Qiymət sorğusu- Card parameters
- Product standards compliance• ETSI TS 102 671
• ETSI TS 102 221
• RoHS: Restrictions of Hazardous Substances Directive
• REACH: Registration, Evaluation, Authorisation and
Restriction of Chemicals
• GSMA SAS-UP
• GSMA SAS-SM
• ISO 10373-1
• ISO 7810
• ISO 7816 - Data retention (RX = RC)10 Years @25°C
- Endurance cycles (UX = UB)
ETSI TS 102 221Integrated Circuit: Minimum 320,000 read/write cycles
Kigen Operating System enhanced high endurance flash interface
enables approximately 240 million chunk updates, which can be
interpreted as 10 million+ updates for a specific file with a high
update frequency - Operational and storage
temperature (TX = TA)
JESD22-A104-40℃ to 105℃ - Corrosion (CX = CA)
JEDEC22-A107BSalt atmosphere corrosion test: 24 hours - Electrical characteristicsOperating Voltage: 1.62V ~ 5.5V
Operating External Frequency
1 ~ 10MHz (Class A/B), 1 ~ 7.5MHz (Class C)
Operating External Frequency
Max 28MHz - Technology2G/3G/4G/LTE/5G – according to the profile
- Function•Internet traffic
•Calls and Messages
•10M default data - Cut2FF/3FF/4FF removable (Any cut, any combination)
- Form factorFull ISO Size / Half ISO Size
- General
- Dimension (W×H×D)86(3.34″) x 54 (2.12″) x 1 (0.04″) mm
- 1 g
