- Operating SystemARM FAROS
- AIOP
- AIOP Picture Analysis Performance1. AIOP Image Performance — Small Models:
1. Detection and Classification Mixed:
a) ≤5 MP: 16 images/s/KT4 chip;
b) >5 MP to 8 MP: 9 images/s/KT4;
2. Multi-attribute Classification:
a) ≤5 MP: 16 images/s/KT4 chip;
b) >5 MP to 8 MP: 12 images/s/KT4;
3. Dual Detection:
a) ≤5 MP: 16 images/s/KT4 chip;
b) >5 MP to 8 MP: 13 images/s/KT4;2. AIOP Image Performance — Large Models:
1. Mixed Large Model: 2 MP–8 MP, 16 targets, 1 image/s/KT4 chip;
2. Dual Detection Large Model: 2 MP–8 MP, 4 targets, 0.6 image/s/KT4 chip.System Total Performance: 54 imgs/s
- AIOP Video Analysis PerformancePerformance Specifications (2MP – 5MP):
Deteciton and classification Mixed: (1 detection + 1 classification): 40 channels of video analysis per device;
Object Detection Mode: 40 channels of video analysis per device;
Single-label Classification Mode: 40 channels of video analysis per device;
Multi-attribute Classification Mode: 40 channels of video analysis per device;
Performance Specifications (>5MP – 8MP):
Deteciton and classification Mixed:(1 detection + 1 classification): 30 channels of video analysis per device;
Object Detection Mode: 30 channels of video analysis per device;
Single-label Classification Mode: 30 channels of video analysis per device;
Multi-attribute Classification Mode: 30 channels of video analysis per device; - Number of AI Models64
- Scheduled Capture Analysis Performance80-channel schedule snapshot.
- Product Performance
- Algorithm TypeEvent detecting algorithms includes:
(1) Indoor Event:
Supports real-time detection for events such as climbing, working status (absence, sleeping), overtime loitering, sudden spikes in sound intensity, abnormal headcount, physical conflicts , standing detection, regional headcount, Using mobile phone, uniform compliance, falling down, and people counting.
(2) Perimeter Protection:
Provides real-time detection and alerts for line crossing, area intrusion, entering/exiting specific zones, and loitering.
(3) Street Event:
Supports real-time detection for running, physical conflicts, people gathering, and persons falling down.
(4) Trend Event:
Supports real-time detection for People Density Analysis,regional people counting,People Counting.
(5) Multimodal Capabilities
Supports multimodal secondary recognition for scenarios like sleeping with head covered, hands under blankets, and pointing/gesturing.
(6) AI Open Platform Algorithms
Delivers real-time detection and alerts for events based on detection, dual-detection, classification, and hybrid algorithms trained on the open platform. - Event Data Storage Capacity4 TB, Event Image Storage (including AIOP event alarm and behavior capture images): 200,000 images (full coverage).Calculated based on the camera resolution and event image size.
- Analysis Format
- Picture Resolution32 × 32 to 4096 × 4096 Picture format: JPEG (JPG), TIF, BMP, PNG, gif (static); Picture size: no more than 10 MB.
- Video Frame RateH.264 video stream、H.265 video stream (HIKVISION),Resolution: 2 MP-8 MP(4096 × 2160);
Frame rate: 12/s to 30/s;
- Hardware Specifications
- CPU8 cores
- GPU2 GPU cards (6 chips), with 141 TOPS INT8 computing power and 48GB RAM per card.
- Memory8 GB DDR4 × 2
- HDD4 TB SATA pre-installed.
- Network InterfaceRJ45 10/100/1000Mbps Ethernet ports x4
- HDD InterfaceSupports up to 12 x 3.5-inch SATA HDDs
- Auxiliary Interface
- Serial Interface 1 RS-232, 2 RS-485 (half-duplex)
- Alarm In/Out8/4
- USB Interface2 × USB 2.0 (Front Panel) + 4 × USB 3.0 (Rear Panel)
- VGA1
- HDMI1
- Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KΩ)
- ButtonPower Button (front, integrated LED), UID Button (front, integrated LED), Reset Button (rear)
- LED IndicatorsPower (front, integrated with power button), Status, LAN, Alarm, HDD
- General
- Power SupplyAC 100V~240V，800W(1+1)
- Consumption≤700W (without HDD)
- Working Temperature-10℃～＋35℃
- Working Humidity10%~90%RH
- Chassis2U
- Dimension (W × D × H)448mm(W) x 470mm(D) x 87.1mm(H)
- 20.410kg (With Package)
- Package Dimension655mm(W) x 595mm(D) x 260mm(H)
