- Main LCD
- Panel Typea-Si TFT-LCD
- Screen Dimensions18.5 inch
- Display Color16.7 M
- Screen Ratio16:9
- Resolution1366 × 768, SXGA
- Panel Brightness1000 cd/m² (Typ.)
- Contrast1000:1 (Typ.) (transmission)
- Touch Resolution32767 × 32767
- Touch Accuracy< 1.5 mm (central area), < 3.2 mm (edge area)
- Response Time< 16 ms
- Touch Intensity< 85 g
- Touch TimesNo limit
- Service Life30000 h
- Transmittance> 95%
- Coin Collection
- Coin In ModeFrom top/side
- Receiving TypeMax. 3
- Coin Collection Box Capacity137 mm × 167 mm × 55 mm (E.g., 800 × RMB 1 coin)
- Receiving Speed2 coins/s
- Coin Classification Channel3 channels optional
- Coin Dimensionsφ 15 to 30 mm
- Security CertificateCE, RoHS
- Coin Change
- Coin Out ModeOrbital coin out
- Coin Out TypeMax. 2
- Coin Change Box CapacityUltra-large capacity (E.g., 1300 × RMB 1 coin)
- Service Life3,000,000 coins, no internal spring, no quick-wear part, durable
- Printer
- Print ModeThermal line printer
- Print SpeedMax. 150 mm/s
- Print DirectionOne-way friction paper feed
- Paper Width80 mm
- Max. Width of Winding ShaftMax. 100 mm
- Print Density8 dots/mm
- Valid Print Width76 mm
- UPS
- Capacity2000 VA/1200 W
- Input VoltageRated voltage: 220 VAC, input voltage range: 140 to 290 VAC @ 50 Hz ± 10%
- Output VoltageOutput voltage range under utility mode: 210 to 235 VAC ± 1%, output voltage range under battery mode: 220 VAC ± 10% @ 50 ± 1 Hz, transition time: 2 to 6 ms, simulated sine wave
- Alarm1 time/8 s under battery mode, 1 time/1 s under low battery mode, 1 time/0.5 s under overload mode, continuous buzzer under error
- Battery12 V 9 AH battery set, chargeble to 90% in 6-8 h, enabling the device of 100 W to work for approx. 70 min under battery mode without power supply
- Protection FunctionSurge protection, Overload protection, Discharge protection, Short circuit protection
- PC
- MainboardMini ITX
- CPUI3 10110
- Memory4G DDR4 memory
- Storage256 G SSD
- SystemWin10 X64 operating system
- Installation
- Maintenance ModeFront maintenance installation, no need to embed into the wall
- Video Intercom
- Resolution
Main stream: 1920 × 1080p
Sub stream: 640 × 480p
- FoVHorizontal: 131°, vertical: 78°
- Supplement LightIR light, up to 3 m
- Audio Input1 built-in omnidirectional microphone
- Audio Output1 built-in loudspeaker
- Volume AdjustmentAdjustable
- Temperature Control System
- Heater500 W PTC heater, combined with 9225 ball fan to raise case temperature quickly
- Radiator12025 dual fans for heat dissipation
- ControllerTemperature range: 0 to 60 ℃, auto control
- Dehumidifier60 W, dehumidification space: 2 m³, moisture removal: 300 ml/day, auto dehumidification, humidity range: 0 to 99% RH
- Bill Collection
- Supported Currency TypeMax. 5
- ReliabilityMTBF (Mean Time Between Failures): 200,000 h
- ExtensibilityMultiple cash boxes/panels available
- Communication InterfaceRS-232
- Power Supply12 VDC
- Bill Collection Capacity500 pieces (1000 pieces available)
- Bill Change
- Supported Currency TypeMax. 3
- ReliabilityMTBF (Mean Time Between Failures): 200,000 h
- ExtensibilityMultiple cash boxes/panels available
- Communication InterfaceRS-232
- Power Supply12 VDC
- Bill Change Capacity500 pieces
- Code Reading
- Recognition ModeCMOS
- Image Pixel640 × 480
- Reading AngleTilt angle: ± 65°, pitch angle: ± 45°
- Reading Code TypeBar code, QR code
- InterfaceUSB, RS-232
- Reading Distance50 cm to 120 cm
- General
- Working EnvironmentWorking temperature: -25 ℃ to 50 ℃ (-13 °F to 122 °F), humidity: 10% to 90%
- Storage Temperature and HumidityStorage temperature: -25 ℃ to 70 ℃ (-13 °F to 158 °F), humidity: 10% to 90%
- Working Voltage220 VAC
- Power Consumption< 200 W
- Dimensions800 × 1706 × 695 mm (31.5 × 61.2 × 27.4 inch)
- Dimensions (with Package)900 × 1930 × 800 mm (35.4 × 76.0 × 31.5 inch)
- 195 kg (429.9 lb.)
- Weight (with Package)220 kg (485.0 lb.)
