Hikvision DS-2CD6D84G3-IZHS(/NFC)

4 sensors, 1/2.7″ Progressive Scan CMOS

3840 × 2160

Color: 0.002 Lux @ (F1.2, AGC ON),B/W: 0.001 Lux @ (F1.2, AGC ON),0 Lux with light

1 s to 1/100,000 s

IR cut filter

Remote adjustment (Max. 400 cycles)
Pan: 0° to 350°,tilt: 17° to 105°,rotate: -90° to 90°

Varifocal lens, motorized lens, 3 to 7.5 mm

3 to 7.5 mm, horizontal FOV 113.6° to 44.3°, vertical FOV 59.6° to 24.9°, diagonal FOV 137.8° to 50.9°

Integrated

Auto,Semi-auto,Manual

F1.79

Wide: Overview: 106 m, Outline: 53 m, Discern: 26.5 m, Perceive: 17 m, Characterize: 8.5 m, Validate: 4.2 m, Scrutinize: 1.4 m .
Tele: Overview: 247.3 m, Outline: 123.7 m, Discern: 61.8 m, Perceive: 39.6 m, Characterize: 19.8 m, Validate: 9.9 m, Scrutinize: 3.3 m .

The OODPCVS values are calculated using pixel densities for different use cases as recommended by the IEC/EN 62676-4: 2025 standard. IEC 62676-4:2025 describes the planning, design, installation, testing, commissioning, and maintaining of video surveillance systems (VSS) comprising image capture device(s), interconnection(s) and image handling device(s), for use in security applications within private or public spaces.

IR

Up to 30 m

850 nm

channel1：
50 Hz:25 fps(3840 × 2160,3072 × 1728,2560 × 1440,1920 × 1080,1280 × 720)
60 Hz:30 fps(3840 × 2160,3072 × 1728,2560 × 1440,1920 × 1080,1280 × 720)
channel2：
50 Hz:25 fps(3840 × 2160,3072 × 1728,2560 × 1440,1920 × 1080,1280 × 720)
60 Hz:30 fps(3840 × 2160,3072 × 1728,2560 × 1440,1920 × 1080,1280 × 720)
channel3：
50 Hz:25 fps(3840 × 2160,3072 × 1728,2560 × 1440,1920 × 1080,1280 × 720)
60 Hz:30 fps(3840 × 2160,3072 × 1728,2560 × 1440,1920 × 1080,1280 × 720)
channel4：
50 Hz:25 fps(3840 × 2160,3072 × 1728,2560 × 1440,1920 × 1080,1280 × 720)
60 Hz:30 fps(3840 × 2160,3072 × 1728,2560 × 1440,1920 × 1080,1280 × 720)

channel1：
50 Hz:25 fps(704 × 576,640 × 480)
60 Hz:30 fps(704 × 480,640 × 480)
channel2：
50 Hz:25 fps(704 × 576,640 × 480)
60 Hz:30 fps(704 × 480,640 × 480)
channel3：
50 Hz:25 fps(704 × 576,640 × 480)
60 Hz:30 fps(704 × 480,640 × 480)
channel4：
50 Hz:25 fps(704 × 576,640 × 480)
60 Hz:30 fps(704 × 480,640 × 480)

channel1：
50 Hz:25 fps(1920 × 1080,1280 × 720,704 × 576,640 × 480)
60 Hz:30 fps(1920 × 1080,1280 × 720,704 × 480,640 × 480)
channel2：
50 Hz:25 fps(1920 × 1080,1280 × 720,704 × 576,640 × 480)
60 Hz:30 fps(1920 × 1080,1280 × 720,704 × 480,640 × 480)
channel3：
50 Hz:25 fps(1920 × 1080,1280 × 720,704 × 576,640 × 480)
60 Hz:30 fps(1920 × 1080,1280 × 720,704 × 480,640 × 480)
channel4：
50 Hz:25 fps(1920 × 1080,1280 × 720,704 × 576,640 × 480)
60 Hz:30 fps(1920 × 1080,1280 × 720,704 × 480,640 × 480)

Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264/MJPEG,
Third stream: H.265/H.264

32 Kbps to 16 Mbps

Baseline Profile,Main Profile,High Profile

Main Profile

H.264 and H.265 encoding

4 fixed regions for each stream

Yes

G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC

16 Kbps(G.722.1)/64 Kbps (G.711ulaw/G.711alaw)/16~64 Kbps(AAC-LC)/8~320 Kbps(MP3)/16 Kbps(G.726)/32~192 Kbps(MP2L2)

8 kHz/16 kHz/32 kHz/48 kHz

Yes

IPv6,UDP,RTP,SSL/TLS,TCP/IP,ICMP,DDNS,DHCP,RTCP,DNS,IPv4,QoS,RTSP,HTTP,IGMP,802.1X,UPnP,SMTP,WebSockets,PPPoE,HTTPS,SFTP,NTP,SNMP,WebSocket,FTP

Up to 20 channels

ISAPI,EZVIZ,Open Network Video Interface,ISUP,OTAP,SDK

Up to 32 users
3 user levels: administrator, operator, and user

Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface

NAS (NFS, SMB/CIFS)

iVMS-4200,Hik-Connect

Plug-in required live view: IE 10, IE 11,
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+,
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+

sharpness,contrast,brightness,saturation,white balance,gain,adjustable by client software or web browser

Schedule,Night,Auto,Day

120 dB

≥ 52 dB

EIS

HLC,BLC,3D DNR

8 programmable polygon privacy masks

LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.

1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port

Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1 TB

1 input (line in), 3.5 mm connector, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,
1 output (line out), 3.5 mm connector, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium

2 inputs, 2 outputs (max. 24 VDC, 1 A)

1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)

Yes

/NFC: 1 FC fiber optical interface, SFP module, single mode, 20 km transmission distance, 1310 nm (TX) and 1550 nm (RX), 1250 Mbps transmission rate

Motion detection,video tampering alarm,network disconnected,IP address conflict,illegal login,HDD full,HDD error

scene change detection,defocus detection,audio exception detection

audible warning,notify surveillance center,trigger alarm output,Upload to FTP/NAS/memory card,trigger recording,send email

Line crossing, intrusion, region entrance, region exiting
Support alarm triggering by specified target types (human and vehicle)

Supports simultaneous detection and capture of human body, face, vehicle,andnon-motor vehicle,
Supports license plate recognition,
Supports counting the number of line crossing targets by type, including human body, non-motor vehicle, motor vehicle

Detects up to 120 faces simultaneously, captures up to 40 face pictures per frame simultaneously and uploads up to 10 face pictures per second

3-core terminal block,12 VDC ± 20%, 3.3 A, max. 40 W,
PoE: Hi-PoE: 42.5 VDC to 57 VDC, 1.05 A to 0.78 A, max. 45W

Ø290 mm × 147.85 mm (Ø11.42″ × 5.8″)

453 mm × 393 mm × 385 mm (17.8″ × 15.47″ × 15.16″)

Approx. 4.7 kg (10.36 lb.)

Approx. 8.0 kg (17.63 lb.)

-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing)

-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing)

33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

Heartbeat,flash log,password reset via email,pixel counter,password protection,one-key reset,anti-banding

CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021, EN 50121-4: 2016+A1:2019,
RCM: AS/NZS CISPR 32: 2015

CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005

CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006

IP67: IEC 60529-2013,IK10: IEC 62262:2002

NEMA 4X (NEMA 250-2018)
