- Cabinet
- Pixel ConfigurationSMD Triad LED
- Pixel Pitch CategoryP2.9
- Pixel Pitch2.9762 mm
- Modules Component2 × 2
- Dimensions (W × H × D)500 (W) mm × 500 (H) mm × 69 (D) mm (19.69” × 19.69” × 2.72”)
- Resolution168 × 168
- Area0.25 m²
- 7.8 kg (17.20 lb.)
- Pixel Density112896 dots/m²
- Lamp Board HousingWith housing
- Cabinet MaterialDie-casting Aluminium
- Maintenance MethodRear maintenance
- Protection LevelIP65
- Display
- White Balance Brightness4000 cd/㎡
- Color Temperature6500K adjustable
- Viewing AngleHorizontal 160°, vertical 140°
- Contrast Ratio≥ 6000:1
- Color Uniformity≤ ± 0.006Cx，Cy
- Brightness Uniformity≥ 97％
- Processing Performance
- Driving Method1/14
- Frame Frequency50/60 Hz
- Refresh Rate7680 Hz
- Grey Level16 bit
- Key Material
- Lamp EncapsulationBlack SMD1415
- Control SystemHikvision
- Power
- Power SupplyAC: 110 to 220 V ± 15%
- Max. Consumption≤730 W/m² (4000nits)
- Average Consumption≤244 W/m²
- Working Environment
- Working Temperature-20 ℃ to 45 ℃ (-4 ℉ to 113 ℉)
- Working Humidity10% RH to 90% RH (No condensation)
- Storage Humidity10% RH to 90% RH (No condensation)
- Storage Temperature-40 ℃ to 60 ℃ (-40 ℉ to 140 ℉)
- General
- Gross Weight115 kg/10 in 1 (253.53 lb.)
- Package Dimension (W × H × D)1092 (W) mm × 610 (H) mm × 580 (D) mm (42.99” × 24.02” × 22.83”)
