- Camera
- Image Sensor1/1.8″ Progressive Scan CMOS
- Max. Resolution3840 × 2160
- Min. Illumination
Color 0.002 Lux @ (F1.2, AGC ON), 0 Lux with Light,
B/W: 0.0002 Lux @ (F1.2, AGC ON), 0 Lux with IR
- Shutter Time1/3 s to 1/100,000 s
- Day & NightIR cut filter
- Lens
- FocusAuto,Semi-auto,Manual
- Focal Length & FOV
2.8 to 12 mm, horizontal FOV: 104° to 41.2°, vertical FOV: 54.2° to 23.1°, diagonal FOV: 126.5° to 47.3°
8 to 32 mm, horizontal FOV: 41.8° to 14.9°, vertical FOV: 22.9° to 8.5°, diagonal FOV: 48.7° to 17.1°
- Iris TypeAuto-iris
- Aperture
2.8 to 12 mm: F1.2
8 to 32 mm: F1.6
- DORI
- DORI
2.8 to 12 mm:
D: 87 to 216 m, O: 34.5 to 85.7 m, R: 17.4 to 43.2 m, I: 8.7 to 21.6 m
8 to 32 mm:
D: 218 to 580 m, O: 86.5 to 230 m, R: 43.6 to 116 m, I: 21.8 to 58 m
- Illuminator
- Supplement Light TypeIR,White Light
- Supplement Light Range
2.8 to 12 mm: IR: up to 30 m, White Light: up to 20 m
8 to 32 mm: IR: up to 50 m, White Light: up to 30 m
- Smart Supplement LightYes
- IR Wavelength850 nm
- HEOP
- Open Resources
System memory: 40 MB
Smart RAM: 350 MB
Flash: 2 GB
- Computing Power1.5 TOPS
- Deep Learning StructureCaffe,PyTorch,TensorFlow
- Programming LanguageC,C++
- Video
- Main Stream
50 Hz：20 fps（3840 × 2160，3072 × 1728，2560 × 1440，1920 × 1080，1280 × 720）
60 Hz：24 fps（3840 × 2160，3072 × 1728，2560 × 1440，1920 × 1080，1280 × 720）
- Sub-Stream
50 Hz: 20 fps (704 × 576, 640 × 480)
60 Hz: 24 fps (704 × 576, 640 × 480)
- Third Stream
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
- Video Compression
Main stream: H.265/H.264 /H.265+/H.264+
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
- Video Bit Rate32 Kbps to 16 Mbps
- H.264 TypeBaseline Profile,Main Profile,High Profile
- H.265 TypeMain Profile
- Bit Rate ControlCBR,VBR
- Scalable Video Coding (SVC)H.265 and H.264 encoding
- Region of Interest (ROI)1 fixed region for main stream and sub-stream
- Target CroppingYes
- Audio
- Environment Noise FilteringYes
- Audio Sampling Rate8 kHz/16 kHz/32 kHz/48 kHz
- Audio Compression G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC/MP3
- Audio Bit Rate64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)
- Audio TypeMono sound
- Network
- Simultaneous Live ViewUp to 6 channels
- APIOpen Network Video Interface, ISAPI, SDK, ISUP
- ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, SSL/TLS
- User/Host
Up to 32 users
3 user levels: administrator, operator, and user
- Network Storage
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),
Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
- ClientiVMS-4200, Hik-Connect, Hik-Central
- Web Browser
Plug-in required live view: IE 8+, Chrome 41.0 to 44, Firefox 30.0 to 51, Safari 8.0 to 11
Plug-in free live view: Chrome 45.0+, Firefox 52.0+
Local service: Chrome 57.0+, Firefox 52.0+
Not recommended: Safari 11+, Edge
- Image
- Image SettingsRotate mode, saturation, brightness, contrast, sharpness, white balance, AGC, adjustable by client software or web browser
- Wide Dynamic Range (WDR)120 dB
- Picture OverlayLOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.
- Day/Night SwitchDay,Night,Auto,Schedule,Alarm Trigger
- Image EnhancementBLC,HLC,3D DNR,Defog,Gray Scale
- Image Parameters SwitchYes
- SNR≥ 50 dB
- Privacy Mask8 programmable polygon privacy masks
- Interface
- Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
- On-Board Storage
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB,
*You are recommended to purchase memory card together with the product if needed. After ordering, the memory card will be installed to product during manufacturing.
- Audio1 input (line in), 1 output (line out)
- Alarm 1 input, 1 output (max. 24 VDC, 1 A/110 VAC, 500 mA)
- Reset KeyYes
- Event
- Basic Event Motion detection (support alarm triggered by specified target types (human and vehicle)), video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
- Smart Event
Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggered by specified target types (human and vehicle))
Scene change detection, audio exception detection, defocus detection, unattended baggage detection, object removal detection
- LinkageUpload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture
- General
- Power
Three-core terminal block,
DC: 12 V, 0.94 A, max. 11.24 W,
PoE: IEEE 802.3at Class 4, max. 13.37 W
- Dimension
290.8 mm × 199.67 mm × 141 mm (11.45″ × 7.86″ × 5.55″)
- Package Dimension753 mm × 313 mm × 424 mm (29.65″ × 12.32″ × 16.69″)
- Appox. 6.3 kg (13.89 lb.)
- With Package WeightAppox. 8.62 kg (19 lb.)
- Startup and Operating Conditions
Water cooling (with 20 °C (68 °F) pure water):
1. Ambient temperature 200 °C (392 °F), water flow speed 2 L/min, internal body temperature of the body 38 °C (100.4 °F)
2. Ambient temperature 250 °C (482 °F), water flow speed 2.5 L/min, internal body temperature 41 °C (105.8 °F)
Air curtain under water-cooling conditions:
1. Inlet port: G1/4
2. Installation pressure: max. 0.4 MPa
3. Recommended min. pressure: 0.2 MPa
Humidity 95% or less (non-condensing)
*It is necessary to protect the cable from heat when the ambient temperature of the cable is above 120 °C (248 °F).
- Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- Linkage MethodUpload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture
- General FunctionAnti-banding, three streams, heartbeat, mirror, flash log, password reset via email, pixel counter
- Approval
- EMC
CE-EMC (EN 55032: 2015+A11:2020+A1:2020, EN 50130-4: 2011+A1: 2014,EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3: 2013+A1:2019+A2:2021)
UKCA (EN 55032: 2015+A11:2020+A1:2020, EN 50130-4: 2011+A1: 2014,EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3: 2013+A1:2019+A2:2021)
- EnvironmentCE-RoHS (RoHS Directive 2011/65/EU+2015/863)
- ProtectionIP68 (IEC 60529-2013)
