8 kanallı 1U, 8 PoE, 8K DeepinMind NVR
8 kanallı 1U, 8 PoE, 8K DeepinMind NVR
Sorğu əsasında
Qiymət sorğusu- AI Open Platform Performance
- Engine3 * KT5，2 for small model analysis as default , 1 for lager model algorithm secondary analysis,1 engine can support 4 algorithm models at the same time
- Live Video Analysis1 engine can support up to 8ch,(8ch@4MP，4ch @8MP)
- Auto-Switch Video Analysis1 engine can support up to 16ch,(switch time between 10 to 3600 seconds)
- Scheduled Capture Analysis1 engine can support up to 16ch, (switch time between 3 to 3600 seconds)
- Offline Picture Analysis4 images per GPU per second or 1 image per GPU per second ( Large model)
- Human
- Facial recognitionFace Capture/Face Picture Comparison(32 face libraries, 100, 000 pictures)
- Personnel ComplianceHard Hat/Reflective Cloth/Skin Exposure/Goggles/Smoking/Phone Call/Using Phone/Sleeping (Face down)/Sleeping (Reclining)/Absence/Seatbelt/Person Overstay/Person Loitering
- Workwear Registration and ComparisonWork uniform/Work hat
- People CountingRegional people counting/People counting statistics
- Street BehaviourViolent/Fall Down/Running/Gathering
- Vehicle
- Vehicle RecognitionExcavator/Bulldozer/Dump Truck/Concrete Pump Truck/Crane/Cement Tanker/Tower Crane/Truck/Oil Tank Truck/Electric Moped/Bicycle/Coach/Small Sized Vehicle/Forklift/Tricycle
- Environment
- Smoke and FireSmoke/Fire
- Perimeter ProtectionIntrusion detection/Line crossing detection/Region entrance detection/Region exiting detection
- Fire Escape Occupation DetectionFire_Escape_Occupation_Detection
- Object
- Object DetectionFire_Extinguisher/ Oxygen_Cylinder/ Acetylene_Cylinder/ Gas_Cylinder/ Fire_Extinguisher_Box/Fire_Blanket/ Banner/ Dustbin/Traffic_Cone
- AIOP
- AI Open Platform AlgorithmDetection model, Classification model, Mixed model (Detection model and
Classification model), Double detection model
- RAID
- RAID TypeRAID0, RAID1, RAID5, RAID6, RAID10
- Video and Audio
- IP Video Input32-ch
- Incoming Bandwidth320 Mbps
- Outgoing Bandwidth256 Mbps
- Video Output ModeHDMI1/VGA1 simultaneous output, HDMI2/VGA2 simultaneous output
- HDMI OutputHDMI1：8K (7680 × 4320)/30 Hz, 4K (3840 × 2160)/60 Hz, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1080P (1920 × 1080)/60 Hz
HDMI2：4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz
*: When HDMI 1 output resolution is 8K, the maximum HDMI 2 output resolution is 1080p. - VGA OutputVGA1：1080P (1920 × 1080)/60 Hz
VGA2：1080P (1920 × 1080)/60 Hz - Audio Output1-ch, RCA (Linear, 1 KΩ)
- Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KΩ)
- Decoding
- Decoding FormatH.265/H.265+/H.264/H.264+
- Decoding CapabilityUp to 2-ch@32 MP/2-ch@24 MP/4-ch@12 MP/8-ch@8 MP/16-ch@4 MP/32-ch@1080P
- Recording Resolution32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/ 2CIF/CIF/QCIF
*: After ultra HD resolution mode is enabled, the NVR supports up to 8-ch 32 MP/24 MP IP video inputs. - Synchronous Playback16-ch
- Network
- Remote Connection128
- Network ProtocolTCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
- APIONVIF (profile S/G); SDK; ISAPI
- Compatible BrowserIE11, Chrome V57, Firefox V52, Safari V12, Edge V89, or above version
- Network Interface2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
- Auxiliary Interface
- Ctrl 12VControllable 12 V DC, 1 A power output for external alarm device; The power will be turned on when the alarm output is triggered.
*: The Ctrl 12V power is controlled by alarm output 9. - DC 12V12 VDC, 1 A power output
- SATA8 SATA interfaces; 3.5-inch HDD
- CapacityUp to 20 TB capacity for each HDD
- eSATA1 eSATA interface
- Serial Interface1 RS-232, 1 RS-485 (full-duplex)
- USB InterfaceFront panel: 2 × USB 2.0; Rear panel: 2 × USB 3.0
- Alarm In/Out16/9
- General
- GUI LanguageEnglish, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Turkish, Japanese, Danish, Swedish Language, Norwegian, Finnish, Korean, Traditional Chinese, Thai, Estonian, Vietnamese, Croatian, Slovenian, Serbian, Latvian, Lithuanian, Uzbek, Kazakh, Arabic, Ukrainian, Kyrgyz , Brazilian Portuguese, Indonesian
- Power Supply100 V to 240 V AC, 50 Hz to 60 Hz
- Consumption≤ 60 W (without HDD)
- Working Temperature-10℃ to 55℃ (14℉ to 131℉)
- Working Humidity10% to 90%
- Dimension (W × D × H)442 mm × 460 mm × 88 mm
- ≤ 13 kg (without HDD)
