Qiymət sorğusu- Camera
- Image Sensor1.61ʺ Progressive Scan CMOS
- Max. Resolution6816 × 3840
- Min. Illumination
Color: 0.001 Lux @ (F1.2, AGC ON)
Black: 0.0005 Lux @ (F1.2, AGC ON), 0 Lux with IR
- Shutter Time1/25 s to 1/100,000 s
- Day & NightIR cut filter. Blue glass module to reduce ghost phenomenon.
- Lens
- Lens TypeC/CS
- Focal Length & FOV
50 mm, horizontal FOV 22.4°, vertical FOV 12.7°, diagonal FOV 25.7°
85 mm, horizontal FOV 13.3°, vertical FOV 7.5°, diagonal FOV 15.4°
- ApertureMax. F2.0
- DORI
- DORI
85 mm: D (Detect) : 1172.4 m, O (Observe) : 465.2 m, R (Recognize) : 234.5 m, I (Identify) : 117.2 m;
50 mm: D (Detect) : 689.7 m, O (Observe) : 273.7 m, R (Recognize) : 137.9 m, I (Identify) : 69 m
- Illuminator
- Supplement Light TypeIR
- Supplement Light RangeUp to 100 m
- IR Wavelength850 nm
- Video
- Main Stream
1 encoder track mode:
H.264/H.265:
50 Hz: 25 fps (6816 × 3840, 6048 × 4008, 5472 × 3648, 4944 × 3280, 4608 × 2592, 3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (6816 × 3840, 6048 × 4008, 5472 × 3648, 4944 × 3280, 4608 × 2592, 3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720)
3 encoder tracks mode:
H.264/H.265:
50 Hz: 25 fps (6816 × 3840, 6048 × 4008, 5472 × 3648, 4944 × 3280, 4608 × 2592)
60 Hz: 30 fps (6816 × 3840, 6048 × 4008, 5472 × 3648, 4944 × 3280, 4608 × 2592)
- Sub-Stream
1 encoder track mode:
H.264/H.265/MJPEG:
50 Hz: 25 fps (704 × 480, 640 × 480)
60 Hz: 30 fps (704 × 480, 640 × 480)
3 encoder tracks mode: No
- Third Stream
1 encoder track mode:
H.264/H.265:
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
3 encoder tracks mode: No
- Fourth Stream
1 encoder track mode:
H.264/H.265/MJPEG:
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
3 encoder tracks mode: No
- Fifth Stream
1 encoder track mode:
H.264/H.265/MJPEG:
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
3 encoder tracks mode: No
- Video Compression
Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
Fourth stream: H.265/H.264/MJPEG
Fifth stream: H.265/H.264/MJPEG
- Video Bit Rate32 Kbps to 32 Mbps
- H.264 TypeBaseline Profile,Main Profile,High Profile
- H.265 TypeMain Profile
- Scalable Video Coding (SVC)Yes
- Region of Interest (ROI)4 fixed regions for each stream
- Target CroppingYes
- Audio
- Environment Noise FilteringYes
- Audio Sampling Rate8 kHz/16 kHz/32 kHz/48 kHz
- Audio Compression
G.722.1/MP2L2/G.726/G.711/MP3/PCM/AAC-LC
- Audio Bit Rate64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/PCM/16 to 64 Kbps (AAC-LC)
- Audio TypeMono sound
- Network
- Simultaneous Live ViewUp to 20 channels
- APIONVIF (Profile S, Profile G),ISAPI,SDK,ISUP
- ProtocolsSSL/TLS,IGMP,UPnP,WebSocket,SNMP,IPv4,DNS,Bonjour,UDP,WebSockets,RTSP,RTCP,DDNS,NTP,RTP,HTTP,ICMP,PPPoE,802.1X,DHCP,QoS,FTP,SMTP,HTTPS,SFTP,IPv6,TCP/IP
- User/HostUp to 32 users. 3 user levels: administrator, operator and user
- SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2, TLS 1.3, TPM 2.0 (FIPS 140-2 level 2), AES128/256
- Network StorageNAS (NFS, SMB/CIFS)
- ClientiVMS-4200,HikCentral Professional
- Web Browser
Plug-in required live view: IE 10, IE 11
Plug-in free live view:Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
- Image
- Wide Dynamic Range (WDR)Digital WDR
- Picture OverlayLOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.
- Day/Night SwitchNight,Alarm Trigger,Day,Schedule,Auto
- Image Enhancement
HLC,3D DNR,EIS,BLC
- Image Settings
contrast,saturation,white balance,brightness,gain,sharpness
- Satellite Positioning
- Satellite Positioning DetectionGPS
- Interface
- Alarm 3 inputs, 3 outputs (max. 24 VDC/VAC, 1 A)
- Audio
1 inputs (line in), 3.5 mm connector, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium;
1 output (line out), 3.5 mm connector, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium;
- On-Board Storage
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1 TB
- Video Output1 Vp-p composite output (75 Ω/CVBS), only for adjustment
- Reset KeyYes
- Ethernet Interface1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port
- Power Output12 VDC, max. 100 mA
- Fiber Optical1 fiber optical interface, SFP module, single mode, 20 km transmission distance, 1310 nm (TX) and 1550 nm (RX), 1250 Mbps transmission rate
- Event
- LinkageUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording
- Deep Learning Function
- People Density
Supports up to 8 detection regions, and independent arming schedule and linkage method
People density detection: supports setting density levels based on the number of people and target pixel ratio
Supports scheduled data uploading
- General
- Power24 VAC ± 20%, 2.28 A, max. 37.4 W
- Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- General FunctionOne-key reset, anti-flicker, heartbeat, mirror, password protection, pixel counter
- Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing)
- Startup and Operating Conditions-40 °C to 60 °C (-40 °F to 140 °F), humidity 95% or less (non-condensing)
- MaterialMetal
- Dimension569 mm × 171.5 mm × 165.8 mm (22.4″ × 6.75″ × 6.53″)
- Package Dimension668 mm × 408 mm × 289 mm (26.3″ × 16.06″ × 11.38″)
- Approx. 5.08 kg (11.2 lb.)
- With Package WeightApprox. 7.9 kg (17.42 lb.)
- Approval
- EMC
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021
RCM: AS/NZS CISPR 32: 2015,
- Safety
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
LOA: IEC/EN 60950-1
- Environment
CE-ROHS (2011/65/EU);
REACH (Regulation (EC) No 1907/2006);
WEEE (2012/19/EU);
- ProtectionIP66: IEC 60529-2013
- Anti-Corrosion ProtectionNEMA 4X (NEMA 250-2018)
