- Video
- Video CompressionH.264,H.265
- Video Input16 CH access; up to 12MP resolution
- Network
- ProtocolsTCP/IP,UDP,IPv4/IPv6,ARP,ICMP,DHCP,802.1X,QoS,DNS,DDNS,SSL/TLS,HTTP,HTTPS,NTP,IGMP,RTP,RTSP,RTCP,FTP,SNMP,SSH2
- APIISUP,ONVIF (PROFILE S, PROFILE G, PROFILE T),ISAPI,SDK,OTAP
- SecurityPassword protection,Complicated password,HTTPS encryption,802.1X authentication (EAP-PEAP; EAP-LEAP; EAP-MD5),Watermark,Basic and digest authentication for HTTP/HTTPS,WSSE and digest authentication for ONVIF,RTP/RTSP over HTTPS,Control timeout settings,Security audit log,TLS 1.1
- User/HostUp to 127 users,3 user levels: administrator, operator, and user
- Client
Hik-Central Master,
Hik-Central Pro,
HikCentral Master Lite
- Web Browserchrome 89.0+
- Interface
- Network Interface16 x 1000 M Ethernet interface, 1 x internal 10/100/1000 M self-adaptive Ethernet interface, 1 x external 10/100/1000 M self-adaptive Ethernet interface, 1 x internal 1000 M fiber interface, 1 x external 1000 M fiber interface
- Audio Input1
- Audio Output1
- Alarm Input2
- Alarm Output2
- RS-232 Interface2 (1 internal debugging，1 external debugging）
- RS-485 Interface2
- USB1 x USB3.0(up to 5V 2A)
- Function
- Data StorageVehicle information (passing records and pictures) storage
- Video RecordingVideo recording function. Recording duration is determined by the stream size and the HDD capacity.
- Data UploadingANPR and manual uploading
- Network SettingsAble to set two-segment IP address
- System
- Operation SystemEmbedded Linux operating system
- Operating GUIWEB
- HDD Storage4 x SATA (Each SATA interface supports up to 8TB HDD.)
- Indicator4 x indicator (1 x Power Indicator, 1 x Alarm Indicator, 1 x HDD Indicator, 1 x Ready Indicator)
- General
- Weight Approx. 5.69 kg (12.54 lb.)
- With Package WeightApprox. 7.95 kg (17.53 lb.)
- Package Dimensions563 mm × 363 mm × 180 mm (22.1″ × 14.3″ × 7.1″) (L × W × H)
- Dimensions370 mm × 273 mm × 102.5 mm (14.6″ × 10.7″ × 4.03″) (L × W × H)
- Power
DC 12 V ± 10%, 6 A, max. 72 W
- Operating Condition-40 °C to 70 °C (-40 °F to 158 °F). Humidity: 10% to 90% (non-condensing)
- Storage Condition-30 °C to 70 °C (-22 °F to 158 °F). Humidity 95% or less (Non-condensing)
- Approval
- EMCCE-EMC: EN 55032: 2015+A11:2020+A1:2020, EN IEC61000-3-2: 2019+A1:2021, EN 61000-3-3: 2013+A1:2019+A2:2021, EN 50130-4: 2011+A1: 2014
- Safety
CB: IEC 62368-1:2014; CB: IEC 62368-1: 2018; CE-LVD: EN 62368-1:2014+A11:2017
- Environment
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
