Qiymət sorğusu- Camera
- Image Sensor
1/2.8″ Progressive Scan CMOS
- Max. Resolution
1920 × 1080
- Min. Illumination
Color: 0.001 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
- Shutter Time
1 s to 1/100,000 s
- Day & Night
IR cut filter
- Angle Adjustment
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
- Lens
- Lens Type
Fixed focal lens, 2.8, 4, and 6 mm optional
- Focal Length & FOV
2.8 mm, horizontal FOV 112°, vertical FOV 61°, diagonal FOV 132.4°
4 mm, horizontal FOV 91°, vertical FOV 47.8°, diagonal FOV 110.2°
6 mm, horizontal FOV 56°, vertical FOV 29.8°, diagonal FOV 65.3° - Lens Mount
M12
- Iris Type
Fixed
- Aperture
F1.6
- Depth of Field
2.8 mm: 1 m to ∞
4 mm: 1.1 m to ∞
6 mm: 2.8 m to ∞
- O2DCPVS
- DORI
2.8 mm, O: 52.8 m, O: 26.4 m, D: 13.2 m, P: 8.4m , C: 4.2m, V: 2.1m, S: 0.7m
4 mm, O: 66.9 m, O: 33.4 m, D: 16.7 m, P: 10.7m , C: 5.4m, V: 2.7m, S: 0.9m
6 mm, O: 110.3 m, O: 55.2 m, D: 27.6 m, P: 17.7m , C: 8.8m, V: 4.4m, S: 1.5m
- Illuminator
- Supplement Light Range
-2LISU model: up to 60 m
-4LISU model: up to 80 m - Supplement Light Type
IR,White Light
- Smart Supplement Light
Yes
- IR Wavelength
850 nm
- Video
- Main Stream
50 Hz:
25 fps (1920 × 1080, 1280 × 720)
60 Hz:
30 fps (1920 × 1080, 1280 × 720) - Sub-Stream
50 Hz:
25 fps (768 × 432, 640 × 360)
60 Hz:
30 fps (768 × 432, 640 × 360) - Third Stream
50 Hz:
10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz:
10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
*Third stream is supported under certain settings. - Fourth Stream
50 Hz:
10 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz:
10 fps (1280 × 720, 640 × 480, 640 × 360)
*Fourth stream is supported under certain settings. - Video Compression
Main stream: H.265/H.264/H.264+/H.265+,
Sub-stream: H.265/H.264/MJPEG,
Third stream: H.265/H.264,
Fourth stream: H.265/H.264/MJPEG,
*Third stream and fourth stream are supported under certain settings. - Video Bit Rate
32 Kbps to 8 Mbps
- H.264 Type
Baseline Profile, Main Profile, High Profile
- H.265 Type
Main Profile
- Scalable Video Coding (SVC)
H.264 and H.265 encoding
- Bit Rate Control
CBR,VBR
- Region of Interest (ROI)
5 fixed regions for main stream and sub-stream
- Target Cropping
NO
- Audio
- Audio Compression
G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
- Audio Bit Rate
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
- Audio Sampling Rate
8 kHz/16 kHz/32 kHz/48 kHz
- Environment Noise Filtering
Yes
- Network
- Protocols
HTTP,PPPoE,SFTP,HTTPS,SSL/TLS,UPnP,RTCP,WebSockets,QoS,TCP/IP,IGMP,RTP,DHCP,ICMP,FTP,WebSocket,UDP,IPv4,DNS,NTP,IPv6,802.1X,RTSP,DDNS,SNMP
- Simultaneous Live View
Up to 6 channels
- API
ONVIF (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP
- Security
Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
- User/Host
Up to 32 users
3 user levels: administrator, operator, and user - Client
iVMS-4200, Hik-Connect, Hik-Central
- Network Storage
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),
Together with high-end Hikvision memory card, memory card encryption and health detection are supported. - Web Browser
Plug-in free live view: Chrome 91+, Firefox 88+, Edge 91+, Safari 13+,
Local service: Chrome 91+, Firefox 88+, Edge 91+
- Image
- Image Parameters Switch
Yes
- Day/Night Switch
Day, Night, Auto, Schedule
- Image Settings
Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
- Wide Dynamic Range (WDR)
130 dB
- SNR
≥ 52 dB
- Image Enhancement
BLC, HLC, 3D DNR
- Privacy Mask
8 programmable polygon privacy masks
- Interface
- Ethernet Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
- On-Board Storage
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
- Alarm
1 input, 1 output (max. 24 VAC/VDC, 1A)
- Reset Key
Yes
- Audio
Built-in Microphone: Arrayed dual-microphone,1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,
1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
- Event
- Basic Event
Motion detection (support alarm triggering by specified target types (human, vehicle and animal)),video tampering alarm,exception
- Smart Event
Unattended baggage detection, object removal detection, loitering detection, people gathering detection, fast moving detection, parking detection,video quality diagnosis
- Linkage
notify surveillance center,send email,trigger recording,trigger capture
- Deep Learning Function
- Face Capture
Yes
- Perimeter Protection
Line crossing, intrusion, region entrance, region exiting
Support alarm triggering by specified target types (human, vehicle and animal)
- General
- Power
-2LI:
12 VDC ± 25%, 0.75 A, max. 9.0 W, Ø5.5 mm coaxial power plug, reverse polarity protection
PoE: IEEE 802.3af, Class 3, max. 10.5 W
-4LI:
12 VDC ± 25%, 0.95 A, max. 11.5 W, Ø5.5 mm coaxial power plug, reverse polarity protection
PoE: IEEE 802.3af, Class 3, max.12.5 W - Material
Metal
- Dimension
88.7 mm × 91.2 mm × 323.2mm (3.5″ × 3.6″× 12.7″)
- Package Dimension
386 mm × 156 mm × 155 mm (15.2″ × 6.1″ × 6.1″)
-
Approx. 1200 g (2.65 lb.)
- With Package Weight
Approx. 1770 g (3.9 lb.)
- Storage Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Startup and Operating Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Language
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- General Function
Heartbeat,mirror,flash log,password reset via email,pixel counter,anti-banding
- Approval
- EMC
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,
RCM: AS/NZS CISPR 32: 2015,
IC: ICES-003: Issue 7 - Safety
UL: UL 62368-1,
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005,
LOA: IEC/EN 60950-1 - Environment
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006 - Protection
IP67: IEC 60529-2013,IK10: IEC 62262:2002
