Qiymət sorğusu- Cabinet
- Pixel ConfigurationSMD Triad LED
- Pixel Pitch CategoryP5
- Pixel Pitch5 mm
- Modules Component3 × 6
- Dimensions (W × H × D)960 mm × 960 mm × 104 mm
- Resolution192 × 192
- Area0.9216 m²
- 32.95 kg
- Pixel Density40000 dots/m²
- Lamp Board HousingWith housing
- Cabinet MaterialDiecasting Aluminium
- Maintenance MethodBack maintenance
- Cabinet Flatness0.2 mm
- Protection LevelFront IP65/Rear IPX5
- Display
- White Balance Brightness4500 nit (Factory preset brightness)
5000 nit (Peak) - Color Temperature2000K～14000K adjustable
- Viewing AngleHorizontal 160°, vertical 140°
- Contrast Ratio≥ 5000:1
- Color Uniformity≤ ± 0.003Cx，Cy
- Brightness Uniformity≥ 97％
- Processing Performance
- Driving MethodConstant current driving
- Frame Frequency50/60 Hz
- Refresh RateUp to 3840 Hz
- Grey Level13bit-15bit adjustable
- Key Material
- Control SystemDS-D42C04-H
- Power
- Power Supply110~220 VAC ± 15%
- Max. Consumption≤ 579 W/m² (4500nits)
- Average Consumption≤ 193 W/m² (4500nits)
- Working Environment
- Working Temperature-20 ℃ to 60 ℃ (-4 ℉ to 140 ℉)
- Working Humidity10%~90%RH (No condensation)
- Storage Humidity10%~90%RH (No condensation)
- Storage Temperature-20 ℃ to 60 ℃ (-4 ℉ to 140 ℉)
- General
- Gross Weight150 kg /4 in 1
- Package Dimension (W × H × D)1108mm x 703mm x 1194mm
- LifespanLamp 100,000 hours
