Qiymət sorğusuImage Sensor | 1/3″ Progressive Scan CMOS |
Max. Resolution | 2688 × 1520 |
Min. Illumination | Color: 0.001 Lux @ (F1.0, AGC ON),0 Lux with light |
Shutter Time | 1/3 s to 1/100,000 s |
Day & Night | IR cut filter |
Angle Adjustment | Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360° |
Lens Type | Fixed focal lens, 2.8 and 4 mm optional |
Focal Length & FOV | 2.8 mm, horizontal FOV 100.2°, vertical FOV 54.7°, diagonal FOV 119.7°;4 mm, horizontal FOV 81.1°, vertical FOV 44.7°, diagonal FOV 94.6° |
Lens Mount | M12 |
Iris Type | Fixed |
Aperture | F1.0 |
Depth of Field | 2.8 mm: 1.9 m to ∞;4 mm: 2.5 m to ∞ |
DORI | 2.8mm: D: 63 m, O: 25 m, R: 12 m, I: 6 m;4mm: D: 78 m, O: 31 m, R: 15 m, I: 7 m |
Supplement Light Type | IR,White Light |
Supplement Light Range | Up to 60 m |
Smart Supplement Light | Yes |
IR Wavelength | 850 nm |
Open Resources | Memory: 60 MB,;Smart RAM: 400 MB,;eMMC: 2 GB |
Computing Power | 1.5 TOPS |
Open Capability | HEOP 2.0 OpendevSDK |
Deep Learning Structure | Caffe, PyTorch, TensorFlow, PaddlePaddle, ONNX |
Programming Language | C,C++ |
Main Stream | 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) ;60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) |
Sub-Stream | 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360);60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) |
Third Stream | 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360);60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360);*The third stream is supported under certain settings. |
Fourth Stream | 50 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360);60 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360);*The fourth stream is supported under certain settings. |
Video Compression | Main stream: H.265/H.264/H.264+/H.265+,;Sub-stream: H.265/H.264/MJPEG,;Third stream: H.265/H.264,;Fourth stream: H.265/H.264/MJPEG,;*The third stream and the fourth stream are supported under certain settings. |
Video Bit Rate | 32 Kbps to 8 Mbps |
H.264 Type | Baseline Profile,Main Profile,High Profile |
H.265 Type | Main Profile |
Bit Rate Control | CBR,VBR |
Scalable Video Coding (SVC) | H.264 and H.265 encoding |
Region of Interest (ROI) | 5 fixed regions for main stream and sub-stream |
Target Cropping | Yes |
Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
Audio Bit Rate | 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
Audio Sampling Rate | 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
Environment Noise Filtering | Yes |
Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SFTP, ARP, SNMP, WebSocket, WebSockets, SRTP |
Simultaneous Live View | Up to 6 channels |
API | Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP |
User/Host | Up to 32 users;3 user levels: administrator, operator, and user |
Security | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address) |
Network Storage | NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),;Together with high-end Hikvision memory card, memory card encryption and health detection are supported. |
Client | iVMS-4200,Hik-Connect,Hik-Central |
Web Browser | Plug-in required live view: IE 10, IE 11,;Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+,;Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ |
Image Parameters Switch | Yes |
Image Settings | Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser |
Day/Night Switch | Day,Night,Auto,Schedule |
Image Enhancement | BLC,HLC,3D DNR,Defog |
SNR | ≥ 52 dB |
Wide Dynamic Range (WDR) | 130 dB |
Privacy Mask | 4 programmable polygon privacy masks |
Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
On-Board Storage | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB |
Audio | 1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,;1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium |
Alarm | 2 inputs, 2 outputs (max. 24 VDC, 1 A) |
Reset Key | Yes |
Power Output | 12 VDC, max. 100 mA |
Basic Event | Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception |
Linkage | Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,trigger capture,trigger alarm output,audible warning |
Smart Event | Unattended baggage detection,object removal detection, scene change detection,audio exception detection,defocus detection |
Face Capture | Yes |
People Counting | Yes |
Perimeter Protection | Line crossing detection, intrusion detection, region entrance detection, region exiting detection,;Support alarm triggered by specified target types (human and vehicle) |
Power | 12 VDC ± 25%, 0.66 A, max. 8 W,Ø5.5 mm coaxial power plug,reverse polarity protection,;PoE: IEEE 802.3af, Class 3, max. 10 W |
Material | Front cover: Metal, body: Metal, bracket: Metal |
Dimension | 325.7 mm × 93.3 mm × 91.2 mm (12.8″ × 3.7″ × 3.6″) |
Package Dimension | 386 mm × 157 mm × 155 mm (15.2″ × 6.1″ × 6.1″) |
Weight | Approx. 1100 g (2.4 lb.) |
With Package Weight | Approx. 1610 g (3.5 lb.) |
Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
Startup and Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
General Function | Heartbeat,mirror,anti-banding,flash log,password reset via email,pixel counter |
Language | 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
EMC | ;CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,;RCM: AS/NZS CISPR 32: 2015, ;IC: ICES-003: Issue 7 |
Safety | UL: UL 62368-1,;CB: IEC 62368-1: 2014+A11,;CE-LVD: EN 62368-1: 2014/A11: 2017,;BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005,;LOA: IEC/EN 60950-1 |
Environment | CE-RoHS: 2011/65/EU |
Protection | IP67: IEC 60529-2013 |
Anti-Corrosion Protection | -Y: NEMA 4X (NEMA 250-2018) |
