Qiymət sorğusu- Camera
- Image Sensor
Middle camera: 1/2.7 CMOS; Left and right camera: 1/1.8″ CMOS”
- Max. Resolution
Middle camera: 2688 × 1944, Left and right camera: 2944 × 1728
- Min. Illumination
Middle camera: Color: 0.04Lux@ (F2.2，AGC ON); B/W: 0.02Lux@ (F2.2，AGC ON),
Left and right camera: Color: 0.0005Lux @ (F1.6, AGC ON); B/W: 0.0002Lux@ (F1.6，AGC ON)
- Shutter Time50 to 20000 μs
- Day & NightIR cut filter
- Lens
- Lens Type
Fixed focal lens
- Focal Length & FOV
Middle camera: 1.16 mm, horizontal FOV 164°, vertical FOV 164°, diagonal FOV 164°,
Left and right camera: 4 mm, horizontal FOV 89.2°, vertical FOV 50.9°, diagonal FOV 101.7°
- Lens MountM12
- Iris TypeFixed iris
- Aperture
Middle camera: F2.2,
Left and right camera: F1.6
- Illuminator
- Built-in Supplement Light TypeIR light,White light
- Light Bead18
- Built-in Supplement Light Range
Left and right light: Up to 20m,
Middle light: Up to 4m
- IR Wavelength850 nm
- Video
- Main Stream
Middle camera: 50Hz: 50fps(2688×1944, 1920×1088, 1280×1024, 640×480); 60Hz: 60fps(2688×1944, 1920×1088, 1280×1024, 640×480),
Left and right camera: 50Hz 25fps(2944×1728, 1920×1200, 1920×1080, 1280×720); 60Hz 30fps(2944×1728, 1920×1200, 1920×1080, 1280×720)
- Sub-Stream
Middle camera: 50Hz 50fps(1920×1088, 1280×720, 704×576, 352×288); 60Hz 60fps(1920×1088, 1280×720, 704×576, 352×288),
Left and right camera: 50Hz 25fps(1920×1080, 1280×720, 704×576, 352×288); 60Hz 30fps(1920×1080, 1280×720, 704×576, 352×288)
- Video Compression
Main stream: H.264/H.265/MJPEG,
Sub-stream: H.264/H.265/MJPEG
- Video Bit Rate32 Kbps to 8 Mbps
- H.264 TypeBaseline Profile,Main Profile,High Profile
- H.265 TypeMain Profile
- Network
- Protocols
TCP/IP,ICMP,HTTP,HTTPS,FTP,DNS,RTP,RTSP,RTCP,NTP,SNMP,802.1X,IPv4/IPv6,UDP,ISUP,ARP,IGMP,SMTP
- Simultaneous Live ViewUp to 6 channels
- APIISAPI,SDK,ISUP
- User/HostUp to 32 users,3 user levels: administrator, operator, and user
- SecurityPassword protection,HTTPS encryption,Complicated password,Control timeout settings,802.1X authentication (EAP-PEAP, EAP-LEAP, EAP-MD5)
- Network StorageLocal storage,SD card (512 GB)
- ClientHik-Central Pro
- Web BrowserChrome V61+, IE9 to IE11, Firefox V41+, Edge
- Image
- Image SettingsAGC,White balance,Gain,Sharpness,Contrast,Brightness,Saturation,Adjustable by client software or web browser.
- Day/Night SwitchDay,Night,Auto,Schedule
- Wide Dynamic Range (WDR)
Supported
- Image EnhancementBLC,HLC,3D DNR
- Interface
- Ethernet Interface
2 RJ45 10 M/100 M/1000 M self-adaptive Ethernet interface
- On-Board StorageBuilt-in memory card slot, supporting SD/SDHC/SDXC card, up to 512 GB
- Alarm 1 IO input(s)
- RS-4851 RS-485 ((half duplex, HIKVISION)
- RS-2321 RS-232
- Event
- Basic EventHDD error,Network disconnected,IP address conflict
- Road Traffic and Vehicle Detection
- Trigger ModeVideo trigger
- Smart Function
License plate recognition, Axle total number recognition, Tyre total number recognition, Axle type recognition, Floating axle recognition
- LPR Countries/Regions
Middle East: The United Arab Emirates (Abu Dhabi, Ajman, Dubai, Fujairah, Ras Al Khaimah, Sharjah and Umm Al Quwain), Qatar, Iraq, Egypt, Jordan, Kuwait, Saudi Arabia, Pakistan, Oman, Lebanon, Bahrain,
Africa: Nigeria, Kenya, Ivory Coast , South Africa, Tanzania, Mauritius, Morocco, Tunisia, Sierra Leone, Zambia, Ghana, Zimbabwe, Uganda, Angola, Ethiopia, Senegal, Algeria,
Asia-Pacific: Australia, New Zealand, Indonesia, Malaysia, Singapore, South Korea, Thailand, Vietnam, the Philippines, Hong Kong, Macao, Taiwan, Myanmar, India, Mongolia, Cambodia, Laos, Bangladesh, Nepal, Sri Lanka,
America: Canada, Argentina, Chile, Paraguay, Uruguay, El Salvador, Bolivia, Colombia, Brazil, Ecuador, Peru, Mexico, Panama, Costa Rica, Trinidad and Tobago, the Dominican Republic, Guatemala,
Europe: Turkey, Croatia, Slovakia, Czech Republic, Bulgaria, the Republic of North Macedonia, Hungary, Greece, Poland, France, Netherlands, Switzerland, Spain, the UK, Ireland, Germany, Italy, Austria, Israel, Palestinian, Belgium, Luxembourg, Albania, Kosovo, Serbia, Romania, Montenegro, Denmark, Finland, Sweden, Slovenia, Portugal, Malta, Cyprus, Iceland, Liechtenstein, Bosnia and Herzegovina,
Russian-Speaking Regions: Azerbaijan, Belarus, Kazakhstan, Lithuania, Georgia, Estonia, Latvia, Russia, Ukraine, Moldova, Uzbekistan, Kyrgyzstan, Armenia, Turkmenistan, Tajikistan
- Accuracy (Under recommended installation and lighting conditions)
Capture rate > 99%,
LPR accuracy > 98%,
Mistaken capture rate < 2%
- General
- Operating SystemLinux
- Power
AC 100 V to 240 V, 2.0 A, max. 60 W, 2-core terminal block,
- Material
SGCC
- Dimension
1839.8 mm × 503.3 mm × 282.5 mm (72.43 × 19.81″ × 11.12″) (L × W × H)”
- Package Dimension1925 mm × 410 mm × 430 mm (75.79″ × 16.14″ × 16.93″) (L × W × H)
- Weight
Approx. 22.25 kg (49.05 lb.)
- With Package Weight
Approx. 24.15 kg (53.24 lb.)
- Operating Condition
-30 °C to 70 °C (-22 °F to 158°F). Humidity: 5% to 95% (non-condensing)
- Storage Condition
-30 °C to 70 °C (-22 °F to 158°F). Humidity: 5% to 95% (non-condensing)
- HeaterNot supported
- Language8 languages: English, Thai, Croatian, Korean, Russian, Traditional Chinese, Ukrainian, Spanish
- Approval
- EMC
CE-EMC: EN 50130-4: 2011+A1: 2014, EN55032: 2015+A11: 2020+A1: 2020, EN 55035: 2017+A11: 2020, EN 61000-3-3: 2013+A1: 2019+A2: 2021, EN IEC 61000-3-2: 2019+A1: 2021+A2: 2024, EN IEC 61326-1: 2021
- Safety
CB: IEC 62368-1: 2014,CE-LVD: EN 62368-1: 2014+A11: 2017,
CB: IEC 62368-1: 2018, CE-LVD: EN 62368-1: 2020+A11: 2020
- Environment
CE-RoHS: 2011/65/EU,WEEE: 2012/19/EU,Reach: Regulation (EC) No 1907/2006
- ProtectionIP54: IEC 60529-2013
