Qiymət sorğusu- Camera
- Image Sensor
Channel 1: 1/1.8″ Progressive Scan CMOS,
Channel 2: 1/1.8 Progressive Scan CMOS”
- Max. Resolution
Channel 1: 2560 × 1440,
Channel 2: 2560 × 1440
- Min. Illumination
Channel 1:
Color: 0.0005 Lux @ (F1.2, AGC ON), 0 Lux with Light
B/W: 0.0001 Lux @ (F1.2, AGC ON), 0 Lux with IR
Channel 2:
Color: 0.0005 Lux @ (F1.2, AGC ON), 0 Lux with Light
B/W: 0.0001 Lux @ (F1.2, AGC ON), 0 Lux with IR
- Shutter Time1 s to 1/100,000 s
- Day & Night
Channel 1: IR cut filter, Blue glass module to reduce ghost phenomenon,
Channel 2: IR cut filter, Blue glass module to reduce ghost phenomenon
- Angle Adjustment
Channel 1: Pan: -10° to 190°, tilt: -5° to 25°,
Channel 2: Pan: -10° to 190°, tilt: -5° to 25°
- Lens
- Lens Type
Channel 1: Varifocal lens, 10 to 50 mm,
Channel 2: Varifocal lens, 10 to 50 mm
- Focal Length & FOV
Channel 1: 10 to 50 mm, horizontal FOV 39.2° to 8.8°, vertical FOV 21.9° to 5°, diagonal FOV 45.2° to 10.1°
Channel 2: 10 to 50 mm, horizontal FOV 39.2° to 8.8°, vertical FOV 21.9° to 5°, diagonal FOV 45.2° to 10.1°
- FocusAuto,Semi-auto,Manual
- Min. Focus Distance1.5 m
- Iris TypeDC iris
- Aperture
Channel 1: F1.6,
Channel 2: F1.6
- Depth of Field
Channel 1: 3.1 m to ∞
Channel 2: 3.1 m to ∞
- PTZ
- Movement Range (Pan)Channel 1/Channel 2: Pan: -10° to 190°
- Movement Range (Tilt)Channel 1/Channel 2: Tilt: -5° to 25°
- Pan SpeedPan speed: configurable from 0.1° to 5°/s, preset speed: 2.5°/s
- Tilt SpeedTilt speed: configurable from 0.1° to 5°/s, preset speed 2.5°/s
- DORI
- DORI
Wide: D: 150.3 m, O: 59.7 m, R: 30.1 m, I: 15 m
Tele: D: 635.9 m, O: 252.3 m, R: 127.2 m, I: 63.6 m
- Illuminator
- Supplement Light TypeIR,White Light,Hybrid (IR and White Light)
- Supplement Light RangeUp to 100 m
- Supplement Light Number10
- Smart Supplement LightYes
- IR Wavelength850 nm
- Video
- Main Stream
Channel 1 & Channel 2:
50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
- Sub-Stream
Channel 1 & Channel 2:
50 Hz: 25 fps (704 × 576, 640 × 480)
60 Hz: 30 fps (704 × 480, 640 × 480)
- Third Stream
Channel 1 & Channel 2:
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
- Video Compression
Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264/MJPEG,
Third stream: H.265/H.264
- Video Bit Rate32 Kbps to 8 Mbps
- H.264 TypeBaseline Profile,High Profile,Main Profile
- H.265 TypeMain Profile
- Bit Rate ControlCBR,VBR
- Scalable Video Coding (SVC)H.264 and H.265 encoding
- Region of Interest (ROI)4 fixed regions for each stream
- Target CroppingYes
- Audio
- Audio TypeMono sound
- Audio Compression G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
- Audio Bit Rate64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 48 Kbps (PCM)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
- Audio Sampling Rate8 kHz/16 kHz/32 kHz/48 kHz
- Environment Noise FilteringYes
- Network
- ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, ISUP, ARP, WebSocket, WebSockets
- Simultaneous Live ViewUp to 20 channels
- APIONVIF (Profile S, Profile G, Profile T, Profile M),ISAPI,SDK,ISUP
- User/Host
Up to 32 users
3 user levels: administrator, operator, and user
- SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2, TLS 1.3, TPM 2.0 (FIPS 140-2 level 2), AES128/256
- Network Storage
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),CVR,NVR,
Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
- ClientiVMS-4200,Hik-Connect
- Web Browser
Plug-in required live view: IE 10, IE 11,
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 13+,
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
- Image
- Image Parameters SwitchYes
- Image SettingsRotate mode,saturation,brightness,contrast,sharpness,gain,white balance,AGC,adjustable by client software or web browser
- Day/Night SwitchDay,Night,Auto,Schedule,Alarm Trigger
- Wide Dynamic Range (WDR)150 dB
- Image EnhancementBLC,HLC,3D DNR,Distortion Correction
- Privacy Mask8 programmable polygon privacy masks
- Picture OverlayLOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.
- Satellite Positioning
- Satellite Positioning DetectionGPS
- Interface
- Ethernet Interface1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port
- On-Board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
- Built-in MicrophoneYes, 2 built-in microphones
- Built-in SpeakerYes, 1 built-in speaker,Max. power consumption: 3 W, max. sound pressure level: 10 cm: 95 dB.
- Audio2 inputs (line in), 1 output (line out), 3.5 mm connector, 2 channels
- Alarm 3 inputs, 2 outputs (max. 24 VDC/24 VAC, 1 A)
- RS-4851 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
- Reset KeyYes
- Power Output12 VDC, max. 100 mA
- Event
- Basic Event Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error, abnormal restart),alarm input and output,video quality diagnosis,vibration detection
- Smart EventUnattended baggage detection, object removal detection,scene change detection,audio exception detection,defocus detection
- LinkageUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,audible warning,white light flashing
- Deep Learning Function
- Perimeter Protection
Line crossing, intrusion, region entrance, region exiting
Support alarm triggering by specified target types (human and vehicle)
- Multi-target-type Detection
Detects up to 30 targets simultaneously,Supports simultaneous detection and capture of human body, face and vehicle,
Gets 7 face features,
Gets 13 human body features,
Gets 2 vehicle features
- Face Capture
Detects up to 120 faces simultaneously,
Supports swing left and right from -60° to 60°, tilt up and down from -30° to 30°,
Uploads face with background and closed-up face pictures
- Face Comparison
Up to 10 face libraries. 30,000 faces for each library. 150,000 faces in total,
Supports face library encryption,
Only channel 1 supports
- Queue Management
Supports up to 8 detection regions, and independent arming schedule and linkage method
Supports 2 detection modes: regional people queuing-up, waiting time detection
Generates reports to compare the efficiency of different queuing-ups and display the changing status of one queue
Supports raw data export for further analysis
Supports real-time data uploading and scheduled data uploading
Regional people queuing-up: supports 4 alarm trigger conditions, including greater than threshold, less than threshold, equal to threshold, not equal to threshold
Waiting time detection: supports 1 alarm trigger condition, including greater than threshold
- Heat Map
A graphic description of visits (by calculating amount of people or amount of dwell time) in a configured area.,
Two report types are available, space heat map and time heat map line chart.
- MetadataIntrusion detection,line crossing detection,region entrance detection,region exiting detection,face capture,multi-target-type detection,road traffic
- Road Traffic and Vehicle Detection
Smart Function:
Support license plate recognition of vehicles and motorcycles (only in checkpoint scenario)
Support vehicle attribute detection, including vehicle type, color, brand, driving direction, etc.
Support vehicle and non-vehicle counting
Blocklist and allowlist: up to 10,000 records
LPR Countries/Regions:
4 areas (Europe, Middle East, Asia-Pacific, Africa) and more than 124 countries/regions
Accuracy (Under recommended installation and lighting conditions):
License plate recognition rate ≥98%
Capture rate ≥99%
Driving direction accuracy rate ≥98%
Vehicle Capture Speed:
Front installation in checkpoint scenario: up to 80 km/h
Side installation: up to 60 km/h
Capture Mode: License Plate and Vehicle Mode, Vehicle Priority Mode
- Regional People Counting
Supports up to 8 detection regions, and independent arming schedule and linkage method
Supports 3 detection modes: people density detection, number of people exception detection, waiting time exception detection
Supports parameter settings: alarm times per exception, alarm interval, first alarm delay
Supports searching real-time number of people
People density detection: supports scheduled uploading, number of people change uploading, congestion level uploading
Number of people exception detection: supports 6 alarm trigger conditions, including greater than threshold A, less than threshold A, equal to threshold A, not equal to threshold A, greater than threshold A and less than threshold B, less than threshold A or greater than threshold B (threshold A should be less than threshold B)
Waiting time exception detection: supports 3 alarm trigger conditions, including greater than threshold A, less than threshold A, greater than threshold A and less than threshold B (threshold A should be less than threshold B)
- On/Off Duty Detection
Supports up to 8 detection regions, and independent arming schedule and linkage method
Supports 2 detection modes: absence detection, on/off duty detection
Supports parameter settings: person on duty, absence duration
- General
- Power36 VDC ± 20%, 1.56 A, max. 56.12 W,two-core terminal block
- MaterialPlastics and metal
- Dimension382.3 mm × 193.6 mm × 201.5 mm (15.1″ × 7.6″ × 7.9″)
- Package Dimension490 mm × 280 mm × 343 mm (19.3″ × 11″ × 13.5″)
- Approx. 4795 g (10.6 lb.)
- With Package WeightApprox. 6760 g (14.9 lb.)
- Storage Conditions-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing)
- Startup and Operating Conditions-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing)
- Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- General FunctionHeartbeat,mirror,flash log,password reset via email,pixel counter,password protection,one-key reset,anti-banding
- HeaterYes
- WiperYes
- DemistYes
- Flashing LightWhite Light
- Approval
- EMC
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,
RCM: AS/NZS CISPR 32: 2015,
IC: ICES-003: Issue 7,
KC: KN32: 2015, KN35: 2015
- Safety
CE-LVD: EN 62368-1: 2014/A11: 2017,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005,
LOA: IEC/EN 60950-1
- Environment
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
- ProtectionIP67: IEC 60529-2013
- Anti-Corrosion Protection-Y: NEMA 4X (NEMA 250-2018)
- OtherPVC FREE
