8 kanallı 1U, 8 PoE, 8K DeepinMind NVR
8 kanallı 1U, 8 PoE, 8K DeepinMind NVR
Sorğu əsasında
Qiymət sorğusu- Intelligent Analytics
- AI by NVR
Pre-installed AI Algorithm Package
Human (3 Algorithm models)
1. Facial recognition
2. People counting: regional people counting, people counting statistics
3. PPE: safety helmets and reflective vests detection
Vehicle (2 Algorithm models)
1. Vehicle attribute: vehicle brand, vehicle color, vehicle type
2. Non-motorized vehicle detection: motorcycle, bicycles
Dangerous Event (2 Algorithm models)
1. Fire and smoke detection
2. Occupation of fire escape
Behavior (3 Algorithm models)
1. Street level behavior: falling down detection, people gathering detection, fast moving detection, physical conflict detection
2. Indoor: playing mobile phone, number of people exception, overstaying detection
3. Perimeter: intrusion detection, line crossing detection, region entrance detection, region exiting detection
4. Smoke detection, call detection
AIOP (Up to 16 models)
Model type: detection model, classification model, mixed model (detection model and classification model)
- AI by CameraFacial recognition, perimeter protection, video structuralization, motion detection2.0, ANPR, people counting, VCA
- Engine24
- Video and Audio
- IP Video Input256
- VGA Output1920 × 1080/60 Hz
- Audio Output1-ch, 3.5mm
- Two-Way Audio1-ch, 3.5mm
- Synchronous Playback16-ch
- Incoming Bandwidth (RAID Mode)1024 Mbps
- Outgoing Bandwidth (RAID mode)768 Mbps
- HDMI 1 Output4K (4096 × 2160)/30 Hz, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz
- HDMI 2 Output4K (4096 × 2160)/30 Hz, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz
- Video Output Mode
Provide 4 groups of video outputs. The video outputs in the same group provide simultaneous output, and the video outputs between each group provide independent output.
Group 1: HDMI 1/VGA/LCD
Group 2: HDMI 2
Group 3: DP 1/V-DP 1
Group 4: DP 2/V-DP 2
Note: After enabling DP 1/DP 2, V-DP 1/V-DP 2 would be unavailable.
- Decoding
- Recording Resolution32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
- Decoding FormatH.265+/H.265/H.264+/H.264
- Synchronous Playback16-ch
- Decoding Capability2-ch@32 MP (30 fps)/2-ch@24 MP (30fps)/4-ch@16 MP (30fps)/8-ch@8 MP (30fps)/16-ch@4 MP (30fps)/32-ch@2 MP (30fps)
- Live View Window Division64/36/25/16/9/8/6/4/2/1
- Aux Port Window DivisionG.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2/PCM/MP3
- Network
- Network Interface4, RJ-45 10/100/1000/2500 Mbps self-adaptive Ethernet interface
- Remote Connection256
- Network ProtocolTCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS, ONVIF(Version 2.2), OTAP
- APIONVIF (profile S/G); SDK; ISAPI
- Camera Access ProtocolONVIF(Version 2.5), RTSP
- RAID
- RAID Type RAID0, RAID1, RAID5, RAID6, RAID10
- Auxiliary Interface
- Serial Interface1 RS-485 (full-duplex), 1 RS-232
- SATA24
- eSATA 1 eSATA interface
- CapacityUp to 20 TB capacity for each disk
- Fiber Optic Interface4, Gigabit Ethernet interface
- Alarm In/Out16/8
- USB InterfaceFront panel: 2 × USB 2.0; Rear panel: 4 × USB 3.0
- General
- GUI LanguageEnglish, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Turkish, Japanese, Danish, Swedish Language, Norwegian, Finnish, Korean, Traditional Chinese, Thai, Estonian, Vietnamese, Croatian, Slovenian, Serbian, Latvian, Lithuanian, Uzbek, Kazakh, Arabic, Ukrainian, Kyrgyz , Brazilian Portuguese, Indonesian
- Power Supply100 to 240 VAC, 50 to 60 Hz, redundant power supply
- Consumption≤ 360 W (without HDD)
- Working Temperature0 °C to + 50 °C (32 °F to 122 °F)
- Working Humidity10% to 90%
- Dimension (W × D × H)448 × 490 × 173 mm (17.6″ × 19.3″ × 6.8″)
- ≤ 35KG
- Certification
- Obtained CertificationCE, IC, CB, KC, Rohs, Reach, WEEE, RCM, UKCA, LOA
