Qiymət sorğusu- Camera
- Image Sensor
1/3″ Progressive Scan CMOS
- Max. Resolution
2688 × 1520
- Min. Illumination
Color: 0.001 Lux @ (F1.2, AGC ON),B/W: 0 Lux with IR
- Shutter Time
1 s to 1/100,000 s
- Day & Night
IR cut filter
- Angle Adjustment
Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°
- Lens
- Lens Type
Varifocal lens, motorized lens, 2.7 to 13.5 mm
- Focal Length & FOV
2.7 to 13.5 mm, horizontal FOV 104.4° to 34°, vertical FOV 56.1° to 19.3°, diagonal FOV 124.8° to 39.2°
- Lens Mount
Ø14
- Iris Type
Auto-iris
- Aperture
Max. F1.2
- Depth of Field
1 m to ∞
- O2DCPVS
- DORI
2.7mm:O 79.3m,O 39.6m,D 19.8m,P 12.7m,C 6.3m,V 3.2m,S 1.1m;13.5mm:O 225.8m,O 112.9m,D 56.4m,P 36.1m,C 18.1m,V 9m,S 3m
- Illuminator
- Supplement Light Type
IR,White Light
- Supplement Light Range
Up to 60 m
- Smart Supplement Light
Yes
- IR Wavelength
850 nm
- Video
- Main Stream
50 Hz: 25 fps (2688 × 1520)
60 Hz: 30 fps (2688 × 1520)
50 Hz: 50 fps (1920 × 1080, 1280 × 720)
60 Hz: 60 fps (1920 × 1080, 1280 × 720) - Sub-Stream
50 Hz: 25 fps (1280 × 720, 768 × 432, 640 × 360)
60 Hz: 30 fps (1280 × 720, 768 × 432, 640 × 360) - Third Stream
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) - Fourth Stream
50 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360) - Video Compression
Main stream: H.265/H.264/H.264+/H.265+,
Sub-stream: H.265/H.264/MJPEG,
Third stream: H.265/H.264,
Fourth stream: H.265/H.264/MJPEG - Video Bit Rate
32 Kbps to 16 Mbps
- H.264 Type
Baseline Profile,Main Profile,High Profile
- H.265 Type
Main Profile
- Bit Rate Control
CBR,VBR
- Scalable Video Coding (SVC)
H.264 and H.265 encoding
- Region of Interest (ROI)
5 fixed region for every stream
- e-PTZ
NO
- AI Encoding
Yes
- Audio
- Audio Compression
G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
- Audio Type
Mono sound
- Audio Bit Rate
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
- Audio Sampling Rate
8 kHz/16 kHz/32 kHz/48 kHz
- Environment Noise Filtering
Yes
- Network
- Protocols
HTTP,ICMP,DHCP,IPv4,NTP,PPPoE,WebSockets,DDNS,IPv6,UPnP,FTP,TCP/IP,DNS,RTP,HTTPS,QoS,SNMP,SMTP,RTCP,RTSP,WebSocket,UDP,SSL/TLS,SFTP,IGMP,802.1X
- Simultaneous Live View
Up to 6 channels
- API
ISAPI,SDK,ISUP,ONVIF (Profile S, Profile T, Profile G, Profile M)
- User/Host
Up to 32 users
3 user levels: administrator, operator, and user - Security
complicated password, RTP/RTSP over HTTPS, 802.1X authentication(EAP-LEAP,EAP-TLS,EAP-MD5,EAP-PEAP), security audit log, control timeout settings, HTTPS encryption, basic and digest authentication for HTTP/HTTPS, watermark, TLS 1.2, TLS 1.3, Password protection, AES128/256, IP address filter, WSSE and digest authentication for Open Network Video Interface, host authentication (MAC address)
- Network Storage
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR)
- Client
iVMS-4200,Hik-Connect,Hik-Central
- Web Browser
Plug-in free live view: Chrome 91+, Firefox 88+, Edge 91+, Safari 13+
Local service: Chrome 91+, Firefox 88+, Edge 91+
- Image
- Image Parameters Switch
Yes
- Image Settings
Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
- Day/Night Switch
Day,Night,Auto,Schedule
- Image Enhancement
BLC, HLC, 3D DNR, Distortion Correction
- SNR
≥ 52 dB
- Wide Dynamic Range (WDR)
130 dB
- Image Stabilization
EIS
- Privacy Mask
8 rectangular privacy masks
- Interface
- Ethernet Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
- On-Board Storage
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
- Built-in Speaker
Max. power consumption: 2 W, max. sound pressure level: 10 cm: 120 dB.
- Audio
Built-in Microphone: Arrayed dual-microphone,
1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,
1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium - Alarm
2 inputs, 2 outputs (max. 24 VDC/24 VAC, 1 A)
- Reset Key
Yes
- Power Output
12 VDC, max. 100 mA
- Event
- Basic Event
Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
- Smart Event
Unattended baggage detection, object removal detection, loitering detection, people gathering detection,fast moving detection, parking detection,Scene change detection, defocus detection,Video Quality Diagnosis
- Linkage
Upload to FTP/NAS/memory card,notify surveillance center,trigger recording,trigger capture,send email,audible warning
- Deep Learning Function
- Face Capture
Detects up to 30 faces simultaneously, captures up to 5 face pictures per frame simultaneously and uploads up to 5 face pictures per second
- People Counting
NO
- Perimeter Protection
Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggering by specified target types (human, vehicle and animal))
- AcuSeek
Yes
- General
- Power
12 VDC ± 25%, 1.21 A, max. 14.5 W,reverse polarity protection,
PoE: IEEE 802.3at, Class 4, max. 18 W,2-core terminal block - Material
Front cover: Metal, body: Metal, bracket: Metal
- Dimension
Ø140 mm × 333.8 mm (Ø5.51″ × 13.14″)
- Package Dimension
435 mm × 190 mm × 180 mm (17.1″ × 7.5″ × 7.1″)
-
Approx. 1625 g (3.58 lb.)
- With Package Weight
Approx. 2735 g (6.03 lb.)
- Storage Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Startup and Operating Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- General Function
Heartbeat,mirror,flash log,password reset via email,pixel counter,anti-banding
- Language
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- Flashing Light
White/Red-Blue, configurable
- Approval
- EMC
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021
- Safety
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017 - Environment
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006 - Protection
IP67: IEC 60529-2013,IK10: IEC 62262:2002
- Anti-Corrosion Protection
NEMA 4X (NEMA 250-2018)
