- Display
- Viewing Angle178°(H)/178°(V)
- Screen Size21.5 inch
- Active Display Area478.66 (H) mm × 260.28 (V) mm
- BacklightELED
- Pixel Pitch0.241 (H) mm × 0.241 (V) mm
- Resolution1920 × 1080
- Brightness600 cd/m²
- Color Depth8 bit, 16.7 M
- Contrast Ratio1000:1
- Response Time8 ms
- Color Gamut72% NTSC
- Reliability7 × 16 h
- Touch
- Touch TypeCapacitive touch
- Glass3 mm anti-glare toughened glass
- Touch Point10
- Built-in System
- Operation SystemAndroid 12.0
- CPUCortex-A55，4 Cores, 1.8 GHz
- Memory2 GB
- Built-in Storage16 GB EMMC
- Smart
- Lens2 MP WDR Camera
- Face Database 50,000 pictures, JPG format allowed
- Face Detection Distance
Up to 5 m (196.86”)
0.3 m to 1.5 m (11.81” to 59.06”) recommended
Adjustable through software
- Face Verification Accuracy＞99%
- Face Verification Time≤ 0.5 s/person
- Internal Function
- Loudspeaker8 Ω，3 W × 2
- Interface
- Network InterfaceLAN × 1, built-in Wi-Fi
- Data Transmission InterfaceUSB 2.0 × 2, BT 4.0 × 1, Card-swiping for IC card, Access control linkage
- Power
- Standby Consumption≤ 0.5 W
- Power Consumption≤ 60 W
- Working Environment
- Working Temperature0 ℃ to 40 ℃ (30 ℉ to 104 ℉)
- Working Humidity10% to 90% RH (without condensation)
- General
- Power Supply24 VDC,2.5 A
- Gross Weight8.21 kg
- Net Weight6.54 kg
- Package Dimensions (W × H × D)662 (W) mm × 530 (H) mm × 110 (D) mm (26.1 ” × 20.9 ” × 4.3 ”)
- Packing ListPower adapter × 1, access control linkage line × 1, quick start guide × 1, screw kit × 1, L-type ring spanner × 1, dust-proof bag × 1, intelligent cloud digital signage paper card × 1, power cord × 1
- Product Dimensions (W × H × D)
With base: 514.06 (W) mm × 383.79 (H) mm × 28 (D) mm (20.24” ×15.11” × 1.1”)
Without base: 514.06 (W) mm × 383.79 (H) mm × 26.6 (D) mm (20.24” × 15.11” × 1.06”)
