Qiymət sorğusu- Basic Parameter
- Fiber TypeMulti-mode
- Channel8
- Single-Channel DetectionRange10km
- Positioning Accuracy10km：±0.5m
- Temperature Range-200℃~800℃(actual temperature monitoring capability depends on the selected fiber optic).
- Temperature Accuracy±1℃
- Temperature Resolution0.1℃
- Spatial Resolution1m
- Sampling Interval0.4m
- Partition Quantity≤1000 per channel，it is configurable
- Alarm Response Time≤5s per channel
- Function
- Alarm TriggerConstant Temperature Alarm, Temperature Rise Alarm, Temperature Drop Alarm, Temperature Difference Alarm
- LED Indicator
Power indicator:
Solid blue: power on
Light off: power off
Running indicator:
Solid blue: program running normally
Flashing blue: program running abnormally
Fault indicator:
Light off: all-in-one module running normally
Solid yellow: all-in-one module error
Tamper indicator:
Solid red: tamper alarm triggered
Light off: tamper alarm not triggered
- Buzzer
Stay buzzing for tampering alarm.
When the alarm information is processed or the clear alarm/mute button is pressed, the buzzer can be muted.
- Switch1 rocker switch for power, 1 mute button, 1 clear alarm button
- Communication
- Communication MethodWired communication
- Interface
- Fiber Interface8 FC/APC fiber interfaces
- Power Interface1 power input interface with 100~240V AC power input
- Function Interface
1 RJ45 1000 M network interface,
1 RS-232 interface,
2 RS-485 interfaces,
2 USB 3.0 interfaces
- Alarm Out32 relay outputs
- General
- MaterialMetal
- Power100-240V～50/60Hz 0.5A
- ColorBlack
- Power Consumption＜20 W
- Operating Temperature-15 °C to 55 °C (5 °F to 131 °F)
- Operating Humidity0% to 95% (± 2%)
- Laser Classification Class 1
- Dimension133.51 mm × 483 mm × 449.21 mm (5.26″ × 19.02″ × 17.69″)
- Approx. 10.1 kg (22.27 lb.)
