Qiymət sorğusu- Face Recognition Terminal/System parameters
- ModelDS-K1T341CMF
- Operating systemLinux
- Face Recognition Terminal/Display parameters
- Screen size4.3-inch
- Operation methodCapacitive touch screen
- TypeLCD
- Resolution480 × 800
- Face Recognition Terminal/Video parameters
- Lens× 2
- Resolution2 MP
- Face Recognition Terminal/Network
- Wired network10 M/100 M/1000 M self-adaptive
- Face Recognition Terminal/Interface
- Network interface1
- Lock control1
- Exit button1
- Door contact input1
- TAMPER1
- RS-4851
- Wiegand1
- USB1
- Face Recognition Terminal/Capacity
- Face capacity1,500
- Fingerprint capacity1,500
- Card capacity1,500
- Event capacity150,000
- Face Recognition Terminal/Authentication
- Face recognition distance0.3 to 1.5 m
- Face recognition accuracy rate＞99%
- Face recognition duration＜ 0.2 s
- Fingerprint recognition duration＜ 1 s
- Card typeM1 card
- Card reading frequency13.56MHz
- Card reading distance0 to 3 cm
- Card reading duration＜ 1 s
- Face Recognition Terminal/Function
- QR code recognitionSupport
- Face anti-spoofingSupport
- Audio promptSupport
- Time synchronizationSupport
- Face Recognition Terminal/General
- ButtonTouch screen
- Power supply12 VDC, 2 A.
- Working temperature-30 °C to 60 °C (-22 °F to 140 °F)
- Working humidity0 to 90% (No condensing)
- Protective levelIP65
- Dimensions172.5 mm × 83.2 mm × 22.7 mm (6.79″ × 3.27″ × 0.89″)
- InstallationSurface mounting
- Magnetic Lock/General
- ModelDS-K4H258S
- UnlockmethodCurrent interruption
- Maximum holding force280 kg (617.4 Lbs) linear thrust
- Power supply12 VDC, 340 mA
- IndicatorGreen (work status)
- Surface temperature≤ ambient temperature 20 °C (68 °F)
- Working temperature-10 °C to 55 °C (14 °F to 131 °F)
- Working humidity0 to 95% (relative humidity)
- Dimensions
Lock body: 238 mm × 45 mm × 25 mm (9.4″ × 1.8″ × 1.0″)
Armature plate: 182 mm × 38 mm × 12.5 mm (7.2 × 1.5″ × 0.5″)”
- 2.1 kg (4.6 Lbs)
- Suitable doorWooden door, glass door, metal door, fireproof door
- Shell performanceHard anodizing electroplating operated
- Lock bodyEco-friendly Nickel electroplating operated
- Armature plateEco-friendly Nickel electroplating operated
- Card/General
- ModelFM11RF08-M1
- RAM1 K byte
- Card reading frequency13.56 MHz
- Card propertyThin card
- FunctionRead/write
- Card reading distance≤10 cm
- Working temperature-20 °C to 75 °C (-4 °F to 167 °F)
- Dimensions85.5 mm × 54 mm × 0.8 mm (3.37″× 2.13″ × 0.03″)
- ＜ 5.6 g (0.2 oz)
- MaterialPVC
- ColorWhite
- Bracket of Magnetic Lock/General
- Dimensions
L-bracket: 238 mm ×30 mm × 47 mm (9.4″ × 1.2″ × 1.9″)
Z-bracket: 185 mm ×44mm × 100 mm (7.3 ×1.7″ × 3.9″)”
- ModelDS-K4H258-LZ
- Suitable DoorWooden, metal
- Shell performanceHard anodizing electroplated
- 0.77 kg (1.7 lb)
- Exit Button/General
- ModelDS-K7P03
- Power supply12 VDC, 40 mA (standby)/70 mA (working)
- Current rating1 A@30 VDC
- Working temperature-20 °C to 50 °C (-4 °F to 122 °F)
- Working humidity0 to 95% (relative humidity)
- Dimensions86 mm × 86 mm × 25.7 mm (3.39″ × 3.39″ × 1.01″)
- 0.2 kg (0.44 lb)
- MaterialStainless steel
- Output contactNO/NC/COM contact
- Aging testAlready passed 1 million times aging test
- Suitable doorAll kinds of narrow doorframes
