- Camera
- Sensor Type1/3″ Progressive Scan CMOS
- Main Stream
50Hz：25 fps (2560 × 1440，1920 × 1080, 1280 × 720)
60Hz：30 fps (2560 × 1440，1920 × 1080, 1280 × 720)
- Max. ResolutionMax. effective resolution: 256 × 192; Encoding resolution: 1280 × 720
- Sub Stream
50Hz：25 fps (704 × 576，640 × 480, 352 × 288)
60Hz：30 fps (704 × 480，640 × 480, 352 × 240)
- Min. IlluminationColor : 0.01 Lux @（F1.6，AGC ON）
- LensHorizontal: 78.96°, Vertical: 43.17°, Diagonal: 93.31°
- Image SettingsSaturation, brightness, contrast, sharpness, AGC and white balance can be adjusted through the client or browser.
- WDRWDR
- Shutter1/25 ~ 1/100,000 s
- Image EnhancementBLC, 3D DNR
- Main Stream Video Compression StandardH.265;H.264
- Sub Stream Compression StandardH.265;H.264
- Video Bitrate256Kbps ~ 8192Kbps
- Intelligent AlarmIntrusion detection, line crossing detection, smoke and flame detection
- ProtocolTCP/IP, HTTP, HTTPS, DHCP, DNS, RTP, RTSP, RTCP, NTP, IPv4, UDP
- Interface ProtocolONVIF(PROFILE S, PROFILE G), ISAPI，EZVIZ
- GeneralAnti flicker, heartbeat, image, password protection, video occlusion
- StorageMicro SD/SDHC/SDXC card (256 G) disconnection local storage
- Exception DetectionMotion Detection, video tampering alarm, network cable disconnection, IP address conflict, invalid access, full memory, memory error
- WEB ConfigurationSupport web preview, configuration and parameter import/export
- Power Consumption＜ 10 W
- IR Range30 m
- Accessory TypeWall mounted support, pendent support, universal joint
- Detector
- Image Sensor
Vanadium Oxide (VOx) Microbolometer
Flame: 4.3um(main)+5.0um(auxiliary)+3.8um(auxiliary)
- Pixel Size12 μm
- Response Waveband8~14 μm
- Focal Length of Thermal Imaging Lens3.2 mm
- Thermal Imaging Field of View56.2° ×42.2°
- Palette ModeSupport 15 modes including white hot, black hot, fusion 1, rainbow, fusion 2, iron red 1, iron red 2, etc.
- Fire and Smoke DetectionYes
- Temperature Exception DetectionYes
- Temperature Measurement Range-20 °C ~ 400 °C
- Thermography PrecisionMax (± 8 °C, ± 8 %) , within the range of 0.4 ~ 2.5 m from the device
- Noise Equivalent Temperature Difference (NETD)≤50 mK(@25 °C,F1.0)
- Temperature Sensing ModeSupport non-contact temperature sensing
- High Temperature AlarmYes
- Alarm Indicator Light
Red: Alarm
Green: Normal
Yellow: Fault
- Interface
- Alarm Interface2 way alarm input (Alarm in), 2 way alarm output (Alarm out, support DC 30 V/2 or AC 125 V/0.5 A)
- Ethernet InterfaceRJ45 10 M/100 M adaptive Ethernet port × 1
- Audio Interface1 way audio input (Line in), 1 way audio output (Line out), 1 way built-in microphone, 1 way built-in speaker
- Professional Intelligence (Deep Learning Algorithm)
- Flame DetectionYes
- Smoke Detection Yes
- General
- Ingress ProtectionIP 66
- Mounting Height
Indoor: higher than 2.5 m
Outdoor: higher than 3.5 m
- Power Interface Type3pin industrial terminal, spacing: 3.81
- PowerDC 9V ~ DC 30V, 24W MAX; PoE: 802.3at; CLASS 4 (The power adapter is not included; you will need to configure it yourself)
- Working Temperature-20~60°C
- Working Humidity＜95% RH
- Product Implementation StandardQ/HKD 054-2024
- 1.4 kg (without packaging), 1.7 kg (with packaging)
- Dimension (L × W × H)212.5 × 130.0 × 84.8 mm
