- Software features
- Tag48
- Area32
- ZonesUp to 96 (including 48 PIRCAMs & 16 onboard Wired Zones & 2 onboard Wired Outputs)
- Onboard video clips4
- Installer1
- User46
- Admin1
- Voice PromptSupported
- Loudspeaker built inSupported
- Tag reader built inNo
- Memory Log stored5000
- Programming toolsHik-Connect/Hik-ProConnect/Web Portal/ IVMS4200/ Convergence Cloud
- Firmware upgradeAPP/Web Portal
- Arm modesAway/Stay
- Automatic Arm/Disarm TimersSupported
- Forced Arming with Open ZonesSupported
- Diagnostics via the APP or WebSupported
- ARC protocol
SIA DC09(SIA level 2, Contact ID), ISUP, ISAPI (SDK)
Hik-IP Receiver & Hik-IP Receiver Pro (Sur-Gard & Ademco 685)
Supports video verification and remote control
- User APP for operatingSupported
- Installer APP for programmingSupported
- Web server for maintenance (offline configuration)Supported
- Hardware features
- Power Output2 onboard (12v, total 1A)
- RS232 outputSupported
- SIM slotDual
- RF transmission
- Two-way Wireless CommunicationSupport
- RF Frequency433Mhz
- Wireless SecurityFrequency Hoping 128 AES Encryption
- 3/4G on boardSupported
- Display
- LEDs StatusArm/Disarm, Alarm, Tamper, Fault, Cloud, Power
- Electrical characteristics
- Power supplyBuilt in power supply
- Battery type12v 7Ah Storage battery (Battery is not included by default)
- Battery life spanUp to 36 hours at normal temperature (The battery working time can be significantly reduced at low temperatures)(Battery life varies from different battery types)
- Wireless transmission
- Wired networkSupported
- Wi-Fi StandardSupported
- General
- Operation temperature-10 °C to 40 °C
- Shell materialPlastic
- Dimension(WxHxD)261*199*86.4mm
1083g (No battery)
- ColorWhite
- Device management
- Keyfob48
- Wireless sounder6 (3 internal+3 External)
- Keypad8 (Including Tag reader)
- Wireless Repeater4
- Multi Transmitter5
- PIR CamSupported
