Qiymət sorğusu- Camera
- Image Sensor
Channel 1: 1/3″ Progressive Scan CMOS,
Channel 2: 1/3 Progressive Scan CMOS”
- Max. Resolution
Channel 1: 2688 × 1520,
Channel 2: 2688 × 1520
- Min. Illumination
Channel 1: Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR,
Channel 2: Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
- Shutter Time1/3 s to 1/100,000 s
- Day & Night
Channel 1: IR cut filter,
Channel 2: IR cut filter
- Angle Adjustment
Channel 1: Pan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360°,
Channel 2: Pan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360°
- Lens
- Lens Type
Channel 1: Varifocal lens, motorized lens, 2.8 mm and 4 mm,
Channel 2: Varifocal lens, motorized lens, 2.8 mm and 4 mm
- Focal Length & FOV
Channel 1:
2.8 mm, horizontal FOV 99.3°, vertical FOV 52.9°, diagonal FOV 120.2°
4 mm, horizontal FOV 80.0°, vertical FOV 44.1°, diagonal FOV 94.0°
Channel 2:
2.8 mm, horizontal FOV 99.3°, vertical FOV 52.9°, diagonal FOV 120.2°
4 mm, horizontal FOV 80.0°, vertical FOV 44.1°, diagonal FOV 94.0°
- Lens MountØ14
- Iris TypeFixed
- ApertureF1.6
- Depth of Field
2.8 mm: 1.2 m to ∞
4 mm: 1.5 m to ∞
- DORI
- DORI
Channel 1:
2.8 mm, D: 66.6 m, O: 26.4 m, R: 13.3 m, I: 6.7 m
4 mm, D: 79.2 m, O: 31.4 m, R: 15.8 m, I: 7.9 m
Channel 2:
2.8 mm, D: 66.6 m, O: 26.4 m, R: 13.3 m, I: 6.7 m
4 mm, D: 79.2 m, O: 31.4 m, R: 15.8 m, I: 7.9 m
- Illuminator
- Supplement Light TypeIR,White Light
- Supplement Light Range
IR: up to 40 m
White Light: up to 40 m
- Smart Supplement LightYes
- IR Wavelength850 nm
- Video
- Main Stream
Channel 1 & Channel 2:
50 Hz:
25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz:
30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub-Stream
Channel 1 & Channel 2:
50 Hz: 25 fps (768 × 432,640 × 360)
60 Hz: 30 fps (768 × 432,640 × 360)
- Third Stream
Channel 1 & Channel 2:
50 Hz: 1 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 1 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
*Third stream is supported under certain settings.
- Video Compression
Main stream: H.265/H.264/H.264+/H.265+,
Sub-stream: H.265/H.264/MJPEG,
Third stream: H.265/H.264,
*Third stream is supported under certain settings.
- Video Bit Rate32 Kbps to 16 Mbps
- H.264 TypeBaseline Profile,Main Profile,High Profile
- H.265 TypeMain Profile
- Scalable Video Coding (SVC)H.264 and H.265 encoding
- Bit Rate ControlCBR,VBR
- Region of Interest (ROI)1 fixed region for main stream and sub-stream and third Stream
- Target CroppingYes
- Audio
- Audio Compression G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
- Audio Bit Rate64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
- Audio Sampling Rate8 kHz/16 kHz/32 kHz/48 kHz
- Environment Noise FilteringYes
- Network
- ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets
- Simultaneous Live ViewUp to 6 channels
- APIONVIF (Profile S, Profile G),ISAPI,SDK,ISUP
- SecurityPassword protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2/1.3, WSSE and digest authentication for Open Network Video Interface
- User/Host
Up to 32 users
3 user levels: administrator, operator, and user
- ClientiVMS-4200,Hik-Connect,Hik-Central
- Network Storage
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),
Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
- Web Browser
Plug-in free live view: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+,
Local service: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+
- Image
- Image Parameters SwitchYes
- Day/Night SwitchDay,Night,Auto,Schedule
- Image SettingsRotate mode
- Wide Dynamic Range (WDR)120 dB
- SNR≥ 52 dB
- Image EnhancementBLC,HLC,3D DNR
- Privacy Mask8 programmable polygon privacy masks
- Interface
- Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
- On-Board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
- Reset KeyYes
- Built-in Speaker 1 built-in speaker,Max. power consumption: 1.5 W, max. sound pressure level: 10 cm: 110 dB.
- Audio
Built-in Microphone: Arrayed dual-microphone,1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,
1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
- Alarm 2 inputs, 2 outputs (max. 24 VDC/24 VAC, 1 A)
- RS-4851 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
- Event
- Basic Event Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
- LinkageUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,audible warning,strobe light flashing
- Deep Learning Function
- Perimeter Protection
Line crossing, intrusion, region entrance, region exiting
Support alarm triggering by specified target types (human and vehicle)
- General
- Power12 VDC ± 25%, 1.42 A, max. 17 W,two-core terminal block,reverse polarity protection, PoE: IEEE 802.3at, Class 4, max. 18 W
- MaterialMetal
- Dimension199.9 mm × 120.1 mm × 97.2 mm (7.87″ × 4.73″ × 3.83″)
- Package Dimension305 mm × 162 mm × 165 mm (12.01″ × 6.38″ × 6.5″)
- Approx. 1215 g (2.7 lb.)
- With Package WeightApprox. 1582 g (3.5 lb.)
- Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Startup and Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- General FunctionHeartbeat,mirror,flash log,password reset via email,pixel counter,anti-banding
- Flashing LightWhite Light
- Approval
- EMC
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,
IC: ICES-003: Issue 7
- Safety
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017
- Environment
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
- ProtectionIP67: IEC 60529-2013
