- Function
- Protection FunctionOutput Protection: Over-Current Protection, Over-Temperature Protection
Clipping Output Processing: Supports single-stage peak detection compressor
- Network
- Network ProtocolAES67, TCP/IP, ICMP, HTTP, HTTPS, DNS, RTP, RTSP, RTCP, NTP, QoS, UDP, SSL/TLS, IEEE1588, IPv4, IGMP, DHCP, ARP, SSH
- Interface Protocol (API)OTAP, EZVIZ
- Audio
- Rated Power4×120W@4Ω
4×120W@8Ω
2×250W@70V（Two-Channel Bridging）
2×240W@100V（Two-Channel Bridging） - THD and SNRTHD: ＜0.05%@1 kHz，1/3 rated power
SNR: >108 dB - EqualizerEach analog input and output channel supports a maximum of 8-band parametric equalizer
- Monitor3-inch display screen
- Interface
- Alarm1 EVAC alarm input
2 alarm input
1 alarm output, when the output device connected to the alarm output is normally closed, connect: 1A GND; when the output device connected to the alarm output is normally open, connect: 1B GND. - Ethernet Interface1 RJ45 10 M/100 M adaptive Ethernet port
- Local StorageBuilt-in 4 GB EMMC (Audio file storage is 1 GB.)
- Audio InRCA in 1 to 4: 0 dBV, 10 kΩ, unbalance, RCA pin jack
XLR in 1 to 4: -8dBu, +4dBu, +21dBu, 13.6kΩ, balance, plug-in screw temrinals
USB 2.0 × 1
Type-C × 1
AES67 IN × 2
*RCA in 1 to 4 and XLR in 1 to 4 cannot be used in the same time - Audio OutOutput Mode 1 (4-channel): Constant Impedance Output × 4: 4 Ω COM & 8 Ω COM, up to 125 W for a single channel output
Output Mode 2 (2-channel): Constant Impedance Output × 2: 4Ω / 8Ω COM, up to 250 W per channel
Constant Voltage Output × 2: 100 V COM & 70 V COM, up to 250 W for a single channel output
RCA out 1 to 2: 0 dBV, unbalance, RCA pin jack
*Constant Impedance Output and Constant Voltage Output cannot be used in the same time. - LED IndicatorPower Indicator:
• Red: Device is powered on.
• White: Device is operating normally.
Input Indicator:
• Green: At least one input channel has a signal.
• Yellow: At least one input channel has a level limitation or overload.
Output Indicator:
• Green: At least one output channel has a signal.
• Yellow: At least one input channel has a level limitation or overload condition.
• Red: At least one output channel has a short circuit, overtemperature, undervoltage, overload, mute, or standby condition.
Network Indicator:
• Red: Network is not connected.
• Green: Network is connected.
EVAC Alarm Indicator:
Red: Device has triggered the EVAC alarm. - ButtonJog dial button × 1
- USBUSB 2.0. File format: FAT32 and EXFAT, maximum capacity: 256 GB.
FAT32 formatted USB drive: maximum capacity of a single partition is 32 GB
EXFAT formatted USB drive: Maximum capacity of a single partition is 256 GB
- General
- Power100 to 240 VAC
- MaterialFront panel: AL6063
Main body: SGCC - Dimension482.87 mm × 50.1 mm × 297 mm (9.01″ × 1.97″ × 11.69″)
- Package Dimension570 mm × 138 mm × 410 mm (22.44″ × 5.43″ × 16.14″)
- ≈ 5.7 kg (12.57 lb.)
- With Package Weight≈ 6.3 kg (13.89 lb.)
- ColorBlack
- Packing ListDevice × 1
Power cable × 1
Regulatory Compliance and Safety Information × 1
Screw pack × 1
Terminal attachment pack × 1 ； - Operating Temperature-10 °C to 50 °C (-14 °F to 122 °F )
- Operating Humidity＜90% (No condensation)
- Power ConsumptionStandby Consumption: 7 W
Annual Average Consumption: Max. Working Consumption: 200 W (based on the average playing time) - EnvironmentThis device can only be safely used in the region below 2,000 meters above the sea level
