 × 4.2 inch)
- Weight (with Package)1 kg (2.2 lb.)
- Dimensions (with Package)275 * 205 * 175 mm(10.8 * 8.1 * 6.9 inch)
- Working Temperature and Humidity
-20 °C to 70 °C (-4 °F to 158 °F)
5% to 95% @ 40°C (non-condensing)
- Working Environment90% or less (non-condensing)
- Storage Temperature and Humidity
Temperature: -20 °C to 70 °C (- 4°F to 158 °F)
Humidity: 95% (non-condensing)
- Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
