- System
- Motorbrushless motor
- MCBF≥ 3 million times
- Operating systemNA
- IR light detectors4 pairs
- BrakeNot support
- Interface
- Exit button
Main: 1
Sub: 1
- Fire alarm input1
- Hardware
- Access controllerNot supplied
- SupercapacitorSupplied
- General
- Throughput
20 to 60 persons per minute
The actual throughput is affected by the person passing rate and passing method.
- Lane width600 mm to 750 mm (23.62″ to 29.53″)
- Barrier material10 mm acrylic glass
- Pedestal materialSPCC 1.2mm
- IndicatorNA
- Working temperature -20 °C to 65 °C (-4 °F to 149 °F)
- Working humidity0% to 95% (No condensing)
- Dimensions
Without package: 1200 mm × 220 mm × 900 mm (47.24″ × 8.66″ × 35.43″)
With package: 1255 mm × 275 mm × 960 mm (49.41 × 10.83″ × 37.80″)”
Net:
Left: 53 kg (116.84 lb)
Middle: 60 kg (132.28 lb)
Right: 55 kg(121.25 lb)
Gross:
Left: 63 kg (138.89 lb)
Middle: 70 kg (154.32 lb)
Right: 65 kg (143.30 lb)
- Approval CE/CB/RoHS/REACH/WEEE
- Power supply methodPower supply: 100 to 240 VAC~, 50/60 Hz, 0.7A
- Power supply for face recognition moduleSupport
- Configuration
- Module selectionNO
- Application environmentindoor and outdoor ( waterproof )
