Qiymət sorğusu- Camera
- Image Sensor
1/3″ Progressive Scan CMOS
- Max. Resolution
2688 × 1520
- Min. Illumination
Color: 0.0008 Lux @ (F1.2, AGC ON),B/W: 0 Lux with IR
- Shutter Time
1 s to 1/100,000 s
- Day & Night
IR cut filter
- Angle Adjustment
Pan: 0° to 355°,tilt: 0° to 75°,rotate: 0° to 355°
- Lens
- Lens Type
Fixed focal lens, 2.8 and 4 mm optional
- Focal Length & FOV
2.8 mm, horizontal FOV 101.3°, vertical FOV 54.6°, diagonal FOV 121.9°
4 mm, horizontal FOV 84°, vertical FOV 45.6°, diagonal FOV 98.9° - Lens Mount
M12
- Iris Type
Fixed
- Aperture
F1.2
- Depth of Field
2.8 mm: 1.7 m to ∞
4 mm: 1.6 m to ∞
- O2DCPVS
- DORI
2.8mm:O 80m,O 40m,D 20m,P 12.8m,C 6.4m,V 3.2m,S 1.1m;
4mm:O 97m,O 48.5m,D 24.3m,P 15.5m,C 7.8m,V 3.9m,S 1.3m;
- Illuminator
- Supplement Light Type
IR,White Light
- Supplement Light Range
Up to 40 m
- Smart Supplement Light
Yes
- IR Wavelength
850 nm
- Video
- Main Stream
50 Hz: 25 fps (2688 × 1520)
60 Hz: 30 fps (2688 × 1520)
50 Hz: 50 fps (1920 × 1080, 1280 × 720)
60 Hz: 60 fps (1920 × 1080, 1280 × 720) - Sub-Stream
50 Hz: 25 fps (1280 × 720, 768 × 432, 640 × 360)
60 Hz: 30 fps (1280 × 720, 768 × 432, 640 × 360) - Third Stream
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) - Fourth Stream
50 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360) - Video Compression
Main stream: H.265/H.264/H.264+/H.265+,
Sub-stream: H.265/H.264/MJPEG,
Third stream: H.265/H.264,
Fourth stream: H.265/H.264/MJPEG - Video Bit Rate
32 Kbps to 16 Mbps
- H.264 Type
Baseline Profile,Main Profile,High Profile
- H.265 Type
Main Profile
- Bit Rate Control
CBR,VBR
- Scalable Video Coding (SVC)
H.264 and H.265 encoding
- Region of Interest (ROI)
5 fixed region for every stream
- e-PTZ
NO
- AI Encoding
Yes
- Audio
- Audio Type
Mono sound
- Audio Bit Rate
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
- Audio Compression
G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
- Audio Sampling Rate
8 kHz/16 kHz/32 kHz/48 kHz
- Environment Noise Filtering
Yes
- Network
- Protocols
HTTP,ICMP,DHCP,IPv4,NTP,PPPoE,WebSockets,DDNS,IPv6,UPnP,FTP,TCP/IP,DNS,RTP,HTTPS,QoS,SNMP,SMTP,RTCP,RTSP,WebSocket,UDP,SSL/TLS,SFTP,IGMP,802.1X
- Simultaneous Live View
Up to 6 channels
- API
ISAPI,SDK,ISUP,ONVIF (Profile S, Profile T, Profile G, Profile M)
- User/Host
Up to 32 users
3 user levels: administrator, operator, and user - Security
complicated password, RTP/RTSP over HTTPS, 802.1X authentication(EAP-LEAP,EAP-TLS,EAP-MD5,EAP-PEAP), security audit log, control timeout settings, HTTPS encryption, basic and digest authentication for HTTP/HTTPS, watermark, TLS 1.2, TLS 1.3, Password protection, AES128/256, IP address filter, WSSE and digest authentication for Open Network Video Interface, host authentication (MAC address)
- Network Storage
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR)
- Client
iVMS-4200,Hik-Connect,Hik-Central
- Web Browser
Plug-in free live view: Chrome 91+, Firefox 88+, Edge 91+, Safari 13+
Local service: Chrome 91+, Firefox 88+, Edge 91+
- Image
- Image Parameters Switch
Yes
- Image Settings
Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
- Day/Night Switch
Day,Night,Auto,Schedule
- Image Enhancement
BLC, HLC, 3D DNR, Distortion Correction
- SNR
≥ 52 dB
- Wide Dynamic Range (WDR)
130 dB
- Image Stabilization
EIS
- Privacy Mask
8 rectangular privacy masks
- Interface
- Ethernet Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
- On-Board Storage
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
- Audio
Built-in Microphone: Arrayed dual-microphone,
1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,
1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium - Alarm
1 input, 1 output (max. 24 VAC/VDC, 1A)
- Reset Key
Yes
- Power Output
12 VDC, max. 100 mA
- Event
- Basic Event
Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
- Linkage
Upload to FTP/NAS/memory card,notify surveillance center,trigger recording,trigger capture,send email,audible warning
- Smart Event
Unattended baggage detection, object removal detection, loitering detection, people gathering detection,fast moving detection, parking detection,Scene change detection, defocus detection,Video Quality Diagnosis
- Deep Learning Function
- Face Capture
Detects up to 30 faces simultaneously, captures up to 5 face pictures per frame simultaneously and uploads up to 5 face pictures per second
- People Counting
NO
- Perimeter Protection
Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggering by specified target types (human, vehicle and animal))
- AcuSeek
Yes
- General
- Power
12 VDC ± 25%, 0.9 A, max. 10.8 W,Ø5.5 mm coaxial power plug,reverse polarity protection,
PoE: IEEE 802.3af, Class 3, max. 12 W - Material
Metal
- Dimension
Ø121.5 mm × 97.6 mm (Ø4.78″ × 3.84″)
- Package Dimension
150 mm × 150 mm × 141 mm (5.91″ × 5.91″ × 5.55″)
-
Approx. 630 g (1.39 lb.)
- With Package Weight
Approx. 880 g (1.94 lb.)
- Storage Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Startup and Operating Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- General Function
Heartbeat,mirror,flash log,password reset via email,pixel counter,anti-banding
- Language
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- Approval
- EMC
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021
- Safety
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017 - Environment
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006 - Protection
IP67: IEC 60529-2013,IK10: IEC 62262:2002
- Anti-Corrosion Protection
NEMA 4X (NEMA 250-2018)
- Camera
- Image Sensor
1/3″ Progressive Scan CMOS
- Max. Resolution
2688 × 1520
- Min. Illumination
Color: 0.0008 Lux @ (F1.2, AGC ON),B/W: 0 Lux with IR
- Shutter Time
1 s to 1/100,000 s
- Day & Night
IR cut filter
- Angle Adjustment
Pan: 0° to 355°,tilt: 0° to 75°,rotate: 0° to 355°
- Lens
- Lens Type
Fixed focal lens, 2.8 and 4 mm optional
- Focal Length & FOV
2.8 mm, horizontal FOV 101.3°, vertical FOV 54.6°, diagonal FOV 121.9°
4 mm, horizontal FOV 84°, vertical FOV 45.6°, diagonal FOV 98.9° - Lens Mount
M12
- Iris Type
Fixed
- Aperture
F1.2
- Depth of Field
2.8 mm: 1.7 m to ∞
4 mm: 1.6 m to ∞
- O2DCPVS
- DORI
2.8mm:O 80m,O 40m,D 20m,P 12.8m,C 6.4m,V 3.2m,S 1.1m;
4mm:O 97m,O 48.5m,D 24.3m,P 15.5m,C 7.8m,V 3.9m,S 1.3m;
- Illuminator
- Supplement Light Type
IR,White Light
- Supplement Light Range
Up to 40 m
- Smart Supplement Light
Yes
- IR Wavelength
850 nm
- Video
- Main Stream
50 Hz: 25 fps (2688 × 1520)
60 Hz: 30 fps (2688 × 1520)
50 Hz: 50 fps (1920 × 1080, 1280 × 720)
60 Hz: 60 fps (1920 × 1080, 1280 × 720) - Sub-Stream
50 Hz: 25 fps (1280 × 720, 768 × 432, 640 × 360)
60 Hz: 30 fps (1280 × 720, 768 × 432, 640 × 360) - Third Stream
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) - Fourth Stream
50 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360) - Video Compression
Main stream: H.265/H.264/H.264+/H.265+,
Sub-stream: H.265/H.264/MJPEG,
Third stream: H.265/H.264,
Fourth stream: H.265/H.264/MJPEG - Video Bit Rate
32 Kbps to 16 Mbps
- H.264 Type
Baseline Profile,Main Profile,High Profile
- H.265 Type
Main Profile
- Bit Rate Control
CBR,VBR
- Scalable Video Coding (SVC)
H.264 and H.265 encoding
- Region of Interest (ROI)
5 fixed region for every stream
- e-PTZ
NO
- AI Encoding
Yes
- Audio
- Audio Type
Mono sound
- Audio Bit Rate
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
- Audio Compression
G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
- Audio Sampling Rate
8 kHz/16 kHz/32 kHz/48 kHz
- Environment Noise Filtering
Yes
- Network
- Protocols
HTTP,ICMP,DHCP,IPv4,NTP,PPPoE,WebSockets,DDNS,IPv6,UPnP,FTP,TCP/IP,DNS,RTP,HTTPS,QoS,SNMP,SMTP,RTCP,RTSP,WebSocket,UDP,SSL/TLS,SFTP,IGMP,802.1X
- Simultaneous Live View
Up to 6 channels
- API
ISAPI,SDK,ISUP,ONVIF (Profile S, Profile T, Profile G, Profile M)
- User/Host
Up to 32 users
3 user levels: administrator, operator, and user - Security
complicated password, RTP/RTSP over HTTPS, 802.1X authentication(EAP-LEAP,EAP-TLS,EAP-MD5,EAP-PEAP), security audit log, control timeout settings, HTTPS encryption, basic and digest authentication for HTTP/HTTPS, watermark, TLS 1.2, TLS 1.3, Password protection, AES128/256, IP address filter, WSSE and digest authentication for Open Network Video Interface, host authentication (MAC address)
- Network Storage
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR)
- Client
iVMS-4200,Hik-Connect,Hik-Central
- Web Browser
Plug-in free live view: Chrome 91+, Firefox 88+, Edge 91+, Safari 13+
Local service: Chrome 91+, Firefox 88+, Edge 91+
- Image
- Image Parameters Switch
Yes
- Image Settings
Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
- Day/Night Switch
Day,Night,Auto,Schedule
- Image Enhancement
BLC, HLC, 3D DNR, Distortion Correction
- SNR
≥ 52 dB
- Wide Dynamic Range (WDR)
130 dB
- Image Stabilization
EIS
- Privacy Mask
8 rectangular privacy masks
- Interface
- Ethernet Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
- On-Board Storage
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
- Audio
Built-in Microphone: Arrayed dual-microphone,
1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,
1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium - Alarm
1 input, 1 output (max. 24 VAC/VDC, 1A)
- Reset Key
Yes
- Power Output
12 VDC, max. 100 mA
- Event
- Basic Event
Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
- Linkage
Upload to FTP/NAS/memory card,notify surveillance center,trigger recording,trigger capture,send email,audible warning
- Smart Event
Unattended baggage detection, object removal detection, loitering detection, people gathering detection,fast moving detection, parking detection,Scene change detection, defocus detection,Video Quality Diagnosis
- Deep Learning Function
- Face Capture
Detects up to 30 faces simultaneously, captures up to 5 face pictures per frame simultaneously and uploads up to 5 face pictures per second
- People Counting
NO
- Perimeter Protection
Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggering by specified target types (human, vehicle and animal))
- AcuSeek
Yes
- General
- Power
12 VDC ± 25%, 0.9 A, max. 10.8 W,Ø5.5 mm coaxial power plug,reverse polarity protection,
PoE: IEEE 802.3af, Class 3, max. 12 W - Material
Metal
- Dimension
Ø121.5 mm × 97.6 mm (Ø4.78″ × 3.84″)
- Package Dimension
150 mm × 150 mm × 141 mm (5.91″ × 5.91″ × 5.55″)
-
Approx. 630 g (1.39 lb.)
- With Package Weight
Approx. 880 g (1.94 lb.)
- Storage Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Startup and Operating Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- General Function
Heartbeat,mirror,flash log,password reset via email,pixel counter,anti-banding
- Language
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- Approval
- EMC
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021
- Safety
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017 - Environment
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006 - Protection
IP67: IEC 60529-2013,IK10: IEC 62262:2002
- Anti-Corrosion Protection
NEMA 4X (NEMA 250-2018)
