- Camera
- Max. Resolution1600 × 1200,others: 1280 × 720, 640 × 480, 320 × 240
- Min. IlluminationColor: 0.05 Lux @ (F1.2, AGC ON)
- Shutter Time1/6 s to 100,000 s
- Lens
- Focal Length & FOV4 mm, horizontal FOV 94.2°, vertical FOV 76.9°, diagonal FOV 115.8°
- Lens TypeFixed focal lens, 4 mm
- Iris TypeFixed
- DORI
- DORID: 82.2 m, O: 32.6 m, R: 16.4 m, I: 8.2 m
- Illuminator
- Supplement Light TypeWhite Light
- Supplement Light RangeUp to 0.2 m
- Network
- APIOpen Network Video Interface, ISAPI, SDK, ISUP
- User/Host
Up to 32 users
3 user levels: administrator, operator, and user
- Network StorageNAS (NFS, SMB/CIFS),NVR
- ClientiVMS-4200,Hik-Connect,HCP
- Web Browser
Plug-in required live view: IE 10, IE 11,
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+,
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
- Wi-Fi
- Wi-Fi ProtocolIEEE802.11b,IEEE802.11g,IEEE802.11n
- Frequency Range2.4 GHz to 2.4835 GHz
- Channel Bandwidth 20/40 MHz
- Modulation
802.11b: CCK, QPSK, BPSK,
802.11g/n: OFDM
- Wireless Range
Up to 100 m
(The performance varies based on actual environment)
- Image
- Day/Night SwitchAuto
- Wide Dynamic Range (WDR)Digital WDR
- Image EnhancementBLC,3D DNR
- Interface
- Reset KeyYes,support magnetic reset
- General
- Power 3.6 VDC ± 20%, 1 A, max. 3.6 W,Built-in battery, non-rechargeable
- MaterialMain body: Plastic
- Dimension93 mm × 61.2 mm × 36 mm (3.66″ × 2.41″ × 1.42″)
- Package Dimension187 mm × 122 mm × 55 mm (7.36″ × 4.8″ × 2.17″)
- Approx. 190 g (0.419 lb.)
- With Package WeightApprox. 360 g (0.794 lb.)
- Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Startup and Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- Approval
- EMCCE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021
- Safety
CB: IEC 62368-1: 2014,
CE-LVD: EN 62368-1: 2014/A11: 2017
- Environment
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
- RFCE-RED: EN 301 489-1 V2.2.3, EN 301 489-17 V3.2.4, EN 300 328 V2.2.2, EN IEC 62311: 2020
- ProtectionIP67: IEC 60529-2013
