Qiymət sorğusu- Display
- White Balance Brightness
9000 nit (Factory preset brightness)
10000 nit (Peak)
- Color Temperature9300K adjustable
- Viewing AngleHorizontal 160°, vertical 130°
- Contrast Ratio≥ 8000:1
- Color Uniformity≤ ± 0.003Cx，Cy
- Brightness Uniformity≥ 97％
- Module
- Pixel ConfigurationSMD Triad LED
- Pixel Pitch CategoryP5.7
- Pixel Pitch5.71 mm
- Lamp Bead Dimensions2727
- Dimensions (W × H × D)960 mm × 960 mm × 100 mm (37.795” × 37.795” × 3.973”)
- Area0.9216 m²
- 27.8 Kg
- Pixel Density30625 dots/m²
- Maintenance MethodFront/Rear maintenance
- Waterproof LevelIP66
- Component MaterialAluminum Profile
- Cabinet
- Modules Component3 × 2
- Resolution168 × 168
- Processing Performance
- Driving MethodConstant current driving
- Frame Frequency50/60 Hz
- Refresh RateUp to 3840 Hz
- Grey Level14~16 bit adjustable
- Key Material
- Lamp Encapsulation2727 (gold wire)
- Control SystemHikvision
- Power
- Power Supply110~220 VAC ± 15%
- Max. Consumption≤480 W/m² （9000nits）
- Average Consumption≤160 W/m² （9000nits）
- Working Environment
- Working Temperature-40 ℃to 60 ℃(-40 ℉ to 140 ℉)
- Working Humidity10%~95%RH (No condensation)
- Storage Humidity10%~95%RH (No condensation)
- Storage Temperature-40 ℃ to 70 ℃ (-40 ℉ to 158 ℉)
- General
- Gross Weight32.35 kg /1 in 1
- Package Dimension (W × H × D)1140 (W) mm × 244 (H) mm × 1068 (D) mm
- LifespanLamp 100,000 hours
