Qiymət sorğusu- Cabinet
- Pixel ConfigurationSMD Triad LED
- Pixel Pitch CategoryP2.5
- Pixel Pitch2.5 mm
- Modules Component2 × 2
- Dimensions (W × H × D)500 (W) mm × 500 (H) mm × 69 (D) mm (19.69” × 19.69” × 2.72”)
- Resolution200 × 200
- Area0.25 m²
- 6.8 kg (14.99 lb.)
- Pixel Density160000 dots/m²
- Lamp Board HousingWith housing
- Cabinet MaterialAluminum
- Maintenance MethodFront and Rear maintenance
- Protection LevelIP66
- Display
- White Balance Brightness4500 nit (Factory preset brightness)
5000 nit (Peak) - Color Temperature9300K adjustable
- Viewing AngleHorizontal 160°, vertical 160°
- Contrast Ratio≥ 6000:1
- Color Uniformity≤ ± 0.003Cx，Cy
- Brightness Uniformity≥ 97％
- Processing Performance
- Driving MethodConstant current driving
- Frame Frequency50/60 Hz
- Refresh Rate7680 Hz
- Grey Level14 bit
- Key Material
- Lamp Encapsulation1415
- Control SystemHikvision
- Power
- Power SupplyAC: 110 to 220 V ± 15%
- Max. Consumption≤ 510 W/㎡（AC 220V）
≤ 530 W/㎡（AC 100V） - Average Consumption≤ 170 W/㎡（AC 220V）
≤ 177 W/㎡（AC 100V）
- Working Environment
- Working Temperature-40 ℃ to 60 ℃ (-40 ℉ to 140 ℉)
- Working Humidity10% RH to 90% RH
- Storage Humidity10% RH to 95% RH
- Storage Temperature-40 ℃ to 70 ℃ (-40 ℉ to 158 ℉)
- General
- Gross Weight8.6 kg (18.96 lb.)
- Package Dimension (W × H × D)642 (W) mm × 648 (H) mm × 157 (D) mm (25.28” × 25.51” × 6.18”)
