Qiymət sorğusuImage Sensor | 1/1.8″ Progressive Scan CMOS |
Max. Resolution | 2688 × 1520 |
Min. Illumination | Color: 0.0005 Lux @ (F1.2, AGC ON);;B/W: 0.0001 Lux @ (F1.2, AGC ON), 0 Lux with IR |
Shutter Time | 1 s to 1/100,000 s |
Day & Night | IR cut filter;Blue glass module to reduce ghost phenomenon |
Focal Length & FOV | 2.8 to 12 mm, horizontal FOV: 114.5° to 41.8°, vertical FOV: 59.3° to 23.6°, diagonal FOV: 141.1° to 48°;8 to 32 mm, horizontal FOV: 42.5° to 15.1°, vertical FOV: 23.3° to 8.64°, diagonal FOV: 49.6° to 17.3° |
Focus | Auto,Semi-auto,Manual |
Iris Type | P-iris |
Aperture | 2.8 to 12 mm: F1.2 to F2.5;8 to 32 mm: F1.7 to F1.73 |
DORI | Wide:;2.8 to 12 mm: D (Detect): 60 m, O (Observe): 23.8 m, R (Recognize): 12 m, I (Identify): 6 m;8 to 32 mm: D (Detect): 150.3 m, O (Observe): 59.7 m, R (Recognize): 30.1 m, I (Identify): 15 m;Tele:;2.8 to 12 mm: D (Detect): 149 m, O (Observe): 59.1 m, R (Recognize): 29.8 m, I (Identify): 14.9 m;8 to 32 mm: D (Detect): 400 m, O (Observe): 158.7 m, R (Recognize): 80 m, I (Identify): 40 m |
Supplement Light Type | IR |
Supplement Light Range | 2.8 to 12 mm: 50 m;8 to 32 mm: 100 m |
Smart Supplement Light | Yes |
IR Wavelength | 850 nm |
Main Stream | 50 Hz:;25 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720);50 fps (2560 × 1440, 1920 × 1080, 1280 × 720);60 Hz:;30 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720) ;60 fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
Sub-Stream | 50 Hz: 25 fps (704 × 576, 640 × 480);60 Hz: 30 fps (704 × 480, 640 × 480) |
Third Stream | 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480);60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) |
Fourth Stream | 50 Hz: 25 fps (704 × 576, 640 × 480);60 Hz: 30 fps (704 × 480, 640 × 480) |
Fifth Stream | 50 Hz: 25 fps (704 × 576, 640 × 480);60 Hz: 30 fps (704 × 480, 640 × 480) |
Video Compression | Main stream: H.265+/H.265/H.264+/H.264,;Sub-stream: H.265/H.264/MJPEG,;Third stream: H.265/H.264,;Fourth stream: H.265/H.264/MJPEG,;Fifth stream: H.265/H.264/MJPEG |
Video Bit Rate | 32 Kbps to 8 Mbps |
H.264 Type | Baseline Profile,Main Profile,High Profile |
H.265 Type | Main Profile |
Bit Rate Control | CBR,VBR |
Scalable Video Coding (SVC) | H.264 and H.265 encoding |
Region of Interest (ROI) | 4 fixed regions for each stream |
Target Cropping | Yes |
e-PTZ | Support Patrol and Auto Tracking settings |
Audio Type | Mono sound |
Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
Audio Bit Rate | 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
Audio Sampling Rate | 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
Environment Noise Filtering | Yes |
Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets |
Simultaneous Live View | Up to 20 channels |
API | Open Network Video Interface (Profile S, Profile G, Profile T, Profile M),ISAPI,SDK,ISUP |
User/Host | Up to 32 users;3 user levels: administrator, operator, and user |
Security | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2, TLS 1.3, TPM 2.0 (FIPS 140-2 level 2), AES128/256 |
Network Storage | NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),;Together with high-end Hikvision memory card, memory card encryption and health detection are supported. |
Client | iVMS-4200,Hik-Connect,Hik-Central |
Web Browser | Plug-in required live view: IE 10, IE 11,;Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+,;Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ |
Image Parameters Switch | Yes |
Image Settings | Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser |
Day/Night Switch | Day,Night,Auto,Schedule,Alarm Trigger,Video Trigger |
Wide Dynamic Range (WDR) | 140 dB |
SNR | ≥ 52 dB |
Image Enhancement | BLC,HLC,3D DNR,Distortion Correction,Defog |
Picture Overlay | LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format. |
Image Stabilization | EIS |
Privacy Mask | 8 programmable polygon privacy masks |
Video Output | 1 Vp-p Composite Output (75 Ω/CVBS) (Only for debugging) |
Ethernet Interface | 1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port |
On-Board Storage | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1 TB |
Audio | With -Y: 1 input (line in), 1 output (line out), 3.5 mm connector |
Alarm | 2 inputs, 2 outputs (max. 24 VDC, 1 A) |
RS-485 | With -Y: 1 RS-485 (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) |
Reset Key | Yes |
Power Output | With -Y: 12 VDC, max. 100 mA |
Wiegand | -Y: 1 Wiegand (CardID 26bit, SHA-1 26bit, Hik 34bit, NEWG 72bit) |
Basic Event | Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception (network disconnected, IP address conflict, illegal login, abnormal restart, HDD full, HDD error),video quality diagnosis,vibration detection |
Smart Event | scene change detection,audio exception detection,defocus detection |
Linkage | Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,audible warning |
Perimeter Protection | Line crossing, intrusion, region entrance, region exiting;Support alarm triggering by specified target types (human and vehicle);Support combined event alarm triggering |
Road Traffic and Vehicle Detection | Smart Function:;Support license plate recognition of vehicles and motorcycles (only in checkpoint scenario);Support vehicle attribute detection, including vehicle type, color, brand, driving direction, etc.;Support vehicle and non-vehicle counting;Blocklist and allowlist: up to 10,000 records;LPR Countries/Regions:;4 areas (Europe, Middle East, Asia-Pacific, Africa) and more than 124 countries/regions;Accuracy (Under recommended installation and lighting conditions):;License plate recognition rate ≥98%;Capture rate ≥99%;Driving direction accuracy rate ≥98%;Vehicle Capture Speed:;Front installation in checkpoint scenario: up to 120 km/h;Side installation: up to 80 km/h;Capture Mode: License Plate and Vehicle Mode, Vehicle Priority Mode |
Metadata | Intrusion detection,line crossing detection,region entrance detection,region exiting detection,road traffic |
Parking Management | Support distant view mode and close view mode ;Distant view mode: support status detection on up to 40 parking spaces, parking duration detection, and vacant parking space alarm ;Close view mode: support status detection on up to 4 parking spaces, license plate recognition, parking timeout alarm, and vacant parking space alarm |
Power | 12 VDC ± 20%, 1.19 A, max. 14.28 W, three-core terminal block,;PoE: IEEE 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.396 A to 0. 295 A, max. 16.8 W |
Material | Aluminum alloy body |
Dimension | Without -Y: Ø144 mm × 347 mm (Ø5.7″ × 13.7″);With -Y: Ø140 mm × 351 mm (Ø5.5 × 13.8″”)”” |
Package Dimension | 405 mm × 190 mm × 180 mm (15.9″” × 7.5″” × 7.1″”) |
Weight | Approx. 1950 g (4.2 lb.) |
With Package Weight | Approx. 3070 g (6.7 lb.) |
Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
Startup and Operating Conditions | -40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing) |
Language | 33 languages: English |
