- Camera
- Image Sensor1/3″ Progressive Scan CMOS
- Max. Resolution2688 × 1520
- Min. IlluminationColor: 0.008 Lux @ (F2.0, AGC ON)
- Shutter Time1 s to 1/100,000 s
- Lens
- Focal Length & FOV
2.8 mm, horizontal FOV 90.5°, vertical FOV 46.2°, diagonal FOV 110°
4 mm, horizontal FOV 74°, vertical FOV 38.2°, diagonal FOV 89.5°
- Lens MountM12
- Iris TypeFixed
- Aperture
2.8 mm: F2.0
4 mm: F2.0
- Depth of Field
2.8 mm: 0.7 m to 2.1 m
4 mm: 1.0 m to 3.3 m
- DORI
- DORI
2.8 mm: D: 78.4 m, O: 31.1 m, R: 15.7 m, I: 7.8 m
4 mm: D: 94.4 m, O: 37.5 m, R: 18.9 m, I: 9.4 m
- HEOP
- Open Resources
Memory: 60 MB,
Smart RAM: 370 MB,
eMMC: 2 GB
- Video
- Main Stream
50 Hz: 25 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720)
- Sub-Stream
50 Hz: 25 fps (704 × 576, 640 × 480)
60 Hz: 30 fps (704 × 480, 640 × 480)
- Third Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
- Video Compression
Main stream: H.264/H.265/H.264+/H.265+,
Sub-stream: H.264/H.265/MJPEG,
Third stream: H.264/H.265
- H.264 TypeBaseline Profile,Main Profile,High Profile
- H.265 TypeMain Profile
- Bit Rate ControlCBR,VBR
- Scalable Video Coding (SVC)H.264 and H.265 encoding
- Region of Interest (ROI)4 fixed regions for each stream
- Audio
- Audio TypeMono sound
- Audio Compression G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
- Audio Bit Rate64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 48 Kbps (PCM)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
- Audio Sampling Rate8 kHz/16 kHz/32 kHz/48 kHz
- Environment Noise FilteringYes
- Network
- ProtocolsDNS, SNMP, 802.1X, IGMP, NTP, TCP/IP, HTTPS, SMTP, DHCP, HTTP, IPv4, FTP, DDNS, IPv6, RTCP, WebSockets, RTSP, SSL/TLS, UPnP, RTP, Bonjour, QoS, SFTP, UDP, WebSocket, ICMP
- Simultaneous Live ViewUp to 20 channels
- APIONVIF, ISAPI, SDK, ISUP
- User/Host
Up to 32 users
3 user levels: administrator, operator, and user
- Network StorageNAS (NFS, SMB/CIFS)
- ClientiVMS-4200, Hik-Connect
- SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address)
- Web Browser
Plug-in required live view: IE 10, IE 11,
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+,
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
- Image
- Image Parameters SwitchYes
- Image SettingsRotate mode,saturation,brightness,contrast,sharpness,adjustable by client software or web browser
- Day/Night SwitchDay,Night,Auto,Schedule
- Wide Dynamic Range (WDR)120 dB
- Image EnhancementBLC,HLC,3D DNR,Distortion Correction
- Privacy MaskYes
- Image StabilizationEIS
- Interface
- Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
- Reset KeyYes
- Built-in Microphone1 built-in microphone
- Event
- Basic Event Motion detection,video tampering alarm,network disconnected,IP address conflict,illegal login,HDD full,HDD error,video quality diagnosis,vibration detection
- Smart Eventscene change detection,audio exception detection,defocus detection
- LinkageUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,trigger capture
- Deep Learning Function
- Perimeter Protection
Line crossing, intrusion, region entrance, region exiting
Support alarm triggering by specified target types (human and vehicle)
Support combined event alarm triggering
- General
- Power12 VDC ± 20%, 0.19 A, max. 2.28 W, Ø5.5 mm coaxial power plug
- MaterialAluminum alloy
- Dimension50.8 mm × 48.3 mm × 30.6 mm (2.0″ × 1.9″ × 1.2″)
- Package Dimension150 mm × 110 mm × 90 mm (5.9″ × 4.3″ × 3.5″)
- Approx. 85 g (0.18 lb.)
- With Package WeightApprox. 261 g (0.57 lb.)
- Storage Conditions
-10 °C to 40 °C (14 °F to 104 °F). Humidity 95% or less (non-condensing)
*Use the heatsink to ensure heat dissipation. Refer to Quick Start Guide for the heat dissipation requirement.
- Startup and Operating Conditions
-10 °C to 40 °C (14 °F to 104 °F). Humidity 95% or less (non-condensing)
*Use the heatsink to ensure heat dissipation. Refer to Quick Start Guide for the heat dissipation requirement.
- Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- General FunctionHeartbeat,mirror,password protection,one-key reset
- Approval
- EMC
CE-EMC: EN 55032: 2015+A11:2020+A1:2020, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021, EN 50130-4: 2011+A1:2014,
RCM: AS/NZS CISPR 32: 2015,
IC: ICES-003: Issue 7
- Safety
CB: IEC 62368-1:2014,
CE-LVD: EN 62368-1:2014+A11:2017
- Environment
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
- Transport CertificationIATA Dangerous Goods Regulations, Dangerous Goods List, International Maritime Dangerous Goods Code
