Video konfrans üçün 2 meqapikselli PTZ kamera
Video konfrans üçün 2 meqapikselli PTZ kamera
Sorğu əsasında
Qiymət sorğusu- Camera
- Image Sensor1/2.7″ 4 MP CMOS
- Max. Resolution2560 (H) × 1440 (V)
- Min. Illumination0.1 Lux @ (F2.2, AGC ON)
- Shutter TimePAL: 1/25 s to 1/50,000s,NTSC: 1/30 s to 1/50,000 s
- Angle AdjustmentPan: 0° to 360°,Tilt: 0° to 90°,Rotate: 0°
- Zoom× 1/*× 1.2/× 1.5/× 2/*× 4
(Four-level adjustable. × 1.2 and × 4 are supported under certain frame rates.)
- Lens
- Lens TypeFixed focal lens, 2.8 mm
- Focal Length & FOVHorizontal FOV: 110°, vertical FOV: 75°, diagonal FOV: 120°
- Object Distance Range5 cm to ∞
- Microphone
- Amount2
- Polar Pattern360° Omni-directional
- Pickup DistanceIn a radius of up to 5 m
- Sensitivity-38 dBV/Pa
- SNR70 dB(A)
- Frequency Response100 kHz~20 kHz
- TypeElectret
- 3A AlgorithmANC/AGC/ALC/EQ
- Sampling Rate16 kHz
- Functions
- Image FunctionAuto White Balance, Left/Right Flip, Up/Down Flip, Center Mirror, Face AE, Auto Frame
- Audio FunctionSupports steady smart noise reduction, anti-reverberation, squeal suppression and enhanced vocals to enhance speech quality and offer audio with high quality
- LED IndicatorFlashing white: powering on and starting
Solid white: working (picking up sounds/recording videos)
Light off: standby - Auto FocusYes
- Communication
- Communication MethodUSB cable
- Wired Communication DistanceCable length: 2 m. Transmission distance: 2 m.
If the transmission distance is greater than 2 m and less than 5 m, a normal extension cable is required.
If the transmission is greater than 5 m, an extension cable with a signal amplifier is required.
- Image
- Frame RateH.264:
2560 × 1440 @30 fps/25 fps
1920 × 1080 @60 fps/50 fps/30 fps/25 fps
1280 × 960 @60 fps/50 fps/30 fps/25 fps
1280 × 720 @60 fps/50 fps/30 fps/25 fps
640 × 480 @60 fps/50 fps/30 fps/25 fps
640 × 360 @60 fps/50 fps/30 fps/25 fps
MJPG:
2560 × 1440 @30 fps/25 fps
1920 × 1080 @60 fps/50 fps/30 fps/25 fps
1280 × 960 @60 fps/50 fps/30 fps/25 fps
1280 × 720 @60 fps/50 fps/30 fps/25 fps
640 × 480 @60 fps/50 fps/30 fps/25 fps
640 × 360 @60 fps/50 fps/30 fps/25 fps
YUV2:
1920 × 1080 @5 fps
1280 × 960 @5 fps
1280 × 720 @10 fps
640 × 480 @30 fps/25 fps
640 × 360 @30 fps/25 fps
NV12:
1920 × 1080 @5 fps
1280 × 960 @5 fps
1280 × 720 @10 fps
640 × 480 @30 fps/25 fps
640 × 360 @30 fps/25 fps - Wide Dynamic Range (WDR)≥120 dB
- Interface
- CableType C-to-C interface (with type C-to-A adapter on the cable)
- Device InterfaceUSB Type C interface
- Compatibility
- System RequirementWindows XP/7/8/10/11 (resolution higher than 1080P is only available in Windows 8.1 and above version)
Android 8.1 and above version
Linux 4.14 and above version
macOS 10.12 and above version
Chrome OS
- General
- Operating Condition-10 °C to 45 °C (14 °F to 113 °F). Humidity 90% or less (non-condensing)
- MaterialMetal
- Packing ListWebcam × 1
USB 2.0 cable (2 m) × 1
Bracket × 1
Quick Start Guide × 1
QR code paper card for User Manual × 1 - Power5 VDC ± 5% (USB cable), max. 2.5 W
- Dimension120.3 mm × 49.4 mm × 44.7 mm (4.74″ × 1.94″ × 1.76″)
- Package Dimension147 mm × 107 mm × 52 mm (5.79″ × 4.21″ × 2.05″)
- Approx. 140g (0.31 lb.)
- With Package WeightApprox. 335g (0.74 lb.)
- ColorBlack
